- Page 1 Owner’s Manual CAM-MC Indoor Network Camera...
- Page 2 Universal Remote Control, Inc. Universal Remote Control, INC. shall not be liable for operational, technical or edi- torial errors/omissions made in this manual. The information in this manual may be subject to change without prior notice.
-
Page 3: Table Of Contents
ABLE ONTENTS Introduction Features and Benefits Parts Guide CAM-MC Description Basic Installation Communicating with the Camera Navigating the Web Interface - Live View Navigating the Web Interface - Admin Specifications Limited Warranty Statement End User Agreement Federal Communication Commission Interference Statement... -
Page 4: Introduction
Introduction Congratulations on your purchase of the CAM-MC Indoor IP Camera! The CAM-MC is an indoor IP camera that allows for seamless viewing over the network with Total Control interfaces such as the TRC-1280, TKP-2000, TKP-7000, iPad/iPhone (with TC Mobile App installed) as well as any future Total Control graphical interfaces. -
Page 5: Cam-Mc Description
NDOOR ETWORK AMERA CAM-MC Description Front View LAN LED Power LED Lens Lens Guide Rear View Name Description Power LED Blue – Powered ON LAN LED Green – Link (when connected to a network) Lens Lens for built-in camera Lens Guide... -
Page 6: Basic Installation
(If a PoE switch is not used, you must use a PoE injector to supply power to the camera.) Basic Installation Follow these basic steps to install the Indoor Network Camera CAM-MC. 1. Fasten the camera to your planned location using the supplied mounting bracket. -
Page 7: Communicating With The Camera
NDOOR ETWORK AMERA Communicating with the Camera An IP address is required to view the camera and modify surveillance options. Once installed, locate the IP address assigned by your router (which will differ from the default address below). Your router contains a DHCP table which displays each connected device and its IP address. -
Page 8: Navigating The Web Interface - Live View
NDOOR ETWORK AMERA Navigating the Web Interface - Live View Select from the options below to modify the Live View. Channel Control Displays multiple camera streams. It modifies the primary and secondary streams (frame rate, image size, encoding, camera name, rate control mode, image quality and group of pictures structure) from the Admin page (Device Configuration>... -
Page 9: Navigating The Web Interface - Admin
NDOOR ETWORK AMERA Navigating the Web Interface - Admin Use the Admin interface to modify advanced features for the camera. To gain acccess to the Admin site, enter the default username and password (root and root). Quick Configuration: A guided step-by-step walkthrough to setup your camera’s configuration settings. -
Page 10: Specifications
NDOOR ETWORK AMERA Specifications Camera Type IP Camera Image Sensor 1/4" VGA progressive scan CMOS Indoor / Outdoor Use Indoor Only Lens 3.8mm F2.0, fixed lens Min. illumination 5 lux color Video Compression H.264/MJPEG 640X480 (VGA) Video Resolution 320X240 (Q VGA) 160X112 (QQ VGA) Image quality Control 6 step quality control... -
Page 11: Limited Warranty Statement
Limited Warranty Statement 1. Limited Warranty and Disclaimers Universal Remote Control, Inc. (“URC”) warrants that the URC equipment shall be free from defects in material and workmanship under normal usage for one (1) year from purchase when such is purchased from URC. - Page 12 NDOOR ETWORK AMERA ARE SUPPLIED “AS IS”, WITHOUT ANY WARRANTY, EXPRESS, STATUTORY OR IMPLIED, OF ANY KIND. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, URC EXPRESSLY DISCLAIMS ALL WARRANTIES, EXPRESS, STATUTORY OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF QUALITY OR REASONABLE SKILL AND CARE, OR OUTCOME OR RESULTS.
- Page 13 YPE FOR ETWORK AMERA This limited warranty only covers the URC equipment issues caused by defects in material or workmanship during ordinary consumer use. It does not cover product issues caused by any other reason, including but not limited to product issues due to commercial use, acts of God, third- party installation, misuse, limitations of technology, or modification of or to any part of the URC equipment.
-
Page 14: End User Agreement
YPE FOR ETWORK AMERA MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. URC SHALL NOT BE HELD RESPONSIBLE FOR THE STATEMENTS MADE BY OTHERS. SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO END USER. -
Page 15: Federal Communication Commission Interference Statement
NDOOR ETWORK AMERA Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B dig- ital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 16: Regulatory Information To The User
: EN55022:2006+A1:2007 Immunity : EN61000-3-2:2006+A2:2009 Power : EN61000-3-3:1995+A1:2001+A2:2005 n Declaration of Conformity “Hereby, Universal Remote Control Inc. declares that this CAM-MC is in compliance with the Essential requirements and other relevant provisions of EMC Directive 2004/108/EC.” Certification Type No.(Model No.) CAM-MC Batch/Serial No. -
Page 17: Declaration Of Conformity
We declare our sole responsibility that the product Product : IP CAMERA Model Number(s): CAM-MC to which this declaration relates is in conformity with the following standards and therefore bears CE marking : : EN 55022:2006+A1:2007 (Class B) Information technology equipment-Radio disturbance characteristics-Limits and methods of measurement... - Page 18 NOTE Page 15...
- Page 19 YPE FOR ETWORK AMERA Page 16...
- Page 20 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com Page 17...
