ViewSonic
High-Definition Video Processor
• Picture-in-picture viewing
When connected to a PC you can view a video or TV
window over your data screen.
• Closed caption technology*
Displays text overlay of spoken audio over video.
• SAP/MTS stereo*
Allows the reception of audio other than main
programming audio.

• Parental control*

Built-in V chip allows controlled programming based
on a selected rating system.
• RGB computer pass-through
Watch TV or enjoy your DVD movie without turning
on your computer.
• Auto tuning
Auto tuning of TV broadcast and cable TV channels.
• Multiple channel viewing
Multiview supports 9 individual TV channel windows
with 1 active window.

• Sleep timer

Built-in sleep timer automatically shuts off display at
pre-determined times.
• Easy connection and control
The NextVision N6 is an external plug-and-play table-
top configuration requiring no software drivers or
internal computer installation.
• Convenient 28-key remote control
381 Brea Canyon Road, Walnut, CA 91789 • Phone (800) 888-8583 or (909) 444-8888 • Fax (909) 839-7922 • SalesInfo@ViewSonic.com • ViewSonic.com
* Closed Caption, SAP/MTS and parental control may not be available in all regions. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete
details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2002 ViewSonic Corporation. All rights reserved. [10625-00B-06/02] N6-1
®
NextVision
HIGH-DEFINITION VIDEO PROCESSOR WITH COMPONENT VIDEO INPUTS AND TV TUNER
ANTENNA/CABLE (RF) Tuner
Freq Range
Numbers of Channels 2–69 off air
INPUT SIGNAL Type
TV/Video Compatibility 480i, 480p, 576p, 720p, 1080i
VIDEO OUTPUT Bit Performance 24-bit RGB 700mV±10% (excluding RGB pass-through)
OUTPUT MODE Resolution
(excluding RGB Refresh rate
pass-through)
(Integrated or
progressive scan)
AUDIO OUTPUT MTS*
POWER Input
Output
Type
CONNECTOR Signal
Power
CONTROLS Basic
OnView ®
Remote Control 28-key IR remote control. Power, volume +/-, channel +/-,
OPERATING Temperature
CONDITIONS Humidity
Altitude
REGULATIONS
ACCESSORIES Included
ViewSonic Corporation's QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
FI1236MK2 (North America)
55.25–801.25 MHz
2–125 NTSC cable
RF, S-video, composite (RCA), component (YPbPr) RGB
pass-through
3.5mm mini stereo audio in, and RCA (left/right) audio in
640x480 @ 60Hz/75Hz 1280x720 @ 60Hz
800x600 @ 60Hz/75Hz 1280x768 @ 60Hz
852x480 @ 60Hz 1280x1024 @ 60Hz
1024x768 @ 60Hz/75Hz
Mono/stereo/SAP (available in RF mode)
Universal 90–264V AC, 47–63Hz
12V DC, 1.5 A
Power adapter
F connector for RF, 3.5mm mini stereo jack for audio in and
audio out. RCA left/right for audio in, component video,
(YPbPr), S-video and composite input (RCA), 15-pin mini
D-sub for RGB input and RGB output, front headphone 3.5mm
DC-in jack
Power, input, channel +/- and volume +/-
Contrast, brightness, saturation, sharpness, hue, MTS, treble,
bass, balance, audio source selection, OSD position, OSD
language (English, Spanish, French, traditional Chinese),
resolution, refresh rate, input signal, tuner input (antenna,
CATV std, CATV HRC, CATV IRC), sleep, autoscan, channel
add/remove, channel label, parental control (rating selection
and password), CC and text 1&2 and system info.
four navigation arrows, select, menu, enter, freeze, mute,
input, POP (multi-view), PIP, recall, 10 numbering keys.
0–40° C (32–104° F)
5–95%, non-condensing
-150–12,000 feet above sea level
UL, cUL, FCC Class B
Power adapter, VGA extension cable, 3.5mm mini stereo
cable, A/V cable, user's guide, remote, batteries and stand
included.
ViewSonic recommends any of it's
UltraBrite ™ displays be used with
the NextVision N6 for the ultimate
entertainment and computing experience.
™ N6
