PORTABLE MP3/USB BOOM BOX
CONTROLS
1. STOP
/BAND/CLEAR BUTTON
2. ID 3/DISPLAY BUTTON
3. B-SKIP/DOWN BUTTON
4. REMOTE SENSOR INDICATOR
5. CARRYING HANDLE
6. LCD DISPLAY
7. MONO/STEREO/PLAY MODE BUTTON
8. CD PLAY / PAUSE
9. F-SKIP / UP BUTTON
10. MEMORY/CLOCK ADJ. BUTTON
11. STANDBY INDICATOR
12. M-UP/FOLDER UP BUTTON
13. TIMER/SLEEP BUTTON
REMOTE CONTROL UNIT
FUNCTION BUTTON
STOP/BAND/CLEAR BUTTON
B - SKIP / DOWN BUTTON
- 10 TRACK BUTTON
CLOCK-ADJ./MEMORY BUTTON
ID3/DISPLAY BUTTON
MUTE BUTTON
VOLUME - BUTTON
GB
60
SDM
Instruction Manual
14. STANDBY BUTTON
15. OPEN/CLOSE BUTTON
16. FUNCTION BUTTON
17. PRESET EQ BUTTON
18. VOLUME CONTROL +
19. VOLUME CONTROL -
20. SPEAKER
21. CD DOOR
22. USB PORT
23. TELESCOPIC ANTENNA
24. BATTERY COMPARTMENT
25. PHONES JACK
26. AC SOCKET
27. AUX IN JACK
POWER STANDBY BUTTON
PLAY/PAUSE BUTTON
F - SKIP / UP BUTTON
+ 10 TRACK BUTTON
MEMORY DN/UP BUTTON/
FOLDER DN/UP BUTTON
MONO/ST./PLAY MODE BUTTTON
TIMER/SLEEP BUTTON
PRESET EQ BUTTON
VOLUME + BUTTON
Advertisement
Table of Contents
Related Manuals for Scott SDM60
Summary of Contents for Scott SDM60
- Page 1 PORTABLE MP3/USB BOOM BOX Instruction Manual CONTROLS 1. STOP /BAND/CLEAR BUTTON 14. STANDBY BUTTON 2. ID 3/DISPLAY BUTTON 15. OPEN/CLOSE BUTTON 3. B-SKIP/DOWN BUTTON 16. FUNCTION BUTTON 4. REMOTE SENSOR INDICATOR 17. PRESET EQ BUTTON 5. CARRYING HANDLE 18. VOLUME CONTROL + 6.
- Page 2 WARNING CLASS 1 LASER PRODUCT CAUTION CLASS 1 LASER PRODUCT INVISIBLE LASER RADIATION APPAREIL Á LASER DE CLASSE 1 WHEN OPEN AND INTERLOCKS PRODUCTO LASER DE CLASE 1 DEFEATED. AVOID EXPOSURE TO BEAM This product contains a low power laser device. Warning: Do not touch the lens.
-
Page 3: Power Supply
POWER SUPPLY USING HOUSE CURRENT Before use, check that the rated voltage of your unit matches your local voltage. USING BATTERIES Disconnect the AC power cord from the AC inlet of the unit. Battery power battery door is cut automatically by the cord while it is connected. To AC outlet To AC socket When the volume decrease, or the sound distorts, replace all of... -
Page 4: Clock Adjustment
CLOCk ADJUSTMENT 1. The clock is displayed on CD display at power off condition. MEMORY/CLOCK-ADJ. 2. Press the MEMORY CLOCK-ADJ. button, hour of clock flash. 3. Press the F-SKIP/UP or B-SKIP/DOWN to adjust hour digit. 4. Press the MEMORY CLOCK-ADJ. button, the minute digit flash. 5. Press the F-SKIP/UP or B-SKIP/DOWN to adjust minute digit. 6. Press the MEMORY CLOCK-ADJ. button again, the correct time is shown on display. LISTENING TO THE RADIO Press the FUNCTION button and select Radio 2 . Select AM or FM by pressing the... -
Page 5: Compact Disc Playback
COMPACT DISC PLAYBACk Press the FUNCTION button and select CD Insert a disc with the label side facing up. mode. Press OPEN/CLOSE button to close the CD door. For CD: Total number of tracks and time will be shown on the display. For MP3: Total number of folder and tracks will be shown on the display. -
Page 6: Folder Up / Down
REPEAT , REPEAT FOLDER AND MIX PLAYBACk Press PLAY MODE button during stop mode. CD plays with a single track repeat, all tracks repeat or randomly. FOR NORMAL COMPACT DISC PLAYBACk FOR MP3/WMA/USB PLAYBACk Mode sequence REPEAT >> REPEAT ALL Mode sequence REPEAT >> REPEAT FOLDER >> >> RANDOM >> REPEAT OFF. REPEAT ALL >> RANDOM >> REPEAT OFF. During Repeat 1 mode, During Repeat 1 mode, display shows display shows During Repeat 2 mode, During Repeat 2 mode, display shows display shows During Repeat 3 mode, display shows During Mix mode, display shows During Mix mode,... -
Page 7: Program Playback
ID 3 DISPLAY Song name,Singer name and album name can be displayed cyclically by pressing ID3 button during playing MP3. Title-song name Artist-singer name Album-Album name Press ID3 again to cancel ID3 display. PROGRAM PLAYBACk FOR NORMAL COMPACT DISC PLAYBACk Programmed playback enables tracks on a disc to be played in the desired order. CD display Up to 60 tracks can be programmed. Press the “ MEMORY “ button. Press the skip buttons to select the desired track number. Press “ MEMORY “ button again to memorize the track. Repeat steps 2 and 3 until all desired tracks are programmed. Press the “ PLAY/PAUSE “ button to start. “ MEMORY “ is shown on the CD display. Press “ STOP “ button to stop programmed playback. -
Page 8: Maintenance
MAINTENANCE CLEANING THE UNIT CLEANING CD Do not use volatile chemicals on this unit. Clean by lightly wiping with If the CD skips or will not play , the disc may a soft cloth. need cleaning. Before playing, wipe the disc from the centre out with a cleaning cloth. After IMPORTANT NOTE playing, store the disc in its case. If an abnormal display indication or an operating problem occurs, discon- nect the AC power cord and remove the batteries. Wait at least 5 seconds, then reconnect the AC power cord or reinstall the batteries.
