Summary of Contents for Plantronics M55

  • Page 1 LEARN MORE M55™...

  • Page 2: Product View And Buttons

    TAKE A GOOD LOOK CALL BUTTON VOLUME BUTTON • Take a call (1 tap or say “Answer”) • Volume presets (1 tap per level change) • Reject a call (1-second press or say “Ignore”) INDICATOR LIGHT (LED) • Redial (2 taps) • Charging (solid red until charged) • Initiate phone’s voice-dialing • Very low battery (3 red flashes at powering on) (2-second press until tone is heard) • Pairing mode (repeating red/white flashes)

  • Page 3: Connect To Phone

    CONNECT TO YOUR PHONE PLT_M55 “Pairing” is the set-up process of 1. READY 3. CONNECT 2. SET introducing your headset to your phone. Before using your headset First Time, Right Out of the Box: Select “PLT_M55” from the list of Activate the Bluetooth feature for the first time, you must pair on your phone, then use phone Bluetooth devices shown on your Turn on the headset.

  • Page 4: Try It On

    TRY IT ON The loop of the gel eartip tucks into the back For Left Ear curve of your ear for a stable fit. Try on the headset. The eartip is positioned to suit most people, but you may want to rotate it to best fit your left or right ear.

  • Page 5: Tips

    TIPS Stay Near Your Phone With the headset powered on, simultaneously press the Call button and Volume button until Bluetooth has a working “range” of up to 33 you see the white LED flash twice. To reactivate feet between the phone and headset before the feature, just repeat the steps and you will audio degrades and the connection is lost.

  • Page 6: Specifications

    SPECIFICATIONS Talk Time Up to 11 hours Standby Time Up to 16 days DeepSleep Mode Up to 150 days Operating Distance (Range) Up to 33 feet (10 meters), Class II Headset Weight 8 grams Charge Connector Micro USB charging Battery Type Rechargeable non-replaceable lithium ion polymer Charge Time (Maximum) 2 hours for full Power Requirements 5V DC –...

  • Page 7: Need More Help

    1-866-363-2583. © 2012 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark of Bluetooth SIG, Inc. and any use by Plantronics is under license. All other trademarks Z302 are the property of their respective owners.
