LG LH247HV Specifications

Job Name/Location:
Date:
PO No.:
Architect:
Engr:
Rep:
(Company)
LH247HV
Single Zone High Static Duct
Outdoor Unit (ODU) ‐ LUU247
Performance:
Cooling:
Capacity (Btu/h)
SEER
EER
SEER ‐ Seasonal Energy Efficiency Ratio EER ‐ Energy Efficiency Ratio
Heating:
Capacity (Btu/h)
HSPF
HSPF ‐ Heating Seasonal Performance Factor
Cooling Nominal Test Conditions:
Indoor: 80°F DB/67°F WB
Outdoor: 95°F DB/75°F WB
Electrical:
Power Supply (V¹/Hz/Ø)
MOP (A)
MCA (A)
Cooling Rated Amps (A)
Heating Rated Amps (A)
Compressor (A)
Fan Motor (A)
Cooling Power Input (kW)
Heating Power Input (kW)
MOP ‐ Maximum Overcurrent Protection MCA ‐ Minimum Circuit Ampacity
Piping:
Liquid Line (in, OD)
Vapor Line (in, OD)
Additional Refrigerant (oz/ft)
Max Pipe Length (ft)²
Pipe Length (no add'l Refrigerant, ft)
Max Elevation (ft)
Features:
•ESP control
•Hot start
•Inverter (variable speed fan)
•Internal condensate pump
•Auto restart
Included Accessories:
•Simple Controller with Mode (White) ‐ PQRCVCL0QW
Optional Accessories (sold separately)
LG Programmable Controller ‐ PREMTB10U
Dry Contact Unit Dry Contact Unit (1 contact, 24 VAC external power) ‐ PQDSB1
AC Ez ‐ PQCSZ250S0
For continual product development, LG reserves the right to change specifications without notice.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. "LG Life's Good" is a registered trademark of LG Corp. /www.lghvac.com
For:
GC:
Mech:
(Project Manager)
Indoor Unit (IDU) ‐ LHN247HV
24,000
17.0
12.0
27,000
10.0
Heating Nominal Test Conditions:
Indoor: 70°F DB/60°F WB
Outdoor: 47°F DB/43°F WB
208‐230/60/1
18.1
15.1
15.1
13.5
0.6
2.00
2.28
3/8
5/8
0.43
164
•Control lock func on
•Group control
•Timer (on/off)
•Sleep mode
File Resubmit
Approval
Other
Operating Range:
Outdoor Unit:
Cooling (°F DB)
Heating (°F WB)
Indoor Unit:
Cooling (°F WB)
IDU Heating (°F DB)
Unit Data:
Refrigerant Type
Refrigerant Control
Refrigerant Charge (lbs)
ODU Sound Pressure Max (Cool/Heat) ±3 dB(A)³
IDU Sound Pressure (H/M/L) ±3 dB(A)³
ODU Net Weight (lbs)
ODU Shipping Weight (lbs)
30
IDU Net Weight (lbs)
IDU Shipping Weight (lbs)
Fan:
ODU Type
IDU Type
Fan Speeds (Fan/Cooling/Heating)
Fan Quantity (ODU + IDU)
Motor/Drive
ODU Air Circulation (CFM)
IDU Air Circulation H/M/L (CFM)
Max External Static Pressure (in wg)
Dehumidification Rate (pts/hr)
Notes:
1.Acceptable opera ng voltage: 187V‐253V.
25
2.Piping lengths are equivalent.
3.Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
98
4.All communica on/power cable to be minimum 18 American wire gauge (AWG), 4‐
conductor, stranded, shielded and must comply with applicable local and national code.
5.See Engineering Manual for sensible and latent capaci es.
6.Power wiring cable size must comply with the applicable local and na onal code.
7.The indoor unit comes with a dry helium charge.
8.This data is rated 0 above sea level, with 25 of refrigerant line and a 0 level
difference between outdoor and indoor units.
9.Must follow installa on instruc ons in the applicable LG installa on manual.
Tag #:
Brushless Digitally Controlled/Direct
DFS‐SB‐AM‐001‐US 013E28
PQRCVCL0QW
5‐118
0‐64
57‐77
59‐81
R410A
EEV
4.4
48/52
38/36/35
133
146
73
95
Propeller
Sirocco
3/3/3
1 + 1
2048
688/618/530
0.39
7.0
Page 1 of 3
