Summary of Contents for Allstar Products Group SPS-50
- Page 1 INSTALLATION AND OWNER’S MANUAL MODEL SPS-50 GATE OPERATOR STANDBY POWER SUPPLY 107887 READ THIS MANUAL Serial #: CAREFULLY BEFORE Date Installed: Your Dealer: INSTALLATION OR USE...
- Page 2 TABLE OF CONTENTS Pre-Installation Notes .............. 3 Installing the SPS-50..............4 LED Indicators ............... 5 Electrical Connections..........5 Testing................5 Battery Maintenance ............. 6 Wiring Diagram .............. 7 Technical Specifications ............8 Warranty..................8 READ THESE STATEMENTS CAREFULLY AND FOLLOW THE INSTRUCTIONS CLOSELY.
- Page 3 W A R N I N G ! operator when the main power is interrupted. Additionally, the SPS-50 control box has a set of relay outputs that are activated if TO REDUCE THE RISK OF SEVERE INJURY OR a low battery capacity is detected.
- Page 4 BATTERY PACK. The SPS-50 consists of control box and a battery pack. Connectors are located on the SPS-50 control box for AC IN, AC OUT, RELAY and BAT LO. Pre-wired harnesses are provided to mate with these connectors. The black and red wires are used to connect to the battery pack.
- Page 5 After the batteries are charged, the SPS-50 may be tested. To N - AC neutral: White test, turn the main power off and allow the SPS-50 to cycle the G- AC Ground: Green operator. There will be approximately a ten second delay...
- Page 6 When replacing batteries replace with the same number and type. The SPS-50 uses a PowerSonic PS-1270 rechargeable maintenance free, 12 volt, 7.0 amp/hour battery. When disconnecting the battery pack from the SPS-50 make W A R N I N G ! sure main AC power is turned on.
-
Page 8: Technical Specifications
Manufacturer’s Limited Warranty Linear LLC warrants its Allstar brand SPS-50 to be free from defect in material and workmanship for a period of one (1) year from the date of purchase for single family home or for multi-family and commercial use. To obtain service contact your dealer.
