DEI PVM-4210 DIRECTED ENERGY, INC. PVM-4210 ±950V Pulse Generator Module OPERATION MANUAL Directed Energy, Inc. 2401 Research Blvd., Ste. 108 Fort Collins, Colorado 80526 970/493-1901 FAX 970/493-1903... - Page 2 DEI PVM-4210...
-
Page 3: Table Of Contents
DEI PVM-4210 Table Of Contents 1.0 Safety......................3 2.0 Overview .....................3 3.0 Specifications....................6 4.0 Connector Pin-Outs And User Adjustments..........7 4.1 Polarity Reversal ................7 4.2 Power Supply Enable ................9 5.0 OPERATING INSTRUCTIONS ..............10 5.1 Output Cabling ..................10 5.2 Load Interconnection.................10 5.3 Power-Up Procedures ...............10 6.0 TROUBLESHOOTING .................11... - Page 4 DEI PVM-4210 ********** WARNING ********** SAFE OPERATING PROCEDURES AND PROPER USE OF THE EQUIPMENT ARE THE RESPONSIBILITY OF THE USER OF THIS SYSTEM. Directed Energy, Inc (DEI) provides information on its products and associated hazards, but it assumes no responsibility for the after-sale operation and safety practices.
-
Page 5: Safety
<15 nanoseconds, and pulse widths continuously adjustable from <40 nanoseconds to DC. The pulser operates on +24VDC to +28VDC support power, and features integrated DC high voltage power supplies. The PVM-4210 is optimized for differential drive of deflection plates for electrostatic modulation particle... - Page 6 0 to 950V using screwdriver-adjustable potentiometers readily accessible on the end panel of the pulser module. The PVM-4210 requires +24VDC to +28VDC support power and a TTL (into 50Ω) gate signal. For safety and control flexibility, a TTL level signal is used to enable and disable the DC power supplies.
-
Page 7: Dei Pvm
DEI PVM-4210 P1-9 +5VDC +950V Power +24V To Logic Supply +75V Power P1-15 +24V +15V Supply Positive Pull Positive Gate Inversion on/off Gate Output Pulse Generation Primary Drive Transformer P1-6 Pulse Over current inhibit Positive Pull Down To HV P1-14... -
Page 8: Specifications
F, where C is the total load capacitance, including the capacitance of the load, interconnect cable, and the internal capacitance of the PVM-4210, V is the pulse voltage, and F is the pulse repetition frequency (or the total pulses per second). (For these calculations, the internal capacitance of the PVM-4210 is 125pF, and Belden 8218 cable is 21.5pf/foot.) Given the maximum power supply capability of 4W (4mA) per... -
Page 9: Connector Pin-Outs And User Adjustments
20KHz. This formula is not applicable when driving non-capacitive (resistive or inductive) loads. Contact DEI for information or assistance in using the PVM-4210 with different load characteristics or impedances. 4.0 Connector Pin-Outs And User Adjustments... - Page 10 DEI PVM-4210 GATE INPUT GROUND + PULSE VOLTAGE OUT + PULSE GROUND GROUND - PULSE - PULSE VOLTAGE OUT Output Pulse Configuration With Non-Inverted Gate Selected The ouput polarity can be reversed (so that the output is held at high voltage when the gate is low, and pulsed ground when the gate is high) by jumpering pins 10 and 11 together.
-
Page 11: Power Supply Enable
Output Pulse Configuration With Inverted Gate Selected 4.2 Power Supply Enable For safety and flexibility, the PVM-4210 features a power supply enable input (DSUB connector pin 14). In order to enable the DC power supplies (and therefore generate an output pulse), this input must be held HIGH. This can be done in two ways: 1. -
Page 12: Operating Instructions
5.1 Output Cabling The PVM-4210 is designed to drive capacitive loads with fast rise times. Since the current out of the PVM-4210 is limited, the lower the capacitance, the faster the risetime. -
Page 13: Troubleshooting
DEI PVM-4210 2. Connect the input DSUB connector, and connect the output to an appropriate load, prior to applying +24VDC power. 3. Monitor the voltage across the load, utilizing an appropriate high voltage probe or attenuator. 4. Apply +24VDC to +28VDC power to the module, and apply a TTL level power supply enable signal (or close the switch to connect pin 3 to pin 14 as described above). -
Page 14: Factory Service
DEI PVM-4210 -Input trigger voltage too low. -Input trigger pulse width too short. Increase width. -Input trigger frequency too high. Reduce frequency. -No input high voltage. Check HV supplies. -Enable circuit not satisfied. Ensure that +5VDC is applied to DSUB pin 14. - Page 15 DEI PVM-4210 At DEI's discretion, DEI may elect to repair or replace the equipment claimed to be defective or refund the original purchase price, plus taxes and transportation charges incurred by the purchaser. This Warranty shall not apply to any product that has been: 1.
-
Page 16: Appendix
DEI PVM-4210 APPENDIX Mechanical Dimensions And Mounting Hole/Connector Location Drawing Document Number 9100-0201 Rev 8 Directed Energy, Inc. 2000-2002 Page 14... - Page 17 OPERATION. THERE ARE NO USER-SERVICABLE PARTS INSIDE. 1.00 TOP VIEW 8-32 PEM nut for mounting puposes far side. 4 places PVM-4210 Mechanical Dimensions And Mounting Hole/Connector Locations All Dimensions Are In Inches Not To Scale Document Number 9100-0201 Rev 8 Directed Energy, Inc. 2000-2002...
