Page 1: Quick Start Guide
Quick Start Guide Digital Research Technologies Inc. 4 Marconi, Irvine, CA 92618 For: DLCD26, DLCD32, DLCD42 & DLCD42P LCD Televisions... - Page 2 Distance recommendations: Always position the LCD TV set where sufficient ventilation is available. When installing this LCD TV set, distance recommendations must be maintained between the set and the wall, as well as inside a tightly enclosed area or piece of furniture. Refer to the minimum distance guidelines shown below for a safe operation.
-
Page 3: Inputs And Outputs
Inputs and Outputs Your LCD TV has five types of video connections. Use the Cables best connection available for your LCD TV to get the best 1.RCA composite video cable display quality. For example, if you have a progressive 2. S-video cable DVD player that supports a component video connection, 3. -
Page 4: Connecting The Antenna Or Analog Cable Tv (Catv)
Connecting the Antenna or Analog Cable TV (CATV): Disconnect the TV from all power sources before making any connections. Use the coaxial cable (75 ohms) for connecting TV signal from your antenna or cable TV provider to the tuner input. 3. - Page 5 Connecting Digital Set-Top Boxes (Commonly Used For HDTVs, Satellite TVs, etc.): Disconnect the TV and set-top box from all power sources before making any connections. Use a HDMI cable, component video cable, or S-video cable to connect the HDMI, COMPONENT, or S-VIDEO output jacks of your digital set-top box to the HDMI, COMPONENT, or S-VIDEO input jacks in the back of the LCD TV.
-
Page 6: Connecting S-Video Or Composite Video
Connecting S-Video or Composite Video: This section shows you how to connect devices to the S-video and composite video inputs of your LCD TV. Most devices like VCRs, camcorders, non-progressive scan DVD players, etc. only provide composite video output or S-video output. The steps below are to show you how to connect two devices simultaneously. -
Page 7: Connecting Hdmi
Connecting To a PC: If you wish to connect a PC to the LCD TV, connect the 15-pin D sub RGB connector on your PC to the PC connector on the back of the LCD TV. Connect the audio output on your PC to the PC audio input on the back of the LCD Connecting HDMI: Use a HDMI cable to connect the HDMI output jack of your external device to the HDMI input jack in the back of the LCD TV. -
Page 8: Tv Control Functions
TV Control Functions TV Control Functions Button Button (profile) MENU SOURCE –VOL+ -CH+ POWER The LED indicator lights up in 2 different colors green or red. LED Indicators Each color represent a different status. Green - Power is on; Red - Standby. POWER Press this button to turn the power to on or standby. -
Page 9: Remote Control Functions
Remote Control Functions The table below explains each button’s function. POWER Power on/off. Press to display information about the INFO current input source. Opens the program guide & shows all active channels. (For digital channels only). Choose from widescreen, NORMAL, ASPECT CINEMA, ZOOM. - Page 10 Phone: (949) 707-4888 (M-F 8:00AM – 5:00PM PST) • Internet: http://www.dr-tech.com (Go to the technical support section and fill out support form.) Digital Research Technologies Inc. 4 Marconi, Irvine, CA 92618 Register Your New Product For your convenience, you may fill out a product warranty registration card online at www.registeryourproduct.com.
