Programming the Dragon X2 Thermostat

The remote thermostat supplied with the Dragon X2 Mobile Furnace provides precise,

programmable temperature controls. When properly programmed, the thermostat will cycle the

Dragon on and off to maintain precise temperature range in the target area based on the settings

you program. The thermostat can be programmed in either degrees Fahrenheit or Celsius.

Note that the temperature sensor is located at the end of the cable, and should be placed inside the

environment you wish to heat. For best results, place the sensor away from drafts, windows, and any

equipment that may produce temperature variations.

1. When the Dragon is plugged in and the ON/OFF switch is turned to the Thermostat position, the

thermostat will display the ambient temperature.

The thermostat shows the current ambient temperature when connected to the Dragon.

2. Press the SET key once to access the Fahrenheit/Celsius select mode. The display will show the

current status, either F for Fahrenheit or C for Celsius. To switch between the two modes, press either

arrow key. Choose either F or C.

Choose either the Fahrenheit (F) or Celsius (C) mode.

Table of Contents

Do you have a question about the Dragon X2 and is the answer not in the manual?

Page 1 Sales Inquiries: Contact Sylvane at (800) 934-9194 or visit sylvane.com Programming the Dragon X2 Thermostat The remote thermostat supplied with the Dragon X2 Mobile Furnace provides precise, programmable temperature controls. When properly programmed, the thermostat will cycle the Dragon on and off to maintain precise temperature range in the target area based on the settings you program.
Page 2 Service Questions: Contact Dri-Eaz at (800) 932-3030 Sales Inquiries: Contact Sylvane at (800) 934-9194 or visit sylvane.com 3. Press the SET key again to access the set point. The display will blink "S1" and show the current set point in degrees. The set point is the maximum temperature you wish to maintain in the target area.
Page 3 6. Press the SET key once more to complete the programming of the thermostat. The Dragon X2 thermostat is now ready for use.
