Up Star P32ETW User Manual

32" lcd tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

32" LCD TV
UP STAR USA Group
1885 S Vineyard Ave, Ontario, CA 91761
Toll-free: 1-877-908-6777
MODEL: P32ETW
Tel: 562-972-8098, Fax: 562-972-8068
E-mail: Sales@Upstarusa.com
(Please read this manual carefully before operating the set
www.Upstarusa.com
And retain it for future reference.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P32ETW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Up Star P32ETW

Summary of Contents for Up Star P32ETW

  • Page 1 32" LCD TV UP STAR USA Group 1885 S Vineyard Ave, Ontario, CA 91761 Toll-free: 1-877-908-6777 MODEL: P32ETW Tel: 562-972-8098, Fax: 562-972-8068 E-mail: Sales@Upstarusa.com (Please read this manual carefully before operating the set www.Upstarusa.com And retain it for future reference.)

  • Page 2: Table Of Contents

    Contents Important Safety Instructions ................. 1 WARNING............................1 Caution............................1 Important............................1 REGULATORY INFORMATION......................1 GENERAL INFORMATION ..................3 Accessories............................3 Viewing the Control Panel ......................3 Remote Control..........................4 Batteries Installation of Remote-Control Unit................5 Names of each part........................5 CONNECTIONS......................7 Installing an Antenna ........................7 Satellite/Cable TV Set-Top Box Connections ................8 Watching Cable TV........................8 DVD Connections ..........................9...

  • Page 3: Important Safety Instructions

    Important Safety Instructions WARNING TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTRUE. Caution These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in The operating instructions, unless you are qualified to do so.
  • Page 4 Keep these instructions. Heed all instructions. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturers Instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other Apparatus (including amplifiers) that produce heat.

  • Page 7: Remote Control

    Are the plus and minus ends of the batteries reversed? Are the batteries drained? Is there a power outage or is the power cord unplugged? Is there a special fluorescent light or neon sign nearby? Names of each part P32ETW Screen Remote control and Intelligent sensors Speakers...
  • Page 8 Screen VGA IN TUNER HDMI1 HDMI2 HDMI3 POWER IN PC AUDIO IN COAX AUDIO AV IN Ou t Power ON/OFF switch 7、8、9 HDMI in jack Power in jack 10 USB in jack 11 Y, Pb, Pr and AUDIO (R/L) jack COAX jack TV jack 12 AV IN VIDEO and AUDIO (R/L) jack...

  • Page 9: Connections

    CONNECTIONS Installing an Antenna For connecting to ATSC or NTSC broadcasts POWER IN Press SOURCE button on the remote control to select TV, then press ► button to confirm. Then you can receive the ATSC/NTSC signal. English -7...

  • Page 10: Satellite/Cable Tv Set-Top Box Connections

    Satellite/Cable TV Set-Top Box To the Composite terminal In order to watch Cable TV, Subscribe to your local Cable TV company and install a separate Receiver (SET-Top-Box) Terminals of other equipment By manufacturer and model. <Cable broadcasting receiver> Pubic Pr/Cr AV IN R (OUT) L (OUT)

  • Page 11: Dvd Connections

    DVD Connections Connecting to the Component terminal Connection terminals of other equipments differ by manufacturer and model. < > Component connection cable Component Audio cable Pubic Pr/Cr BP Pr AV IN R (OUT) L (OUT) 1. Connect LCD TV’s Y, BP, Pr terminal to DVD’s Video Out terminal using the external cable. 2.

  • Page 12: Pc Connections

    PC Connections Connection terminals of other equipments differ by manufacturer and model. Analog RGB (D-Sub 15pin) Cable PC Audio Cable Connect LCD TV’s PC Input terminal to PC’s RGB terminal using the D-Sub cable. Connect LCD TV’s PC Audio terminal to PC’s Audio terminal using the Audio cable. (Only for PC’s with Audio terminal) How to Use as PC monitor 1.

  • Page 13: Basic Use

    Basic Use Powering the LCD TV Power ON/OFF To turn the LCD TV on: Press the “POWER” button. To turn the LCD TV off: Press the “POWER” button on the LCD TV. To turn ON or OFF by remote control: Press the “POWER”...

  • Page 14: Application

    Application Operating the Menu 1. Press the POWER button to turn the LCD TV on. 2. Press the MENU button on the remote control, the on-screen menu will appear on the Screen. 3. Use the ◄/► buttons to select your main menu option. PICTURE MENU: Allows you to make adjustments your picture settings.
  • Page 15 Parental Control MENU: Set program rating control and input source, keypad lock function. V-CHIP Change Password Keypad Lock Source Lock SETUP MENU: Select closed caption options, language and time. ：Move OTHERS MENU: Set the OSD blue background, whether auto power of no signal or no operation, clear All user settings etc.

  • Page 16: Picture Menu

    PICTURE MENU Picture Settings Screen Size Wide PC Settings Color Temperature Normal Advanced Picture Settings Move ▼/▲ Press to highlight one of the following options, and then press ENTER or to enter next sub- Menu to adjust it. Press EXIT to clear on-screen menu or MENU back to the previous menu. Picture Settings Adjust the picture quality including brightness, contrast, color, tint, Sharpness.

  • Page 17: Picture Mode

    PICTURE MENU/ PICTURE Settings : Return : M over When Picture Mode is set to User, the following settings can be manually adjusted. Press PMODE shortcut button on the remote control to select picture mode directly. Adjusting the values Picture Mode ◄/►...
  • Page 18 PICTURE MENU/ PC Settings PC Settings Menu is available only in PC DB15 or DVI mode. When DVI signal input, only Horizontal Position and Vertical Position can be adjusted. Press to highlight one of the following options, and then press ENTER to select it. ▼/▲...
  • Page 19 PICTURE MENU/ Advanced Picture Settings : Move Press ▼/▲ to highlight the item and press ENTER or ►to display the sub-menu as following. Dynamic Contrast Of/Low/Medium/High The system will adjust the luminance curve by analyzing the picture content dynamically. Film Mode OFF / ON For the 2:2 or 3:2 format signal of cinema, enable special pixel process to reduce the hick of moving Area.

  • Page 20: Sound Menu

    SOUND MENU Sound Settings Surround Mode Analog Sound Digital Sound Digital Audio Output Equalizer Settings : Move Sound Settings Set the sound mode, and Bass /Treble/Balance. Surround Mode Set to enjoy the virtual surround sound. Press ENTER to set or cancel. Auto Volume Level.
  • Page 21 SOUND MENU/ Sound Settings SOUND SETTINGS : Move Sound Mode Standard/Dynamic/Soft/User Only in User mode, the follow items can be adjusted. Bass Adjust the low frequency band response. Treble adjust the high frequency band response. Balance Adjust the level of sound coming from the left or right speaker. Adjust the Bass/Treble/Balance 1 Set Sound Mode to User.
  • Page 22 SOUND MENU/ Equalizer Settings Mode : Move Mode OFF/Rock/Pop/Jazz/User (only in User mode, the following can be manually adjusted.) Adjust Equalizer Settings Based on your favorites about which frequency band need to be adjusted, make small Adjustment with certain frequency band at a time. Suggest NOT making too large changes. 1 Set Mode to User.

  • Page 23: Channel Menu

    Channel MENU Channel Settings : Move Note: The menu is available only at TV source. Channel List You can view all the channels and choose one quickly. For details of setting. Favorite List all of you favorite channels are listed in this menu and you can choose them Quickly.
  • Page 24 Channel MENU/ Channel List D10-1 : Move “ABC”: Label of the Channel. Press ▼/▲ to highlight a channel and press ENTER to view it. Channel MENU/ Favorite List The list shows channels that you set as favorite. See” Channel Settings” on page 17 to understand how to set channels be favorite. Page 1/1 D10-1 : Move...
  • Page 25 Channel MENU/Auto Channel Search : Stop Auto Channel Search : Skip It will search analog channels rest, then digital channels. Before execute auto channel search, please contra your antenna type is Air or Cable. Wrong setting of Signal Type maybe because ending no channel. Found numbers do not Include encryption programs.
  • Page 26 Channel MENU/Channel Settings CHANNEL SETTINGS Channel Label Skip Favorite D10-1 : Cursor/Page Skip Set the channel to be skipped when using CH+/Ch- to view channels. Favorite Set the channel to your favorite list. Label Rename label of the channel. Change the settings Skip &...

  • Page 27: Parental Control Menu

    PARENTAL CONTROL MENU V-CHIP Change Password Keypad Lock Source Lock ：Enter Password Note: The default user password is “0000”, and if forget what you set, try“1470”. Lock Parental Control The following items are only available if the password input Is correct. V-CHIP Include below settings: US V-Chip...
  • Page 28 PARENTAL CONTROL MENU/ Lock Parental Control Settings ▼/▲ Press to highlight one of the following options, and then press ENTER or to enter next sub- Menu to adjust it. Press EXIT to clear on-screen menu or MENU back to the previous menu. How to access to hotel menu 1、Press the menu button on the remote control, the main menu will display.
  • Page 29 PARENTAL CONTROL MENU/ Hotel Lock Settings HOTEL SETTING Boot Setting Hotel Lock Setting Power Save Export Setting Execute Import Setting Execute Reset Hotel Setting Execute ：Move A. Tuner Lock: Press▲▼ to select tune to lock, then press ENTER to set it to lock. Moreover, it could not search the Channel, .but change available channel.
  • Page 30 PARENTAL CONTROL MENU/US V-CHIP For the United States, the rating setting basically include the following options: Movie Rating, TV Rating. PARENTAL CONTROL MENU/ Movie Rating This system defines the rating controls which come from MPAA rules : Move Rating define General audience.
  • Page 31 PARENTAL CONTROL MENU/ TV Rating The TV ratings compose of two aspects: age-based and content-based. : Move Define Content Deane TV-Y General audience Fantasy violence Parental guidance suggested Suggestive dialogue TV-Y7 TV-G Parents strongly cautioned Strong language TV-PG Sexual situations Retracted Violence No one 17 and under admitted...
  • Page 32 PARENTAL CONTROL MENU/ Canada V-CHIP For Canada, the rating settings include the following options: English Rating, French Rating. English Rating These ratings are for programs which are using English rating system. Rating Defined as Children ENGLISH RATING Children 8 years and older General programming Parental guidance Viewers 14 and older...
  • Page 33 PARENTAL CONTROL MENU/ Change Password : Enter Password At rest you should enter the correct old password then enter new password twice. If you lost your password, try to enter “1470". Source Lock Press ▼/▲ to select the source you want to lock, and then press ENTER to set it to lock. If anyone Want to use this source, the password is needed.

  • Page 34: Setup Menu

    SETUP MENU : Move Closed Caption (CC) Include below options: Caption Display or hide the CC. Analog Caption Type Select from below closed-caption modes for analog programs. CC1, 2, 3, 4 displays corresponding caption channel of an analog program. (Usually be set to CC1 For most programs.) Text1, 2, 3, 4 displays corresponding text service channel of an analog program.
  • Page 35 SETUP MENU/ Digital CC Style CC Size Small CC Font Style4 CC Opacity Solid Text Color CC Background Opacity Transparent CC Background Color Default CLOSED CAPTION : Move : Return This menu is valid only for digital closed caption of digital channels. CC Size Small/Standard/Large/Default CC Font...

  • Page 36: Time Zone

    SETUP MENU/ Clock Daylight Saving Time ： Move : Return : Return Hawaii/Alaska /Pacific / Central/Mountain/ Eastern/ Samoa/Newfoundland Time Zone Auto Clock If set it to ON, the TV will sync the local clock according to the DTV broadcasting time Automatically.

  • Page 37: Others Menu

    Others MENU : Move Blue Back Set the screen background color blue or not when no valid signal input. When analog TV input and has no signal, snow noise will display if this option is cleared. If it is set, TV will automatically enter standby after 10 minutes No Signal Power OFF Without signal input.

  • Page 38: Pc Mode

    PC Mode Setting up your PC software (based on Windows XP) The Windows display-settings for a typical computer are shown below. But the actual screen on Your PC will probably be deferent, depending upon your particular version of Windows and your Particular video card.

  • Page 39: Trouble Shooting

    Trouble shooting Do not use other functions that are not mentioned in this user’s manual. In case a problem occurs with your LCD TV, please take the following steps rest. If you still have the problem, turn the power OFF and contact your dealer or an authorized Service center.

  • Page 40: Specifications

    Specifications Model P32ETW Panel Size 32” Widescreen TFT LCD Resolution 1366×768 Pixel LCD Panel Number of Colors 16.7M Viewing Angle 178°/178° Dynamic Contrast Ratio 50,000:1 Yapp Input AUDIO (L/R) 2(AV and Yapp audio input) Connector PC/AUDIO (L/R) HDMI Output COAX...
  • Page 41 Unauthorized product modification, or failure to follow instructions supplied With the product. Repair or attempted repair by anyone not authorized by up star. Damage to or loss of any programs, data or removable storage media. Software or data loss occurring during repair or replacement.
  • Page 42 May also have other rights that vary from state to state. The Customer Services & Technical Support To obtain warranty service, please contact up star Customer Services for a Return Material Authorization number (RMA). You will be required to provide A copy of the dated sales slip.
  • Page 43 1885 S, Vineyard Ave Ste 1 Ontario, CA 91761 Toll-free: 1-877-908-6777 Tel: 562-972-8098, Fax: 562-972-8068 E-mail: Sales@Upstarusa.com www.Upstarusa.com Programs, specification, pricing & available are subject to change without notice. Copyright by up star USA Group 2011-2021 all rights reserved English-41...
  • Page 44 Up star Warranty Registration Card Up star will register this warranty upon receipt of your Warranty Registration Card & a Copy of your purchase' receipt From one of retail locations as proof of purchase. Please submit your Warranty Registration Card & your receipt within Thirty (30) days of the date of purchase Up star /Warranty Registration Dept.,...
