- Page 1 GV6200 User’s Guide Rev.A _______________________________________________________________________ 2008 Vosonic Technology Corporation. All right reserved.
- Page 2 Part Number: 845550002001 Dear Customer Thank you for purchasing Vosonic GV6200. 1.Before using Vosonic GV6200, you will have to ---------------------------------------------------------------------- 1-1. Make sure the memory card has already partition or re-format again. 1-2. Check www.vosonic.com to download the update firmware that we offer new functions and improved features.
-
Page 3: Fcc Certifications
CAUTION Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty. Do not open the system as there is risk of electrical shock. FCC Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Important Warranty Information
To reduce the risk of fire or shock hazard, do not expose this equipment to rain, any liquid or moisture. Vosonic shall have no obligation to repair, replace or refund until the customer returns the defective product to Vosonic. The repairs and replacement service will not apply to... -
Page 5: Specifications
Specifications 1/3” color CMOS 1.3 Mega Pixel camera Camera 70 degree field of view for camera and motion detection Motion detected recording Recording mode Continuing recording Codec: MPEG-4 Format: MP4 Resolution: 640x480 Pixels Video Recording format Frame Rate: 20~30 fps * The frame rate is subject to the speed of memory card Secure Digital Card (SD) -
Page 6: Overview Of Panels & Keys
2. Overview of Panels & Keys Video-Out Jack Night Vision IR LED x 8 Error LED indicator Microphone Status LED indicator Battery Status Camera Angle Adjuster Hanging Rail 4-digit 7-segment display (Track) Indicator (Counter) SD card slot RESET DC Jack USB Port... - Page 7 keypad Function Description A short press places the recording into loop mode. Loop/Clear Continuous-loop recording Will disable to loop while recording A long press will clear all the recording files. ( Data written to memory card will be all lost) (See 5.4 ) Stop/Set A short press will stop the recording and put the unit...
-
Page 8: Timer Setting
3. Timer Setting 1. Plug the GV6200 power adapter into a working electrical outlet. 2. Long press the [ Enter / Time ] button for timer setting. 3. Set the value for the timer by using [ Loop/Clear ] button. -
Page 9: Led Indicators
Battery Unlit Full charged Charging… Note: The GV6200 includes one Li-ion battery, this is to ensure no critical shot is ever missed during 1 hour power cut. To completely shut down the unit, you can press [reset ] button. -
Page 10: How To Configure Motion Detection
2. Plug the GV6200 power adapter into a working electrical outlet. Aim the motion detector at the field of view you want covered. 3. Insert the SD card into the SD card slot. -
Page 11: Camera Head
Camera Head : The camera head can be adjusted up and down max. 35 degree... -
Page 12: Assembling The Bracket
6. Assembling the bracket Assemble the bracket and fix it to the optional stand as shown. Use the screws provided to fix the optional stand (mounting bracket) to a wall The optional stand can be adjusted to allow camera a 95 of rotation and a pan and tilt action. -
Page 13: Usb Connection
7. USB connection Connect the GV6200 and PC with the provided USB cable Double Click the " My computer" icon , the operating system will display GV6200 as removable disk . You can then read ,write,copy ,delete and remove data on the... - Page 14 *Do not use USB ports repeated through peripherals (such as keyboards) or with un-powered USB hubs. Note: For Windows XP users, to safely disconnect the GV6200 from computer, click on the system tray remove icon and wait until you get a message saying that you can safely unplug the device before disconnecting the USB cable.
-
Page 15: General Information
In the dark areas, use another source of light that enhances images to enable the GV6200 to detect objects and improves the detection. The resolution may change in the direction from center towards the perimeter of the field of view. This is an inherent feature of the image tube type utilized in the device. - Page 16 To keep your SD card in better operating performance , we recommend to periodically run Scan Disk and Disk Defragmenter . NOTE : If the SD card already contain data, please backup the data first, because when you partition and format a SD card , all the data on the partition is permanently deleted Please carefully insert and remove the memory card from slot .
- Page 17 1) Error Code : The error detection method may include producing a warning sound and displaying an error message on the 4-digital 7-segment display indicator. : SD Card Lock : SD Card Error : CMOS (camera) Error 2) If any shut down caused by erroneous operation, you can depress the [ reset] button located on the bottom to switch off the main unit .
-
Page 18: Troubleshooting
Front USB ports are often from non-powered. If you can not find the GV6200 show up in Windows for over one minute, the Files Allocation Table (FAT) of SD card may gets corrupted. Please find other card reader to reformat the memory card but not all data on the card will be erased. -
Page 19: Frequently Asked Questions
Lower frame rate than It may be caused by e.g kind of SD card expected. and its manufacturer. Faulty power adapter Check you are using GV6200 power adapter Image too dark or too Camera incorrectly configured on your light workstation... - Page 20 • VISIT VOSONIC ON THE WEB Go to http://www.vosonic.com to download the latest firmware The latest version of this manual may be available on Vosonic's Web site • CONTACT VOSONIC To process a request for Technical Service, please mail the following information to service@vosonic.com.tw...
- Page 21 THANK YOU FOR CHOOSING THIS PRODUCT We hope it will provide you with years of trouble-free enjoyment. Please look after your Vosonic. If you experience problems and cannot find solutions in the previous sections, please contact your dealer or check for updated firmware at www.vosonic.com...
