Summary of Contents for Accton Technology 1000BASE-LX
- Page 1 1000BASE-LX Gigabit Uplink Module EM4582-LX-SC Quick Installation Guide...
- Page 3 Quick Installation Guide EM4582-LX-SC Gigabit Uplink Module Slide-in module with 1 1000BASE-LX (SC-type) port...
- Page 4 Sales: 800-926-9288 FAX: 886-3-5770-267 Support: 888-398-4101 or 949-707-4847 Internet: support@accton.com.tw RMA: 800-762-4968 FAX: 949-707-2460 Accton is a trademark of Accton Technology Corporation. Other trademarks or brand names mentioned herein are trademarks or registered trademarks of their respective companies. EM4582-LX-SC E102000-R01 150514-102...
-
Page 5: Table Of Contents
Contents Description of Hardware Gigabit Uplink Module Gigabit Port LEDs Installing the Module Package Contents Handling the Module Instructions Maximum Cable Lengths Troubleshooting Product Specifications EMI Certification FCC Class A Certification (USA) Canada Department of Communications - Class A BSMI Class A (Taiwan) VCCI Class A Compliance (Japan) CE Mark Declaration of Conformance for EMI and Safety (EEC) Safety Compliance... - Page 6 Contents...
-
Page 7: Description Of Hardware
Accton’s EM4582-LX-SC fiber optic module provides a Gigabit port which can be used for a high-speed backbone or server connection. It contains one 1000BASE-LX port that can be connected to a site up to 5 km (16,404 ft) away with single-mode fiber cable. -
Page 8: Installing The Module
User Guide Installing the Module Caution: Do not install this module in any unit other than the ES3514F, ES3526F, ES3526G, or ES3552. Contact your distributor for advice on newly released switches which may be designed for use with these modules. The EM4582-LX-SC fiber optic module is field installable. - Page 9 Installing the Module Keep the original faceplate for future use. If you should remove the module, replace the faceplate to prevent dust and debris from entering the unit and to maintain proper air flow. Insert the new module into the switch: Holding the new module with the text on the front panel upright, carefully slide the module into a lower slot on the rear panel, and press gently until it snaps into place.
- Page 10 User Guide Secure the new module: Secure the new module in place by screwing the attached screws clockwise into the switch’s chassis. Tighten them enough to secure the module, but not so tight as to prevent them from being unscrewed by hand.
-
Page 11: Maximum Cable Lengths
7-902 ft (2-275 m) 50/125 micron MMF 400 MHz/km 7-1641 ft (2-500 m) 500 MHz/km 7-1805 ft (2-550 m) Maximum 1000BASE-LX Gigabit Ethernet Cable Length Fiber Size Fiber Bandwidth Maximum Cable Length 62.5/125 micron MMF 500 MHz/km 2-550 ft (7-1805 m) -
Page 12: Troubleshooting
User Guide Troubleshooting If you experience any problems with the module, check the following items before contacting Accton Technical Support: • Ensure the switch with the fiber optic module is powered up. • Ensure that the device attached to the module is powered up and operating correctly. •... -
Page 13: Emi Certification
EMI Certification EMI Certification FCC Class A Certification (USA) Warning: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A digital device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 14: Ce Mark Declaration Of Conformance For Emi And Safety (Eec)
User Guide CE Mark Declaration of Conformance for EMI and Safety (EEC) This is to certify that this product complies with ISO/IEC Guide 22 and EN45014. It conforms to the following specifications: EMC: EN55022(1988)/CISPR-22(1985) class A EN60555-2(1995) class A EN60555-3 IEC1000-4-2(1995) 4kV CD, 8kV AD IEC1000-4-3(1995) -
Page 15: Underwriters Laboratories Inc. (Usa)
Safety Compliance Underwriters Laboratories Inc. (USA) Important! Before making connections, make sure you have the correct Cord Set. Check it (read the label on the cable) against the following specification list. Operating Voltage Cord Set Specifications 120 Volts UL Listed/CSA Certified Cord Set Minimum 18 AWG Type SVT or SJT three conductor cord Maximum length of 15 feet... -
Page 16: Warranty
Optional Hardware EM3604-FX-SC: Media Module with 4 100BASE-FX (SC-type) Ports EM4601-SX-SC: Media Module with 1 1000BASE-SX (SC-type) Port EM4582-LX-SC: Media Module with 1 1000BASE-LX (SC-type) Port ST5002: SC to ST Plug Converter for Fiber Optic Module (for 62.5/125 micron cable only) - Page 18 EM4582-LX-SC E102000-R01 150514-102...
