Projectiondesign WB2560 User Manual

Multi image processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

an introduction to the processors,
an introduction to the processors,
use and set up
use and set up
user's guide
user's guide
Designed and manufactured in Fredrikstad, Norway.
www.projectiondesign.com
Multi
Multi
Processing
Processing
System
System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WB2560 and is the answer not in the manual?

Questions and answers

Summary of Contents for Projectiondesign WB2560

  • Page 1 an introduction to the processors, an introduction to the processors, use and set up use and set up user’s guide user’s guide Multi Multi Image Image Processing Processing System System Designed and manufactured in Fredrikstad, Norway. www.projectiondesign.com...
  • Page 2 Multi image processor User’s Guide – Introduction...

  • Page 3: Thank You

    • Project onto any surface • Zero, or near zero latency, depending on set up and configuration • 3D stereo compatible, up to 1920x1200 on WB2560, and 1280x800 on WB1920 • Patented Black Level Matching for uniform black levels • Per-pixel Colour-, Uniformity-, and brightness matching • 12-bit internal resolution...

  • Page 4: Table Of Contents

    Contents of this User’s Guide Introduction 1.1 Thank you 1.1 Features SAFETY 2.1 GENERAL WARNINGS 2.2 WEEE INFORMATION 2.3 WARNING ABOUT SUBSTANCES 2.3.1 WARNING SYMBOLS What’s in the box? 3.1 The multi image processing system comes with the following: Installation and setup 4.1 System requirements 4.2 System overview 4.3 Connectors...
  • Page 5 5.4 Multi image processing operational states 5.4.1 Bypass states 5.4.2 Calibration state 5.4.3 Online state 5.4.4 Auto state Geometry correction 6.1 Warping algorithms 6.1.1 Perspective 6.1.2 Mesh Warp Transform 6.1.3 Mesh Warp Bezier 6.2 Warping user interface 6.3 Scaling filters 6.3.1 Lanczos filter 6.3.2...
  • Page 6 Black Level Management 9.1 Creating adjustment zones 9.2 Removing BLM zones 9.3 Adjusting black level in a defined zone Masking 10.1 Adding areas to clip 10.2 Removing clip areas Storing and recalling data 11.1 Storing/recalling calibration to/from the multi image processor unit 11.2 Storing/recalling data to/from the control PC 11.2.1 Restoring calbration files...

  • Page 7: General Warnings

    2 SAFETY This device complies with safety regulations for Information Technology Equipment intended to operate in “normal” environments (offices and homes). Before using the device for the first time, please read the safety instructions thoroughly. 2.1 GENERAL WARNINGS Use only the cables and cords supplied with the device or original replacement cables. Using other cables or cords may lead to malfunction and permanent damage of the device.

  • Page 8: Warning About Substances

    2.1 WARNING ABOUT SUBSTANCES This product contains chemicals, including lead, known to the State of California to cause birth defects or other reproductive harm. Recycle properly, do not dispose of in ordinary waste!. 2.1.1 WARNING SYMBOLS READ USER GUIDE Attention! Read the user guide for further information! RECYCLE Warning! Recycle properly, do not dispose of in ordinary waste! NO TELEPHONE Warning! Do not connect to telephone lines! Multi image processor User’s Guide –...

  • Page 9: What's In The Box

    3 What’s in the box? 3.1 The multi image processing system comes with the following: Multi image processing system unit Power Cable (Country Dependant) 2x Dual Link DVI cables CD with software Network cable User Documentation Please verify that you have all compoents upon unpacking the unit, and its contents. Please save packaging materials for future use, should it be necessary to ship the unit.
  • Page 10 Multi image processor User’s Guide - What’s in the Box?

  • Page 11: System Requirements

    4 Installation and setup The following section outlines the general requirements to supporting equipment in order to run the ProNet Calibrator and successfully setting up a multi image based projection system. 4.1 System requirements ProNet 2.0 – required to set up and operate multi image processing system processors, works with Microsoft Windows®...

  • Page 12: System Overview

    4.2 System overview A multi image processing system contains the following main components: • An Image Generator (IG) with one or more channels (outputs) (not provided by projectiondesign). • One multi image unit per channel • One projector per channel • A PC for setup and control • Optional CAD tool for designing systems (not provided by projectiondesign) Figure 4-1 shows a complete system overview of a multi image processing setup.

  • Page 13: Network Settings

    4.4 LED indicators / Front button The front button and the Power and Status LED-indicators on the processor front panel have the following functions: Front button: Power LED: Status LED: Show info on screen Push 1 time: BLUE: ON GREEN: ON (visual ID/IP/present serial no.) BLUE: Blinking GREEN: Blinking...

  • Page 14: Firewall Settings

    4.6 Firewall settings The multi image processing system processor communicates extensively on the network. In order for it to communicate freely with the ProNet application, the following ports must be open in the firewall: • 22 outbound (SSH) • 1900 inbound (UPnP open for AutoDiscovery of multi image processing system processors) • 30000 outbound (dedicated multi image processing instruction command set) • 40400 outbound (dedicated ASCII command set)

  • Page 15: Getting To Know The Gui

    5 Getting to know the GUI 5.1 ProNet.site Figure 5-1 gives an overview of ProNet.site. The application has four main areas of interest: • The File menu located in the top-left corner. • The “Site Devices” overview on the left hand side of the GUI. • Control, status, monitoring and timed operations overviews for one or more selected devices on the right hand side.

  • Page 16: Wb Calibrator – Device View

    5.2 WB Calibrator – Device View Figure 5-1 shows the “Device View” window that is displayed when the “WB Calibrator” plugin is started. The “Device View” window contains the following areas: • The File menu located in the top-left corner • The Device Pool window in the lower left corner.

  • Page 17: Adding Multi Image Processing System Units To A Project

    Figure 5-1. File menu, Device View. 5.2.3 Adding multi image processing system units to a project To enable and add multi image processing system units to a project, simply drag and drop units from the tree view in the Device Pool (Figure 5-1) to the Device View Desktop. The multi image processing system units in the Device Pool are detected using ProNet’s built-in universal plug-n-play capability.

  • Page 18: Using The Device View Toolbar, Dvt

    5.2.4 Using the Device View Toolbar, DVT The Device View Desktop window has a toolbar on the left hand side, known as the Device View Toolbar. The toolbar can be shown with or without help texts, see Figure 5-1. Figure 5-1. Toolbars, shown with and without help texts. Using the toolbar you can: • Add or remove multi image processing system units from a project.

  • Page 19: Clearing Calibration

    5.2.5 Clearing calibration To clear calibration from selected multi image processing system units, select Edit > Clear Calibration from the File menu. Under Clear Calibration, one can select to clear all or just parts of the calibration. See Figure 5-1. Figure 5-1.

  • Page 20: Controlling Edid Information

    The software update process is complete when the power status LED on the unit is showing a steady blue light. Figure 5-1. Multi image processing software upgrade window. 5.2.8 Controlling EDID information The unit defaults to giving the image generator either WUXGA or WQXGA EDID data depending on the version of the multi image processing system unit that is in use.

  • Page 21: Wb Calibrator – Calibration View

    5.3 WB calibrator – Calibration View When all multi image processing system units are added to the project in the Device View, switch WB Calibrator to “Calibration View”. This is done by clicking the “Calibration View” button in the top-left corner. Clicking the same button in Calibration View mode will bring you back to Device View.

  • Page 22: Selecting/Deselecting Multi Image Processing System Units

    5.3.2 Selecting/deselecting multi image processing system units The WB Navigator is a window used to select multi image processing system units in a project, Figure 5-12. In this window, WB units can be selected or deselected either by clicking on them or using the assigned short cut key combination. Figure 5-1.

  • Page 23: Using The Calibration Panel Toolbar (Cpt)

    5.3.3 Using the Calibration Panel Toolbar (CPT) The calibration panel has a set of tools on the left hand side of the window. This toolbar can be shown with or without help texts, “Figure 5-1. Calibration Panel Toolbar, without and with help texts.”...
  • Page 24 The Calibration Panel Toolbar has these main functions: • Zoom. Scale the work area in the calibration panel. • Image Orientation. Change the orientation of the calibration panel to match the physical orientation of the projector (e.g. rear/ceiling or portrait). • Set Colors.

  • Page 25: Multi Image Processing Operational States

    • Show info labels. Show extra info for selected control point. • Bezier Fixed Length/Angle. Specify the bezier guide point behaviour. Off allow adjust- ment of both length and angle. Fixed length allows the user to change angle, but not the length.
  • Page 26 Multi image processor User’s Guide – Getting to know the GUI...

  • Page 27: Warping Algorithms

    6 Geometry correction Image Geometry Correction (often referred to as Image Warping) is the process of digitally manipulating image data so that the image’s projection precisely matches a specific projection surface or shape. Image Geometry Correction compensates for the distortion created by off-axis projection or screen placement or non-flat screen surfaces by applying a compensating inverse distortion to the image in the digital domain.

  • Page 28: Warping User Interface

    6.2 Warping user interface To apply warping to an image, select “Warp” from the left hand toolbar. The window in Figure 6-1 will appear. Figure 6-1. Warping algorithm setup Algorithms can be added or removed. If the perspective transform is added first, Mesh Warp Transform can be used in addition.

  • Page 29: Scaling Filters

    6.3 Scaling filters Regardless of the warping algorithms selected, a scaling filter will be applied. Scaling filters are configured using the Algorithm Setup window. Select the tab “Filter”, Figure 6-2, and select your desired filter. Four different scaling filters are supported: • Lanczos, B-spline, C-spline, Linear Figure 6-2.

  • Page 30: Working With The Perspective Algorithm

    6.4 Working with the perspective algorithm To start working with the perspective algorithm, click the “Warp” icon, add the perspective algorithm and set grid size to 1x1. In order to map the geometry to the surface being projected on, drag the control points with the mouse. Figure 6-3 shows basic usage of the Perspective algorithm.

  • Page 31: Working With The Mesh Transform Algorithm

    6.5 Working with the Mesh Transform algorithm To start working with Mesh Transform algorithm, click the “Warp” icon, add the Mesh Transform algorithm and start with setting the grid size to 1x1. First map the four corners to their desired location. As required, increase the grid size. This will add more rows, columns and control points to the mesh and enable the possibility to map the grid correctly onto the surface.

  • Page 32: Working With Mesh Bezier Algorithm

    6.6 Working with Mesh Bezier algorithm To start working with Mesh Bezier algorithm, click the “Warp” icon, add the Mesh Bezier algorithm and start with setting the grid size to 1x1. The grid you see now will contain four control points – one in each corner. In addition all control point will have 2-4 additional, white control points for controlling the Bezier vectors in a given point, Figure 6-5.

  • Page 33: Fine Tuning Control Points

    Figure 6-6. Working with Mesh Bezier, simple mapping 6.7 Fine tuning control points To fine tune the position of a warping control point, first click on the control point. Then press and hold Ctrl while using the arrow keys on the keyboard to move the control point.
  • Page 34 When Real Time Warp is On, only the active control point will be added to the image from the IG if Show active is selected. Show active can be enabled in the Calibration Panel Toolbar see Figure 6-8. Figure 6-8. Calibration panel guide points NOTE! When working on a warp in Real Time mode, the displayed, warped image will be generated using a linear approximation.

  • Page 35: Edge Blending Algorithms

    7 Edge blending 7.1 Introduction Edge Blending is a companion feature to Image Geometry Correction. Edge Blending ena- bles the seamless projection of a large image using several overlapping projectors. Since geometry correction for projection on non-flat surfaces is a built-in requirement in almost all Edge Blending systems, the pairing of Edge Blending and Image Geometry Correction in the same video signal processor is a natural one.
  • Page 36 Figure 7-1. Basic edge blending. In the Basic Blend setup window, overlapping pixels (or percent) can be specified. The blend drop-off curve of can also be tuned. Tuning the blend drop off curve is also possible when the unit is in Online state, for a visual fine tuning of the curve. Multi image processor User’s Guide –...

  • Page 37: User Interface For Advanced Edge Blending

    7.2.4 User interface for advanced edge blending To apply advanced edge blending to an image, select “Blend” from the actions toolbar, and select Advanced Blend Setup. All blend zones will now have to be added manually. Click “Add zone” and select a default location for the blend zone, see Figure 7-2. Figure 7-2.

  • Page 38: Adjusting The Shape Of Advanced Edge Blending Zones

    The “Add Blend Zone” window in Figure 7-3 will appear. Configure the initial parameters for the blend zone and click “Add Blend Zone” to add it to the UI. “White” means the location of the full on side of the blend zone (white line). “Black” means the location of the full off side of the blend zone (black line).

  • Page 39: Adjusting The Advanced Blend Drop-Off Curve

    7.2.6 Adjusting the advanced blend drop-off curve The drop-off curves can be configured individually for advanced blend. Click on a control point in the blend zone you would like to adjust, or select multiple points or blend zones with by dragging a selection rectangle over the areas of interest. Then select “Drop-off Curve” in the Calibration panel toolbar.
  • Page 40 Go to custom if you need to change the selected curve or enter a new manually, as seen in Figure 7-6. Figure 7-6. Drop-off curve setup Multi image processor User’s Guide – Edge Blending...

  • Page 41: Test Patterns

    8 Test patterns The multi image processor has several built-in test patterns for easier setup. This tool can be used to tune the geometry (warping) in a setup to match reference points, aspect ratio, ensure visual correctness and to configure 3D image generators for shapes like cylinders and domes.

  • Page 42: Circle Test Pattern

    8.1 Circle test pattern Circles can be added to calibration area to ease the setup. The position (x, y pixel coordinates) and the radius (pixels) can be specified. Figure 8-3 shows the Test Image Setup window with two circles added. Figure 8-3.

  • Page 43: Grid (Pixel) Test Pattern

    8.2 Grid (Pixel) test pattern A grid with much smaller cells than the calibration grid can be really convenient for setup. Especially when using the Mesh Bezier Warp where the calibration can be done with very few control point. To add a Grid (Pixel) select the “Grid (Pixel)” tab and specify your parameters (). The parameters are: offset (x, y in pixels for top, left corner) and height and width of the cells in the grid.

  • Page 44: Grid (Angle) Test Pattern

    8.3 Grid (Angle) test pattern The last test pattern available in the processor unit is the Grid (Angle) test pattern. This is used to create a reference grid in a dome or a cylinder. Parameters to specify for this grid are ‘to’ and ‘from’ angles (in degrees) in horizontal and vertical direction.

  • Page 45: Black Level Management

    9 Black Level Management Black Level Management (BLM) is a feature patented by projectiondesign for adjusting offset (brightness) in selected areas to compensate for non-perfect black levels in projectors. This enables the possibility to have seamless images in all the gradients of all colors. To start the black level management tool, click on “Black Level”...
  • Page 46 Figure 9-1. Adding Black Level Management lines. Figure 9-1. Multiple Black Level Management lines added. To create the next side in the zone, click on one of the control points in the first line created (not the Bezier points) and then click (Add) again (Figure 9-1).

  • Page 47: Removing Blm Zones

    Important! To add the last line connecting the first and last control point, it is important to select both of the control points required to encapsulate the calibration area (Figure 9-1). To select multiple points, either press and hold Ctrl while using the mouse point to select points or drag and drop a selection rectangle over the points.
  • Page 48 Multi image processor User’s Guide – Black Level Management...
  • Page 49 10 Masking Masking (also called clipping) is used to cut out areas of the image which should be blanked out. An example of this is overshooting of the image in a dome. To start the masking tool, click “Clip” in the Calibration View Toolbar (Figure 10-1). Figure 10-1.

  • Page 50: Adding Areas To Clip

    10.1 Adding areas to clip Start with clicking (Add) in the Calibration View Toolbar. This will create the first line in the area to mask out (Figure 10-2). Figure 10-2. Adding the first line in a clip area. Multi image processor User’s Guide – Masking...
  • Page 51 To create the next side in the zone, click on one of the control points in the first line created (not the Bezier points) and then click (Add) again (Figure 10-3). This will add other line to the calibration panel. Continue to add lines as needed. All these lines have the same controls as Bezier lines in the Mesh Bezier Warp and the Advanced Edge Blending.

  • Page 52: Removing Clip Areas

    Note! To add the last line connecting the first and last control point, it is important select both of the control points required to encapsulate the calibration area (Figure 10-4). To select multiple points, either press and hold Ctrl while using the mouse point to select points or drag and drop a selection rectangle over the points.

  • Page 53: Storing And Recalling Data

    11 Storing and recalling data The multi image processor system has powerful and flexible features for storing and recalling calibration data. When a calibration is stored, the user can recall all calibration parameters at any given time or on any given control PC. Calibration can be stored: • In the multi image processor unit • On the control PC.

  • Page 54: Storing/Recalling Data To/From The Control Pc

    11.2 Storing/recalling data to/from the control PC Before you can save a calibration to the control PC, you first have to save your calibration to the multi image processor unit. When performing a backup to the control PC, the last data stored in the multi image processor unit will be copied to the control PC.

  • Page 55: Restoring Calbration Files

    If you create a target top folder, multiple units can be backed up in the same operation. Select the target folder to which the data should be saved and press “Start”. When all files are copied to the control PC, click “Done”. Each unit the system will have to be upgraded separately.

  • Page 56: Accept Calibration

    11.3 Accept calibration After a calibration has been completed and the result verified in online state, the calibration must be accepted. When a calibration is accepted for one resolution the binary data is stored in the WB unit and will be loaded automatically every time the unit starts up or the resolution is changed to cur- rent.

  • Page 57: Technical Specifications

    2560 x 1600 (WB2560) 1920 x 1200 (WB1920) 3D stereographic 1920 x 1200@ 120 Hz on WB2560 1280 x 800 @ 120 Hz on WB1920 setup and control ProNet™ setup and calibration tool Automatic Camera setup (tba.)
  • Page 58 12.2 Mechanical Multi image processor User’s Guide - Technical specifications...
  • Page 59 13 Table of figures Figure 4-1. Multi image processing system overview Figure 4-2. Connector panel Figure 4-3. Front button and LED-indicators Figure 4-4. Rack mount plate Figure 4-5. Rack mounted Figure 5-1. Overview of ProNet.site Figure 5-1. WB calibrator, Device View. Figure 5-1.
  • Page 60 Figure 11-1. Save current calibration to the multi image processor unit Figure 11-2. Backup up calibration data. Figure 11-3. Selecting folder for backup Figure 11-4. Restore calibration from control PC Figure 11-5. Accept calibration Multi image processor User’s Guide - Table of figures...
  • Page 62 head office regional offices regional contacts projectiondesign as New York - Americas Panama – Central and South America Habornveien 53 projectiondesign LLC ph +507 69 800 555 fx +47 69 30 45 80 N-1630 Gamle Fredrikstad, 295 North Street, sales@projectiondesign.com Norway Teterboro, NJ 07608, ph +47 69 30 45 50 fx +47 69 30 45 80...

This manual is also suitable for:
