POSline MTS17 User Manual

Touchscreen monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MTS17 TOUCHSCREEN
MONITOR
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTS17 and is the answer not in the manual?

Questions and answers

Summary of Contents for POSline MTS17

  • Page 1 MTS17 TOUCHSCREEN MONITOR User’s Manual...

  • Page 2: Table Of Contents

    Chapter 7: OSD Controls Color Menu…………………………………………………….….. Page 10 Image Setting Menu…………………………………….…….. Page 11 Position………………………………………………………….…. Page 12 OSD Menu………………………………………………………….. Page 13 Language……………………………………………………………. Page 13 Misc……………………………………………………………………. Page 14 Exit…………………………………………………………………... Page 14 Appendix: LCD Monitor 17” Specification – MTS17………………..Page 15 - 1 –...

  • Page 3: Chapter 2: Safety Instructions

    Safety Instructions Never insert anything metallic into the cabinet openings of the LCD display. Doing so may create the danger of electric shock. To avoid electric shock, never touch the inside of the display. Only a qualified technician should open the case of the display Never use your display if the power cord has been damaged.
  • Page 4 Place the display on a solid surface and treat it carefully. The screen is made of thin glass with a plastic front surface and can be damaged if dropped, hit or scratched. Do not clean the front panel with keton-type materials (e.g., acetone), ethyl alcohol, toluene, ethyl acid, methyl, or chloride.

  • Page 5: Chapter 3: Unpacking Of Display

    ● Keep the package for future use after unpacking the display The following equipment is included with the product: Power Cord 15 pin D-SUB Signal Cable Software & Drivers CD Note: Fit the power cord and the 15 pin D-SUB Signal Cable into the back of your monitor and connect to the back of your PC.

  • Page 6: Chapter 4: Setup & Unload Of Base

    1. Base setup Attach the monitor to the base stand by pushing it down onto the elevated section (see image). Detach the monitor from the base stand by pushing the 2. Base unload PUSH button and simultaneously removing the monitor carefully from the base stand (see image).

  • Page 7: Chapter 5: Installing Vesa Compliant Mounting Attaching The Base

    1. Switch off your monitor and unplug its power cord. 2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the screen 3. Remove the four screws and remove the base from the LCD monitor. - 6 –...

  • Page 8: Removing The Base

    1. Screw the mounting bracket onto the back of the monitor. 2. Attach the LCD monitor to the wall by following the instructions in the wall-mounting kit. - 7 –...

  • Page 9: Chapter 6: Function Keys

    - 8 –...
  • Page 10 Functions Keys 1. OPEN the OSD Menu 2. SELECT the OPTIONS within the OSD Menu 1. MENU 3. RETURN to the MENU after adjusting the screen setting Select the PREVIOUS ITEM in the menu 2. ▽ DECREASE the LEVEL of adjustment Select the NEXT ITEM in the menu 3.

  • Page 11: Color Menu

    1. Color Menu: Contrast Adjust the level of contrast Brightness Adjust the level of brightness Color adjust Manual adjustment of the color temperature Color Temp Select a color temperature Back Return to the Main Menu * Select a color temperature manually after setting the Color Temp option to USER Select 9300 for a color temperature of 9300K (blue) Select 6500 for a color temperature of 6500K (transparent) Select 5500 for a color temperature of 5500K (red)

  • Page 12: Image Setting Menu

    2. Image Setting Menu: Clock Adjust the horizontal screen size Phase Optimize the display quality Sharpness Enhance the text quality while under the DOS operation Back Return to the Main Menu - 11 –...

  • Page 13: Position

    2. Position: H. Position Adjust the horizontal position of the screen V. Position Adjust the vertical position of the screen Back Return to the Main Menu - 12 –...

  • Page 14: Osd Menu

    3. OSD Menu: OSD H. Position Adjust the horizontal position of the OSD menu OSD V. Position Adjust the vertical position of the OSD menu Adjust the timing for the OSD menu to close OSD Timing automatically in idle state Back Return to the main menu 4.

  • Page 15: Misc

    5. Misc.: If available you can select the preferred input Signal Source source as listed. The optional input sources depend on your LCD display model. Automatically reset the screen setting to the Reset default setting. 6. Exit: Exit the OSD Menu manually - 14 –...

  • Page 16: Appendix: Lcd Monitor 17" Specification - Mts17

    Appendix – Technical Specifications (Datasheets) LCD Monitor 17” Specification – MTS17 Color active matrix TFT Panel Cell Type (Thin-Film-Transistor) LCD panel Aspect Ratio / Size 4 : 3 / 17" viewable diagonal area Glass Surface Black Anti-Glare, low reflection coating Pixel numbers / Colors 1280(H) x 1024(V) / 16.2 Million...
