FRIDGE FREEZER - MODELS RFA18, RFM18, RFA66, RFM66
INSTRUCTIONS FOR INSTALLATION & USE
GETTING STARTED:
STEP 1
Choose a location for your
fridge freezer, away from
any heat sources and
allow adequate
ventilation - 100mm
(4 inch) gap above.
STEP 3
Level the fridge freezer by
adjusting the front feet.
This will stop rocking or
vibration and keep the
door aligned.
NB. The spanner is for illustration
only and is not supplied with the
fridge freezer.
STEP 5
Plug in and switch on.
Allow the fridge freezer to
cool before placing food
inside.
The high temperature
light will stay on until the
fridge freezer has cooled
down.
All food in the fridge
freezer should be
covered.
Read the rest of these instructions to get the best from your appliance and
To ensure that your fridge freezer runs reliably and efficiently follow these steps.
STEP 7
remember to fill in your guarantee registration.
Keep this Book in a safe place for quick reference.
STEP 2
Move the fridge freezer
into position, using the
sides of the cabinet.
Take care to avoid
damaging the refrigerant
circuit pipe work on the
rear.
STEP 4
Before plugging in and
switching on, leave the
fridge freezer in its final
location for at least 15
minutes to allow it to
settle.
STEP 6
If you are freezing fresh
food, turn on fast freeze
by pressing the switch 24
hours before placing the
food inside.
Place the fresh food
inside.
Remember to turn fast freeze off
after 24 hours, however if you
forget to do so it will automatically
cancel after 48 hours.
Your fridge freezer is now
working.
If after 24 hours your
fridge freezer is not
operating as you want,
refer to the
TROUBLESHOOTING
section.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hotpoint RFA18
Summary of Contents for Hotpoint RFA18
- Page 1 FRIDGE FREEZER - MODELS RFA18, RFM18, RFA66, RFM66 INSTRUCTIONS FOR INSTALLATION & USE GETTING STARTED: To ensure that your fridge freezer runs reliably and efficiently follow these steps. STEP 1 Choose a location for your fridge freezer, away from any heat sources and...
-
Page 2: For Your Safety
For your safety, read the following advice: The fridge freezer cooling system contains a small amount of gas which is environmentally friendly but flammable. To avoid any risk :- Install the fridge freezer following the installation instructions and ensure that ventilation openings are kept clear of obstruction. Take care when installing or moving the fridge freezer to avoid damaging the pipes on the rear. -
Page 3: Installation
Location & Air Circulation Locate your fridge freezer away from sources of heat e.g. cookers, radiators, direct sunlight as extreme temperature will affect its performance. Allow a minimum 100mm (4 inches) between the top of the fridge freezer and the ceiling or the underside of a wall cupboard. - Page 4 Levelling: Level the fridge freezer when it is in its final location by adjusting the front feet, until firm contact is made with the floor. This will stop rocking or vibration and keep the doors aligned which helps the fridge freezer run reliably and efficiently. Note: Before plugging in and switching on, leave the fridge freezer standing in its final location for at least 15 minutes to allow it to settle.
- Page 5 Changing the Mains Lead This appliance is fitted with a special mains lead. If you need to replace the mains lead due to damage, one can be bought from Hotpoint Service (see KEY CONTACTS, back page). It is strongly advised that this work is carried out by a qualified electrician.
- Page 6 Your fridge freezer must NOT be placed in a room where the temperature goes below 6˚C or above 38˚C (models RFA18, RFM18), below 6˚C or above 43˚C (models RFA66, RFM66) for prolonged periods, as the internal temperatures will not be maintained.
- Page 7 The amber fast freeze light indicates that the fast freeze button has been pressed on. By pressing this button ON, the freezer motor will run continuously for extra cooling. Amber Holiday Light (Models RFA18,RFM18 only) The amber holiday light indicates that the holiday mode is set.
- Page 8 Once the fresh food is loaded leave fast freeze on for 24 hours to freeze the food as quickly as possible. Maximum freezing capacity in 24 hours: RFA18,RFM18,RFA66,RFM66 Note : Don’t forget to turn fast freeze off after 24 hours. However fast freeze will turn off automatically after 48 hours if you do forget.
-
Page 9: Useful Advice
Model Number and Serial Number can be found near the bottom of the freezer compartment on the interior wall. Fast Freeze Models: RFA18,RFM18 Useful Advice Note: The photographs indicate the Fast Freeze and storage areas (see tables). The fridge cabinet and door furniture will vary according to each model specifications. - Page 10 Making the best use of your Fridge Freezer Note : Always use the handle provided to open the fridge / freezer door. To ensure that your fridge freezer operates as efficiently as possible : Follow food packaging “best before/use by” instructions or your suppliers advice on a suitable maximum storage time.
- Page 11 Commodity and Bottle Racks Commodity racks can be repositioned in the door to suit your storage requirements. The lidded commodity rack is recommended for the storage of dairy items, such as butter, margarine and cheese. To remove, lift rack vertically to release from fixing supports. To replace, align grooves on either side of the rack above fixing supports and push down until secure.
- Page 12 Microban® technology has been proven safe, durable and effective over many years of use in personal care and household consumer products. In addition, Hotpoint operate a rigorous antibacterial testing programme through approved independent testing laboratories.
-
Page 13: Storage Guide
STORAGE GUIDE Frozen Food Storage Capacity Maximum Freezing Capacity in 24 hours Maximum Conservation Time from Failure Storing Food in a Freezer Freeze and store either fresh food or long term commercially frozen foods. Generally speaking long term storage means up to 3 months but this can vary, so always follow your supplier’s recommendations otherwise refer to the pictorial guide on the door liner (as shown, right). - Page 14 Advice on Using Freezer Drawers The freezer compartments can be used with or without the drawers. However, the bottom drawer needs to remain in position at all times (to maintain the correct storage temperature). It is generally more convenient to use the drawers but if a lot of food is to be stored the drawers can be taken out and food placed directly onto the grids.
- Page 15 Regular use of your appliance causes ice to gradually build up on internal surfaces increasing the running costs of your appliance. When the ice is between 3-5mm inch) Hotpoint recommend ‘fully defrosting your freezer’ . Fully defrosting your freezer... WARNING: Switch off electrical supply and pull out the mains plug.
- Page 16 Cleaning WARNING: Switch off electrical supply and pull out mains plug before cleaning. Interior Note : We recommend you use a straw to keep the defrost gutter drain hole clear of any blockage. DO NOT use sharp metal tools which could cause damage beyond repair.
-
Page 17: Maintenance
Note : Leave the doors ajar to prevent an accumulation of odours. Models RFA18,RFM18 only: Alternatively, if you want to keep your freezer running but want to empty the fridge you could set the holiday mode. -
Page 18: Door Reversal
Door Reversal You will need a selection of small hand tools, screwdrivers, spanners etc. to carry out this procedure. Our Service Department can arrange for an Engineer to do the conversion for you but a charge will be made. WARNING: Switch off electrical supply and pull out the mains plug. Remove all door furniture and all loose items/fittings from inside the fridge freezer. - Page 19 Door Reversal continued... Unscrew the foot and hinge bracket fitted to the bottom right hand side of the appliance. Unscrew the foot and footplate fitted to the left hand side of the appliance. Refit the hinge bracket and footplate to the opposite sides of the appliance. Screw in the feet until there is approximately 35mm projecting from the bottom front edge of the appliance.
-
Page 20: Troubleshooting
24 hours. However if you forget, it will automatically cancel after 48 hours. The amber holiday indicator light is on? (Models RFA18,RFM18 only) 1. Holiday mode is selected. Press the holiday button or open the fridge door to cancel this function and return the fridge freezer to normal operation. - Page 21 USEFUL ADVICE section), food should either be cooked and eaten within 24 hours or cooked and refrozen. If there is still a problem contact Hotpoint Service (See KEY CONTACTS, back page, for contact details). OPERATING SOUNDS OF A FRIDGE FREEZER...
-
Page 22: Hotpoint Guarantee
All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free replacement parts for the first 5 years (except microwaves, selected integrated appliances and cooker hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer. -
Page 23: After Sales Service
Hotpoint appliance than us - the manufacturer” As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts and labour guarantee for the first 12 months. In addition to this you also have the advantage of free replacement parts for the first 5 years when fitted by a Hotpoint engineer. -
Page 24: Key Contacts
Monday to Sunday, 8am to 8pm www.hotpointservice.co.uk Republic of Ireland: 1850 502 200 Genuine Parts and Accessories UK: 08709 077 077 Monday to Friday, 8.30am to 5pm Saturday, 8.30am to 12noon www.hotpointservice.co.uk Republic of Ireland: (01) 842 6836 www.hotpoint.co.uk 07/2005 195051338.01...
