Octo Value OXE831 Specifications

Octo Value
HD Seamless Switcher for Houses of Worship, Conference
Rooms and Large Screen Projections
Inputs
Universal
8
DVI 1080p
WUXGA
Up to
Preliminary Pictures
Transition effect
selection
Convenient input for last
minute connection
LAN control
Standard IEC international
power connector
Inputs
• Analog & Digital In/Out up to 1080p,
• 8 Universal Inputs with 1 DVI,
• Computer and DVI up to WUXGA / 1080p
• Video: NTSC/ PAL/SECAM, S.Video,
YUV, RGB, HDTV
• 8 + 1 Audio Stereo with level adjustmen
for each input
Outputs
Titling
Simultaneous
DVI
Fade
Outputs
Cut
Direct input selection
with LED
Freeze
Universal inputs on BNC, HD15 female
and DVI connectors (Computer, Video,
HDTV, DVI)
RS232 Com Port
Main outputs: 1 DVI and
1 RGB
Outputs
• Main: 1 DVI + 2 RGB up to WUXGA / 1080p
• Preview: XGA RGBHV
• Audio Stereo Main and Pre- List with level
adjustment
Effects Functions
Logo
Clean Cut
PIP System
Frame
Store
Take Easy to read LCD screen
Control Menu
Preview output
Pre List Audio
Main audio inputs and output on MCO and 3.5mm
jack connectors. Stereo inputs with individual line
control, output volume and balance control
Effects
• Scaled Preview, Hi-Res PIP, Fade, Titling,
Seamless Cut, Clean Cut
• Ultra fast and smooth switching
• Logo inserter: 1 animated and up to
8 still logos
• 4 full frame stored in non-volatile memory
Ref. OXE831
Others
100%
Preview
HD
