Broan QTRE100S Specification Sheet

MODEL QTRE100S
HuMIDITY SENSINg FAN
A modern-styled, high performance fan, with
sensing circuitry, that "knows" when to ventilate
the room.
FEATuRES
BLOWER:
•
Plug-in, permanently lubricated motor - engineered
for continuous operation
•
Dynamically balanced centrifugal blower wheel for
quiet, efficient performance
•
Maintains a high percentage of rated CFM in less
than ideal installations
•
Low RPM for quiet operation
HOUSING:
•
Rugged, 26 gauge, galvanized steel construction
•
4" round ducting for superior performance
•
Polymeric duct connector with tapered sleeve and no
metallic clatter
•
7-5/8" height allows for 2" x 8" (nominal) joist
installations
•
Sturdy, easy, four-point mounting directly to joist
•
Includes unique spacer (patent pending) for mounting
to engineered "I" joists
•
Includes hanger bars to position housing anywhere
between 16" to 24"-on-center joists
•
Two sets of mounting holes for hanger bars allow
flush installation with bottom or top of drywall
GRILLE:
•
Polymeric construction
•
Innovative design - the result of extensive research
with designers and consumers
REFERENCE
Broan-NuTone LLC Hartford, Wisconsin www.broan.com 800-558-1711
QTY. REMARKS
AUTOMATIC CONTROL:
•
Humidity control automatically turns fan ON when either of
these conditions is detected:
- a rapid to moderate increase of humidity
- humidity above factory set-point
•
Two wire manual operation for odor control - Turns fan ON
when power line through wall switch is cycled ON, OFF and
back ON
•
Remains ON for 20 minutes after humidity has stabilized
and is below factory set-point or after manually initiated
through power line cycling
•
Saves energy because unit runs only for the time required.
A unit controlled with a wall timer may keep fan ON longer
than required or turn it OFF before room is sufficiently
ventilated
CONTROLS (Purchase separately):
•
Refer to Broan's catalog for a complete line of accessories
to effectively adapt these fans to your construction
requirements
U.L. Listed for use over bathtubs and showers when connected
to a GFCI protected branch circuit (ceiling mount only).
3-Year Warranty
Project
Location
Architect
Engineer
Contractor
Submitted by
SPECIFICATION SHEET
Date
90D 99044036D
