GrandCafe CGI07ALP Operator's Manual

Grill island
Hide thumbs
Table of Contents

Advertisement

Quick Links

Grill Island
Model CGI07ALP
NOTE: Complete Island Kit requires 3 boxes
Grill Information Center:
Call us first if you have any problem with
this product. We can help you with ques-
tions about assembly and grill operation or
if there are damaged or missing parts
when you unpack this unit from the ship-
ping box. Please call before contacting
your local retailer.
1- 800-761-5456
8am-4:30pm CST, Monday through Friday
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of grill)
OPERATOR'S MANUAL
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire (such as vinyl or wood siding, fences
and overhangs) or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
Ÿ
Combustion byproducts produced when using
this product contain chemicals known to the
State of California to cause cancer, birth
defects, or other reproductive harm.
Ÿ
This product contains chemicals known to
the State of California to cause cancer, birth
defects, or other reproductive harm.
Manual # P80170007A -
!
Date:2008/08/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CGI07ALP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GrandCafe CGI07ALP

Summary of Contents for GrandCafe CGI07ALP

  • Page 1 OPERATOR'S MANUAL Grill Island Model CGI07ALP NOTE: Complete Island Kit requires 3 boxes WARNING Grill Information Center: Ÿ Failure to comply with these instructions could Call us first if you have any problem with result in a fire or explosion that could cause this product.

  • Page 2: Table Of Contents

    If you smell gas: qualified gas technician only, using a NG Shut off gas to the appliance. Conversion Kit purchased from Grand Hall. Extinguish any open flame. • Never use your gas grill in a garage, porch, shed, Open lid.

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety To expedite the assembly process follow these WARNING general guidelines: Tools Required for Assembly include: Failure to comply with these instructions may • protective work gloves • result in a hazardous situation which, if not protective eyewear •...
  • Page 4 Hardware Pack Parts List for Model CGI07ALP PART # PART DESCRIPTION QTY PURPOSE OF PART P06024005A Hardware Pack For use in assembly (Grill and Range) S112G04061 Phillips Head Screw 1/4"x3/8" Install Cart Frames to Left / Right Bowl Panels Already packed in the Faucet Assembly Kit Box...
  • Page 5 Parts Diagram for Model CGI07ALP Grill 60 61...
  • Page 6 Parts Diagram for Model CGI07ALP Range 13 5...
  • Page 7 Parts Diagram for Model CGI07ALP Island...
  • Page 8 Parts List for Model CGI07ALP Grill DESCRIPTION KEY# Lid Assembly P00147063A Temperature Gauge P00601071A Lid Handle P00205086B Protective Pad P05518011 I Cooking Rack/Secondary P01516004B Cooking Grid P01604013B Cooking Grid P01604031B Burner/Main P02008032A Infrared Burner Assembly P02005010A Thermocouple P05305019A Savor Plate®...
  • Page 9 Parts List for Model CGI07ALP Grill DESCRIPTION KEY# Hose Holder P05536001A Drawer P01901008B Drawer Handle P00215032A Protective Cap A P05535008I Name Plate P00407010D Level Adjuster P05322003A Door Bracket, Left P03302027C Door Bracket, Right P03302028C Heat Insulating Spacer P06801022A Savor Plate Bracket, Front...
  • Page 10 Parts List for Model CGI07ALP Range DESCRIPTION KEY# P0014605AY Griddle P05702020E Cover Hook P05514133A Burner/Griddle P02008046B Side Burner Body P01106040B Grease Tube P02721042B Frame For Griddle Burner P0071325FC Griddle Bracket P03328041C Lighting Tube P05507139A Bowl Panel, Top P0073941DC Side Burner Pot Support...
  • Page 11 Parts List for Model CGI07ALP Range DESCRIPTION KEY# Refrigerator P05335018A Door For Refrigerator P04301031A Door Handle For Refrigerator P00201001C Door Bracket, Upper P03302029C Door Bracket, Bottom P03302030C Refrigerator Bracket, Left P03329010D Refrigerator Bracket, Right P03329011D Level Adjuster P05322003A Door Bracket, Right...
  • Page 12 Y0250122 Rotisserie Assembly Parts Diagram Y0250122 Rotisserie Assembly Parts List PART# DESCRIPTION P05508092A Rot. Bushing S196G06081 Rot. Thumbscrew 3/8"x1/2" P05508091A Rot. Collar P05508175A Rot. Spit P05508090A Rot. Holding Fork P05508174A Rot. Motor Bracket P07101042B Rot. Motor/AC S112G10121 Rot. Screw#10-24x3/4"UNC S411G03081 Rot.

  • Page 13: Assembly Instructions

    Assembly Instructions Install Cart Frame (For Range Model) Align the 4 holes in the Cart Frame and the Range, Right (Front/Rear) Cart Legs . Insert the 4 Phillips Head Screws 1/4"x1/2" and tighten securely. Phillips Head Screw 1/4"x3/8" Qty.4 Part # S112G04061 Install Cart Frame (For Grill Model) Align the 4 holes in the Cart Frame and the Grill Left Cart Legs (Front/Rear).
  • Page 14 Option 2 Note: All measurements are in inches Install Regulator with Hose to Hose holder. (Island Assembly Set - For Option 1 and 2). With the help of an assistant, proceed with the following steps. Remove the 2 screws and Upper Right Cart Panel. Detach the Regulator with Hose from the Hose Holder and insert the Regulator Hose end through the opening.
  • Page 15 Install Gas Tank to Front & Side Tank Trays. (Island Assembly Set - For Option 1). Slide open the Tank Tray doors (as shown). Turn your LP Gas Tank Valve clockwise to the closed or OFF positon. Unscrew the Wing Bolt from right bracket of tank holder. Place LP Gas tank into tank holder on the Tank Tray.
  • Page 16 Install Faucet Assembly Slide open the Cart Basket Door and from the underside of the Sink Frame unscrew and remove the Left Cart Rear Panel as shown. (See fig. 1). Loosen 4 preassembled Wing Bolts 1/4"x1/2" half way and gently push the Left Cart Rear Panel to slide along the designated slot to remove.
  • Page 17 CGI07 Range Install Ignitor Battery Control Panel Unscrew Ignitor Cap from Control Panel. Place supplied AA battery into the Ignitor Slot with positive pole facing you. Position the Cap and Spring over the AA battery and tighten onto Control Panel. Repeat to install the other AA battery into the Ignitor Slot.
  • Page 18 Install Pot Support and Griddle Place the Side Burner Cap onto the side burner bowl Pot Support insert. Place the Pot Support on the bowl panel Top Panel. Place the Griddle on the Bowl Panel Top Panel. Side Burner Cap Griddle Adjust Island Assembly Set (on uneven surface position).

  • Page 19: Use & Care Instructions

    USE AND CARE INSTRUCTIONS Water supply and drainage system for Dual Function use Island Assembly. Swivel and adjust the flexible faucet neck as needed to direct the spray head. California Proposition 65 Warning This Serving Cart is provided with an optional Faucet faucet and water supply hose.
  • Page 20 NG Conversion Kit purchased from Grand Hall. Never light your gas grill with the lid closed or before checking to ensure the burner tubes are fully...
  • Page 21 USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs LP Gas Model only: Ÿ Secure a 20lb LP Gas Tank to Gas Grill or Many retailers that sell grills offer you the option of Range replacing your empty LP Gas tank through an ex- change service.
  • Page 22 USE AND CARE INSTRUCTIONS Check all connections for LP Gas Leaks Check that the end of each Burner Tube is properly located over each Valve Orifice Never test for leaks with a flame. Prior to first use, 1. Open lid at the beginning of each season, or every time 2.
  • Page 23 USE AND CARE INSTRUCTIONS Burner Control Knobs on Control Panel Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, Grill burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List.

  • Page 24: Lighting Instructions

    USE AND CARE INSTRUCTIONS Troubleshooting Manually Lighting Your Grill By Paper Match If the grill fails to light : To light your gas grill by match, insert a match into the Turn gas off at source and turn Control Knobs to OFF. Lighting Stick and follow steps 1 through 6 of the Grill Wait at least 5 minutes for gas to clear, then retry.
  • Page 25 USE AND CARE INSTRUCTIONS WARNING Keep any electrical supply cord and the fuel supply hose away from any heated surface. CORRECT ROTISSERIE USE Read all instructions before initial use. IMPORTANT: When using electrical appliances, basic safety precautions should always be used. The Rotisserie Motor is set for 120V, 60Hz AC current.

  • Page 26: Rotisserie Instruction

    Rotisserie Instructions 1. Remove all components from the carton. Attach the Motor Bracket on the outside of the right grill bowl panel. Align the two holes of the Bracket with the holes on the grill bowl. Tighten securely using two Screws #10-24x3/4" UNC, Plain Washers and Nuts provided.
  • Page 27 Install the AC (alternating current) Rotisserie Motor onto the Motor Bracket as shown below. Be sure the Motor attaches to the Bracket with the electrical cord down. This installation insures that once the Spit is inserted into the Motor it will also rest securely into the slot of your grill bowl. Rotisserie Motor Rotisserie Spit must rest securely into the slot of your grill bowl.

  • Page 28: Cleaning And Maintenance

    ® Replace Savor Plates and Cooking Grids. CLEANING AND MAINTENANCE Reconnect the gas source and observe the Proper care and maintenance will keep your grill in top Burner flame for correct operation. operating condition and prolong its life. Follow these cleaning procedures on a timely basis and your grill will Cleaning Exterior Stainless Steel Surfaces: stay clean and operate with minimum effort.
  • Page 29 CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must use, we recommend you also complete the following clean the Burner Tubes as follows at least once a month steps to help prolong Burner life.
  • Page 30 Cooking Instructions Indirect Cooking using Main Burners Burn-Off Before cooking on your gas grill for the first time, you The indirect cooking method can also be used with should "burn off" the grill to eliminate any odor or the supplied Cooking Grids. To cook indirectly, the foreign matter.
  • Page 31 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on HIGH, close the Lid and preheat T-bone steak Medium: 10-14 minutes your grill 3 to 5 minutes.
  • Page 32 Guide to Searing using the Infrared Cooking Zone • Important notes about using the Infrared Burner Once lit, leave the Infrared Burner on High and sear both sides of meat using the guidelines below. Whether you are a seasoned chef or a newcomer to gas •...
  • Page 33 Guide to Roasting and Baking Using the Main Burners An Important Note About Heat Settings Food preparation Trim meat of excess fat. Truss meat and poultry with The suggested heat settings shown are approximate. There are many factors such as outside temperature, cooking string to retain shape if desired.
  • Page 34 Guide to Rotisserie Cooking Guide to Smoking Slow Cooking with a Rotisserie Preparing to Smoke Rotisserie cooking produces foods that are moist, Smoking gives food a distinctive, delicious flavor. You will flavorful and attractive. The rotisserie system is most find a variety of wood chips available for use in smoking commonly used for cooking meat or poultry and is grilled foods.
  • Page 35 OPTIONAL GRILL ACCESSORIES Cast-Iron Cooking Pan with Lid This cast iron pan conducts heat wonderfully and cooks evenly, making this the ideal accessory for baking and roast- ing on your new grill. Prepare pizza, potatoes, stew, corn bread and desserts. Can be used in place of 1 grid and Flame Tamer or use on...
  • Page 36 A low volume of sound is normal and will not NG Conversion Kit purchased from Grand Hall. interfere with the operation of your grill. Loud or excessive regulator humming and/or low flow and...
  • Page 37 Question: To slow the rusting process on steel Cooking Grids The Regulator and Hose supplied with my gas grill (select models) we recommend greasing the Cooking does not fit the older LP Gas tank I’ve used for Grids before and after each cookout. Use a brush to years.
  • Page 38 Grand Hall Limited Warranty Grand Hall Enterprise Co., Ltd. will warrant to the ORIGINAL PURCHASER of this gas grill that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly: Full Warranty on Grill –...
