To Enter The S.a.m.e. Fips Codes Into The Memory Locations; Charging A Usb Device; Set Up Simple Noaa Weather & Emergency Alert Mode; Set Up Tornado Mode - Cobra CWR200 User Manual

To enter the S.A.M.E. FIPS codes into the
memory locations:
1. Press the Power/Menu button until SET MEMORY
is shown.
2. Press the Select button to the Memory Location.
For example, MEMORY 01.
3. Press the Select button to choose that
Memory Location or press the Up or Down
buttons to select another Memory Location.
For example, Memory 02, Memory 03, etc.
4. Press the Up, Down and Select buttons to enter all 6
digits of the FIPS code.
5. The ON and OFF selection for that FIPS Code will then
be blinking. Press the Up button to select ON if you
want to receive alerts for this area.
6. The next Memory Location will then be shown.
Repeat these steps for up to 25 FIPS location codes.
7. When done entering your FIPS codes, press the Menu button to save
the changes and move onto the rest of the setup menu.
Notes:
• Most users will only enter 1-5 FIPS codes.
• Make sure the Memory Location's FIPS code it set to ON if you want
to receive alerts for that location. For your convenience, they can
be set to ON or OFF in case you travel between local areas and only
want to receive the applicable alerts for your location. If it is set to
OFF then you will not receive alerts for that area.
• You can leave multiple and/or all the FIPS codes set to ON and this is
probably the most common and best practice.
11

Charging a USB Device

1. To turn USB Charging ON.
2. Press the Power/Menu button until you reach
"SET CHARGING".
3. Press the Select button to choose between
"ON" and "OFF" position.
4. Once on, you will see the USB icon in
the display.
5. Connect a USB compatible device into the
charging port located on the side of the radio.
6. Once connected, the radio will act as an external
power source to charge the desired device.
OUT OUT
WA R N I N G
WAT C H
A D V I S O RY
VOL CHN
VOL CHN
MODE
Connecting a USB-compatible device
to the CWR200 to charge
16
Set Up Simple NOAA Weather & Emergency Alert Mode:
This radio can also be set to just receive all 1050 Hz alert tone
generated weather alerts. This is a simple mode of operation and it
will alert to all emergencies which broadcast this tone. The option to
turn this ON will appear in the menu only if SAME is turned OFF.
For example, you might want to use this mode if your radio is set with
SAME codes for home use and then you decide to take it on a road trip.
You can leave those Memory Location programmed and just turn SAME
MODE off and WX Alert mode ON. The radio will now receive all alerts.
To turn Weather Alert Mode ON or OFF:
1. Press the Power/Menu
button until SET SAME is
shown.
2. Press the Select button to
show ON or OFF.
3. Press the Up or Down buttons until OFF is shown.
4. Press Select to turn SAME Mode OFF.
5. SET WX ALERT will now
appear on the display.
Press Select and ON or
OFF will show.
6. Press the Up or Down
button to select ON or OFF.
7. Press Select to choose your setting.
Notes:
• The SET WX ALERT will only show in the menu if SET SAME has
been turned OFF. If SET SAME is turned ON again then the SET WX
ALERT will disappear (not show) from the menu until the next time
SET SAME is turned OFF.
• If both Weather Alert Mode and SAME Mode are turned OFF then
you will not receive any alerts. You can continue to listen to the
weather and emergency channels but you will not receive any alerts
(overriding the volume), colored lights or text notifications about the
alert levels and types.
12
Customer Assistance
Should you encounter any problems with this product, or not understand its
many features, please refer to this owner's manual. If you require further
assistance after reading this manual, Cobra Electronics offers the following
customer assistance services:
For Assistance in the U.S.A.
Automated Help Desk:
WA R N I N G
English only. 24 hours a day, 7 days a week, phone 773-889-3087.
Customer Assistance Operators:
WAT C H
English and Spanish. 8:00 a.m. to 5:30 p.m. Central Time, Monday through
Friday (except holidays), phone 773-889-3087.
A D V I S O RY
Questions:
English and Spanish. Faxes can be received at 773-622-2269.
Technical Assistance:
English only. www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo@cobra.com (e-mail).
For Assistance Outside the USA:
Contact Your Local Dealer
Trademark Acknowledgement
Cobra and the snake design are registered trademarks of Cobra
®
Electronics Corporation, USA.
Cobra Electronics Corporation™ is a trademark of Cobra Electronics
Corporation, USA.
All other trademarks and trade names are those of their respected
owners.
17

Set Up Tornado Mode:

This radio has something special called the Tornado Mode. It allows
you to block the audio alerts from many common, but maybe unwanted
alerts during the night and other times when you would prefer less
alerting. If the Tornado Mode is turned on, the radio continues to
receive and log the alerts but the alarm will not sound and it will not
switch to the broadcast voice audio. The radio's visual alerts (light and
message) will continue to display. The Tornado Mode will be indicated
on the display as BLOCK ON and BLOCK OFF. If BLOCK is set to ON,
all incoming alerts will be detected and will be "silenced" except for
tornados and other extreme emergencies*.
To turn BLOCK ON or BLOCK OFF:
1. Press the Tornado Mode button to
select ON or OFF.
2. Just leave the radio for a few seconds
and that Tornado Mode setting will be
saved.
If the Tornado Mode is enabled, the display continuously alternates
between the clock time and showing BLOCK ON. If the Tornado Mode is
disabled (BLOCK OFF), then no message regarding Tornado Mode status
will be shown.
*Extreme emergencies that will not be silenced using the Tornado Mode (Block ON)
include extreme emergencies like; Biological Hazard Warning, Civil Danger Warning,
Civil Emergency Message, Chemical Hazard Warning, Contaminated Water Warning,
Dam Break Warning, Contagious Disease Warning, Emergency Action Notification,
Emergency Action Termination, Earthquake Warning, Immediate Evacuation, Food
Contamination Warning, Hazardous Materials Warning, Hurricane Warning, Industrial
Fire Warning, Local Area Emergency, Law Enforcement Warning, Landslide Warning,
Nuclear Power Plant Warning, Radiological Hazard Warning, Shelter-In Place Warning,
Tornado Warning, Tropical Storm Warning, Tsunami Watch, Tsunami Warning, Volcano
Warning and Wild Fire Warning.
13
Product Service
For any questions about operating or installing this new Cobra product, or
if parts are missing...PLEASE CALL COBRA FIRST...do not return this
product to the store. If this product should require factory service, please
call Cobra before sending the product. This will ensure the fastest turn-
around time on any repair. If Cobra asks that the product be sent to
its factory, the following must be furnished to have the product serviced
and returned:
1. For Warranty Repair include some form of proof-of-purchase, such as
a mechanical reproduction or carbon of a sales receipt. Make sure the
date of purchase and product model number are clearly readable. If
the originals are sent, they cannot be returned;
2. Send the entire product;
3. Enclose a description of what is happening with the product. Include a
typed or clearly printed name and address of where the product is to
be returned, with phone number (required for shipment);
4. Pack product securely to prevent damage in transit. If possible, use
the original packing material;
5. Ship prepaid and insured by way of a traceable carrier such as United
Parcel Service (UPS) or Priority Mail with delivery confirmation to
avoid loss in transit to: Cobra Factory Service, Cobra Electronics
Corporation, 6500 West Cortland Street, Chicago, Illinois 60707
U.S.A.;
6. If the product is in warranty, upon receipt of the product it will either
be repaired or exchanged depending on the model. Please allow
approximately 3 – 4 weeks before contacting Cobra for status. If the
product is out of warranty, a letter will automatically be sent with
information as to the repair charge or replacement charge.
For any questions, please call 773-889-3087 for assistance.
18
LED Flashlight
Press and release the LED
Flashlight button to use the LED
flashlight located at the bottom of
the radio.
LED Flashlight Button
Setting an Alarm:
If you have already set the time, then you can also use it to set an alarm.
This radio can be used as an alarm clock.
1. Press the Power/Menu button until SET ALARM is
shown.
2. Press the Select button to show ON or OFF.
3. Press the Up or Down buttons until ON is shown and
then press Select. The last set alarm time will be
shown with the hour setting blinking.
4. Press the Up and Down buttons to adjust the hour and
press Select.
5. Use the same procedure to set the minutes and AM
or PM.
6. Press Select to set the alarm for that time.
An alarm icon will show up on the display to let you know
an alarm is active and waiting to go off. When the alarm
sounds, press the Weather Snooze button to snooze the
alarm for 5 minutes. The alarm must be turned off in
the menu to permanently silence the alarm.
14
Limited 1-Year Warranty
For Products Purchased in the U.S.A.
Cobra Electronics Corporation warrants that its weather radios, and the
component parts thereof, will be free of defects in workmanship and
materials for a period of one year from the date of first consumer
purchase. This warranty may be enforced by the first consumer
purchaser, provided that the product is utilized within the U.S.A.
Cobra will, without charge, repair or replace, at its option, defective
weather radios, products or component parts upon delivery to the Cobra
Factory Service Department, accompanied by proof of the date of first
consumer purchase, such as a duplicated copy of a sales receipt.
You must pay any initial shipping charges required to ship the product
for warranty service, but the return charges will be at Cobra's expense, if
the product is repaired, this warranty gives you specific rights, and you
may also have other rights which vary from state to state.
Exclusions: This limited warranty does not apply:
1. To any product damaged by accident.
2. In the event of misuse or abuse of the product, or as a result of
unauthorized alterations or repairs.
3. If the serial number has been altered, defaced or removed.
4. If the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and
fitness for a particular purpose are limited in duration to the length of
this warranty.
Cobra shall not be liable for any incidental, consequential or other
damages; including, without limitation, damages resulting from loss of
use or cost of installation.
Some states do not allow limitations on how long an implied warranty
lasts and/or do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you.
19
Turning Key Tones ON or OFF:
When Key Tone is ON, an audible tone will sound each time a button is
pressed. To turn turn Key Tones ON or OFF:
1. Press the Power/Menu button until SET KEY TONE is
shown.
2. Press the Select button to show ON or OFF.
3. Press the Up or Down buttons until ON or OFF is
shown and then press Select.
4. Press Select to confirm your choice.
15
Channel Availability
The radio is capable of receiving and successfully decoding signals on the
following frequencies:
Channel Frequency
1 162.400 MHz
2 162.425 MHz
3 162.450 MHz
4 162.475 MHz
5 162.500 MHz
6 162.525 MHz
7 162.550 MHz
20
