Summary of Contents for Gigabyte GA-B75M-D3P

  • Page 1 Инструкция GigaByte GA-B75M-D3P rev. 1.0 Перейти в карточку товара 8 800 775 98 98...
  • Page 2 GA-B75M-D3P User's Manual Rev. 1002 12ME-B75MD3P-1002R...
  • Page 3 G.B.T. Technology Trading GMbH Address: Bullenkoppel 16, 22047 Hamburg, Germany Declare that the product Product Type: Motherboard Product Name: GA-B75M-D3P conforms with the essential requirements of the following directives: 2004/108/EC EMC Directive: Conduction & Radiated Emissions: EN55022:2006+A1:2007 Immunity: EN55024:1998+A1:2001+A2:2003 Power-line harmonics:...

  • Page 4: Identifying Motherboard Revision

    Copyright © 2012 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved. The trademarks mentioned in this manual are legally registered to their respective owners. Disclaimer Information in this manual is protected by copyright laws and is the property of GIGABYTE. without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.

  • Page 5: Table Of Contents

    Table of Contents GA-B75M-D3P Motherboard Layout ................5 GA-B75M-D3P Motherboard Block Diagram ..............6 Chapter 1 Hardware Installation ..................7 Installation Precautions ..................7 ..................8 Installing the CPU ..................11 Installing the Memory ..................12 Installing an Expansion Card ................. 12 Back Panel Connectors .................. 13 Internal Connectors ..................

  • Page 6: Ga-B75M-D3P Motherboard Layout

    GA-B75M-D3P Motherboard Layout KB_MS_USB ATX_12V LGA1155 DP_HDMI_SPDIF R_USB30 SYS_FAN USB_LAN CPU_FAN F_USB30 AUDIO GA-B75M-D3P PCIEX16 B_BIOS PCIEX1 Realtek M_BIOS GbE LAN TPM IC Intel ® SATA3 SATA2 PCIEX4 CODEC Marvell 88SE9172 F_AUDIO F_USB2 F_USB1 CLR_CMOS F_PANEL COMA COMB GSATA3 7 6...

  • Page 7: Ga-B75M-D3P Motherboard Block Diagram

    GA-B75M-D3P Motherboard Block Diagram 1 PCI Express x16 LGA1155 PCIe CLK Dual Channel Memory PCI Express Bus 2 SATA 6Gb/s DVI-D Dual BIOS D-Sub 1 SATA 6Gb/s Marvell HDMI 88SE9172 DisplayPort 5 SATA 3Gb/s Intel PCI Express Bus ® 8 USB 2.0/1.1...

  • Page 8: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become manual and follow these procedures: Prior to installation, make sure the chassis is suitable for the motherboard. warranty sticker provided by your dealer. These stickers are required for warranty validation. Always remove the AC power by unplugging the power cord from the power outlet before installing or removing the motherboard or other hardware components.
  • Page 9 Support for Intel ® Core ™ i7 processors/Intel ® Core ™ i5 processors/ Intel ® Core ™ i3 processors/Intel ® Pentium ® processors/Intel ® Celeron ® processors in the LGA1155 package L3 cache varies with CPU Chipset Intel ® B75 Express Chipset Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical...
  • Page 10 Storage Interface Chipset: devices Marvell 88SE9172 chip: devices Support for RAID 0 and RAID 1 Chipset: * In Windows XP, the Intel USB 3.0 ports can support up to USB 2.0 transfer speed. Internal 1 x 24-pin ATX main power connector Connectors 1 x 4-pin ATX 12V power connector 3 x SATA 6Gb/s connectors...
  • Page 11 Hardware System voltage detection Monitor CPU/System temperature detection CPU/System fan speed detection CPU overheating warning CPU/System fan fail warning CPU/System fan speed control * Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install. BIOS Use of licensed AMI EFI BIOS Support for DualBIOS...

  • Page 12: Installing The Cpu

    Installing the CPU Read the following guidelines before you begin to install the CPU: Make sure that the motherboard supports the CPU. Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage. Apply an even and thin layer of thermal grease on the surface of the CPU.

  • Page 13: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.

  • Page 14: Back Panel Connectors

    Back Panel Connectors USB 2.0/1.1 Port PS/2 Keyboard/Mouse Port Use this port to connect a PS/2 mouse or keyboard. D-Sub Port The D-Sub port supports a 15-pin D-Sub connector. Connect a monitor that supports D-Sub connection to this port. DVI-D Port (Note) DVI-D connection to this port.
  • Page 15 DisplayPort DisplayPort is one of the new generation interface technologies that delivers high quality digital imaging and audio, supporting bi-directional audio transmition. DisplayPort can support both DPCP and HDCP content protection mechanisms. Connect the audio/video device that supports DisplayPort to this port. The DisplayPort Technology can support a maximum resolution of 2560x1600 but the actual resolutions supported depend on the monitor being used.

  • Page 16: Internal Connectors

    Internal Connectors ATX_12V CLR_CMOS F_PANEL CPU_FAN F_AUDIO SYS_FAN SPDIF_O F_USB30 SATA3 0 F_USB1/F_USB2 SATA2 1/2/3/4/5 COMA/COMB GSATA3 6/7 Read the following guidelines before connecting external devices: First make sure your devices are compliant with the connectors you wish to connect. Before installing the devices, be sure to turn off the devices and your computer.
  • Page 17 1/2) ATX_12V/ATX (2x2 12V Power Connector and 2x12 Main Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components off and all devices are properly installed. The power connector possesses a foolproof design. Connect the power supply cable to the power connector in the correct orientation.
  • Page 18 3/4) CPU_FAN/SYS_FAN (Fan Headers) All fan headers on this motherboard are 4-pin. Most fan headers possess a foolproof insertion design. optimum heat dissipation, it is recommended that a system fan be installed inside the chassis. CPU_FAN/SYS_FAN: Pin No. +12V SYS_FAN Sense Speed Control CPU_FAN...
  • Page 19 6) SATA3 0 (SATA 6Gb/s Connector, Controlled by Intel B75 Chipset) The SATA connector conforms to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA 1.5Gb/s standard. Each SATA connector supports a single SATA device. Pin No. SATA3 7) SATA2 1/2/3/4/5 (SATA 3Gb/s Connectors, Controlled by Intel B75 Chipset) The SATA connectors conform to SATA 3Gb/s standard and are compatible with SATA 1.5Gb/s standard.
  • Page 20 8) GSATA3 6/7 (SATA 6Gb/s Connectors, Controlled by Marvell 88SE9172 Chip) The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA 1.5Gb/s standard. Each SATA connector supports a single SATA device. The Marvell 88SE9172 chip Pin No.
  • Page 21 10) F_PANEL (Front Panel Header) Connect the power switch, reset switch, speaker, chassis intrusion switch/sensor and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables. Message/Power/ Power Sleep LED...
  • Page 22 11) F_AUDIO (Front Panel Audio Header) your chassis front panel audio module to this header. Make sure the wire assignments of the module connector match the pin assignments of the motherboard header. Incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it. For HD Front Panel Audio: For AC'97 Front Panel Audio: Pin No.
  • Page 23 13) F_USB30 (USB 3.0/2.0 Header) Pin No. Pin No. VBUS SSRX1- SSRX1+ SSTX2+ SSTX1- SSTX2- SSTX1+ SSRX2+ SSRX2- VBUS No Pin 14) F_USB1/F_USB2 (USB 2.0/1.1 Headers) optional USB bracket. For purchasing the optional USB bracket, please contact the local dealer. Pin No.
  • Page 24 15) COMA/COMB (Serial Port Headers) The COM header can provide one serial port via an optional COM port cable. For purchasing the optional COM port cable, please contact the local dealer. Pin No. NDCD- NSIN NSOUT NDTR- NDSR- NRTS- NCTS- NRI- No Pin 16) LPT (Parallel Port Header)

  • Page 25: Chapter 2 Bios Setup

    Chapter 2 BIOS Setup saving system parameters and loading operating system, etc. BIOS includes a BIOS Setup program that allows When the power is turned off, the battery on the motherboard supplies the necessary power to the CMOS to To access the BIOS Setup program, press the <Delete> key during the POST when the power is turned on. To upgrade the BIOS, use either the GIGABYTE Q-Flash or @BIOS utility.

  • Page 26: The Main Menu

    The Main Menu On the main menu of the BIOS Setup program, press arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. Or you can use your mouse to select the item you want. (Sample BIOS Version: F1f) Setup Menus Help...

  • Page 27: M.i.t

    M.I.T. Whether the system will work stably with the overclock/overvoltage settings you made is dependent to CPU, chipset, or memory and reduce the useful life of these components. This page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or This section provides information on the BIOS version, CPU base clock, CPU frequency, memory frequency, - 26 -...
  • Page 28 M.I.T. Current Status This screen provides information on CPU/memory frequencies/parameters. Advanced Frequency Settings Processor Graphics Clock CPU Clock Ratio Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the CPU being installed. CPU Frequency Displays the current operating CPU frequency.
  • Page 29 CPU Clock Ratio, CPU Frequency The settings under the two items above are synchronous to those under the same items on the Advanced Frequency Settings menu. Intel(R) Turbo Boost Technology (Note) Allows you to determine whether to enable the Intel CPU Turbo Boost technology. Auto lets the BIOS Turbo Ratio (1-Core Active~4-Core Active) (Note) Allows you to set the CPU Turbo ratios for different number of active cores.
  • Page 30 (Note) enabled. System Memory Multiplier Allows you to set the system memory multiplier. Auto sets memory multiplier according to memory SPD Memory Frequency (MHz) Displays the value of memory frequency which is automatically adjusted according to the System Memory Multiplier settings. Advanced Memory Settings (Note) , System Memory Multiplier (SPD), Memory...
  • Page 31 When using a non-XMP memory module or is set to Disabled, this item will display as 1.50V. When is set to , this item will display the value based on the SPD data on the XMP memory. The value displayed here is dependent on the CPU being used. Channel Interleaving Enables or disables memory channel interleaving.
  • Page 32 PC Health Status Reset Case Open Status Enabled Clears the record of previous chassis intrusion status and the Case Open Case Open Displays the detection status of the chassis intrusion detection device attached to the motherboard CI clear the chassis intrusion status record, set Reset Case Open Status to Enabled, save the settings to the CMOS, and then restart your system.

  • Page 33: System

    Manual Allows you to control the CPU fan speed under the Slope PWM item. Disabled Allows the CPU fan to run at full speeds. Slope PWM CPU Fan Speed Control is set to Manual. Options are: 0.75 PWM value / 1st System Fan Speed Control Allows you to determine whether to enable the system fan speed control function and adjust the fan speed.

  • Page 34: Bios Features

    System Time Sets the system time. The time format is hour, minute, and second. For example, 1 p.m. is 13:0:0. Use desired value. Access Level BIOS settings; the User level only allows you to make changes to certain BIOS settings but not all. ATA Port Information This section provides information on the device connected to each SATA port controlled by Intel B75 Chipset.

  • Page 35: Administrator Password

    Bootup NumLock State Full Screen LOGO Show Allows you to determine whether to display the GIGABYTE Logo at system startup. Disabled skips the PCI ROM Priority Allows you to determine which Option ROM to launch. Options are Legacy ROM and EFI Compatible ROM. Limit CPUID Maximum (Note) Allows you to determine whether to limit CPUID maximum value.

  • Page 36: Peripherals

    Peripherals LAN PXE Boot Option ROM SATA Controller(s) (Intel B75 Chipset) SATA Mode Selection (Intel B75 Chipset) - 35 -...

  • Page 37: Audio Controller

    Serial ATA features such as Native Command Queuing and hot plug. xHCI Pre-Boot Driver Disabled The USB 3.0 ports are routed to the EHCI controller before booting to OS. When this item is set to Enabled, the xHCI Mode below will be automatically set to Smart Auto; when this item is set to Disabled, the xHCI Mode below will be automatically set to Auto.
  • Page 38 Init Display First Specifes the frst initiation of the monitor display from the installed PCI graphics card, PCI Express graphics card, or the onboard graphics. Internal Graphics Internal Graphics Memory Size DVMT Total Memory Size Intel(R) Rapid Start Technology Legacy USB Support XHCI Hand-off Determines whether to enable XHCI Hand-off feature for an operating system without XHCI Hand-off EHCI Hand-off...
  • Page 39 When set to Enabled, the following two items will appear. PLDM for SMBIOS parallel port. Serial Port A/B Parallel Port Intel(R) Smart Connect Technology GSATA Controller (Marvell 88SE9172 Chip, GSATA3 6 and GSATA3 7 connectors) the SATA controllers to AHCI mode. The area below displays the current status of the two SATA ports. Serial ATA features such as Native Command Queuing and hot plug.
  • Page 40 Serial Port Console Redirection Console Redirection This section allows you to enable/disable serial port console redirection for remote server management Console Redirection Settings - 39 -...

  • Page 41: Power Management

    Power Management AC BACK Determines the state of the system after the return of power from an AC power loss. Memory The system returns to its last known awake state upon the return of the AC power. Always On The system is turned on upon the return of the AC power. Power On By Keyboard Allows the system to be turned on by a PS/2 keyboard wake-up event.

  • Page 42: Save & Exit

    Soft-Off by PWR-BTTN Delay 4 Sec Press and hold the power button for 4 seconds to turn off the system. If the power button is pressed for less than 4 seconds, the system will enter suspend mode. Internal Graphics Standby Mode Allows you to determine whether to let the onboard graphics enter standby mode to decrease power Internal Graphics Deep Standby Mode Save &...

  • Page 43: Chapter 3 Drivers Installation

    If your system becomes unstable and you have loaded the BIOS default settings, you can use this function Chapter 3 Drivers Installation After installing the operating system, insert the motherboard driver disk into your optical drive. The driver Autorun screen is automatically displayed which looks like that shown in the screen shot that are recommended to install.

  • Page 44: Chapter 4 Appendix

    Chapter 4 Appendix Before you begin Windows 7/XP setup disk. Motherboard driver disk. A. Installing SATA hard drive(s) in your computer Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available SATA port on the motherboard.
  • Page 45 b. Stripe Size: c. Quick Init: Select whether to quickly erase old data on the hard drives when creating the array. d. Cache Mode: Select write-back or write-through cache. e. VD Name: 3. After completing the settings above, move to NEXT and press <Enter> to begin creating the array. When 4.

  • Page 46: Regulatory Statements

    Regulatory Statements Regulatory Notices This document must not be copied without our written permission, and the contents there of must not be imparted Contravention will be prosecuted. We believe that the information contained herein was accurate in all respects at the time of printing. GIGABYTE cannot, however, assume any responsibility for errors or omissions in this text. Also note that the information in this document is subject to change without notice and should not be construed as a commitment by GIGABYTE.
  • Page 47 - 46 -...
  • Page 48 - 47 -...
  • Page 49 Contact Us GIGA-BYTE TECHNOLOGY CO., LTD. Address: No.6, Bao Chiang Road, Hsin-Tien Dist., New Taipei City 231,Taiwan TEL: +886-2-8912-4000, FAX: +886-2-8912-4003 You may go to the GIGABYTE website, select your language in the language list on the top right corner of the website. GIGABYTE Global Service System question, please link to: http://ggts.gigabyte.com.tw Then select your language to enter the system.
