P ro d u c t N u m b e r :
P ro d u c t N a m e :
As of September 2012. Specifications and appearance are subject to change without notice.
SFL12M015
S
P
E
C
PT VW431D
LCD Projector
F
I
L
E
1 / 1 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT-VW431D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic PT-VW431D

Summary of Contents for Panasonic PT-VW431D

  • Page 1 PT VW431D P ro d u c t N u m b e r : LCD Projector P ro d u c t N a m e : As of September 2012. Specifications and appearance are subject to change without notice. 1 / 1 3 SFL12M015...

  • Page 2: Digital Link

    PT VW431D LCD Projector Specifications Main unit Power supply 100 –240 V AC, 50/60 Hz Power consumption 365 W (0.3 W when set to 12.5 W when STANDBY MODE STANDBY MODE (19.7 W with DIGITAL LINK, 27.5 W, when NETWORK STANDBY MODE is set to SOUND...

  • Page 3: Lcd Projector

    PT VW431D LCD Projector COMPUTER (RGB) 2 IN / 1 OUT R, G, B D-sub HD 15-pin (female) × 1 (input/output selectable using on-screen menu.) G: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms; B, R: 0.7 Vp-p, 75 ohms; HD/VD, SYNC: high impedance, TTL (positive/negative) NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.
  • Page 4 PT VW431D LCD Projector Dimensions unit : mm (inch) NOTE: This illustration is not drawn to scale. 9 0.5 189.5 ( 3 - 9 /16 ) ( 7-15 / 32 ) 379 (14 -29 / 32 ) Terminals Computer 1 input Computer 2 input / computer 1 output HDMI input LAN / DIGITAL LINK connector...

  • Page 5: Standard Setting-Up Position

    PT VW431D LCD Projector Standard setting-up position NOTE: Illustrations show the projector installed using optional ceiling mount ∅ bracket ET-PKV100H and bracket (1-1/2) assembly ET-PKV200B. This illustration is not drawn to scale. Upper edge of projected image (5-5/8) (6-3/8) Projected image Lower edge of projected image unit : mm (inch) Projected image...
  • Page 6 PT VW431D LCD Projector Projection distance for 16:9 aspect ratio screen unit: meters (feet) Projection size Projection distance [L] Height from the edge of screen to center of lens [ H ] [diagonal] Min [wide] Max [telephoto] 0.76 m 30˝ (2.5) (3.9) 0.01...
  • Page 7 PT VW431D LCD Projector Shift range Optical axis shift function allows to shift the position of a projected image as shown below. • Floor mount • Ceiling mount (Width of (Width of projected image) projected image) Standard postition of projected image Standard postition of projected image Installable angle...
  • Page 8 PT VW431D LCD Projector List of compatible signals The signals that can be input to this projector are shown in the table below. Horizontal scanning fre- quencies of 25 kHz to 80 kHz (15 kHz to 100 kHz for RGB signals), vertical scanning frequencies of 50 Hz to 120 Hz (50 Hz to 100 Hz for RGB signals), and a dot clock of 162 MHz maximum (140 MHz maximum for RGB signals) can be input.
  • Page 9 PT VW431D LCD Projector Display mode Display Scanning frequency Dot clock Format resolution frequency (dots)* (kHz) (kHz) (MHz) WXGA DIGITAL LINK/ 1280 × 768 47.8 59.9 79.5 60.3 74.9 102.3 HDMI/RGB 68.6 84.8 117.5 50.0 68.6 1280 × 800 41.2 79.4 49.6 60.1...
  • Page 10 PT VW431D LCD Projector Serial connector The serial connector complies with RS-232C. To control the projector from a personal computer, com- mands must be input through communication software, based on the format and satisfying the commu- nication conditions shown below. Pin assignments and signal names Signal name Description...

  • Page 11: Cable Specifications

    PT VW431D LCD Projector Cable specifications Projector PC (DTE) Control commands Command: <Parameter> Function Callback: <Parameter> Parameter value – – Power on (standby mode on) – – Power off (standby mode off) Volume control AVL:<pl> AVL:<pl> – – Input signal selection IIS:<input si gnal>...
  • Page 12 PT VW431D LCD Projector Status request commands Command Description Callback <Parameter> Standby power status <power condition> Lamp status <lamp condition> <input signal> Input signal status <pl> Volume adjustment value Picture mode status Standard Dynamic Cinema Real Blackboard Colorboard Image 1 Image 2 Image 3 Image 4...
  • Page 13 PT VW431D LCD Projector Notes on projector placement and operation The projector uses a high-wattage lamp that becomes very hot during operation. Please observe the following precautions. Never place objects on top of the projector while it is operating. Make sure there is the unobstructed space as shown below or more around the projector’s exhaust openings.
