NetLink 72-0064-00-F User Manual

Earpiece
LCD Panel
Headset Jack
Line Indicators
Status Indicators
Power
Start
End
Next Menu
Previous Menu
Line
Hold
Function
Volume
Microphone
On/Off Press and hold PWR. Two chirps on, one chirp off
Make a call Press START to get dial tone.
Hang up Press END. Be sure to do this at the end of
each call.
Answer call Press START. Line indicator comes on steady
when the call is answered.
Answer Press HOLD to put your current call on hold, or
second call END to hang up. Press LINE + the digit that is
flashing.
Hold Press HOLD
Take off Hold Press LINE followed by the digit for the line on
hold, which will be flashing.
Mute On/Off Press FCN and then 1
Function Pressing FCN while off hook allows you to scroll
through menu screens.
User Options Press FCN while on hook to change handset
settings.
Adjust Volume Press VOL while in a call to toggle between base
and louder level
Status/Tone Indicators
NO SVC
An alarm sounds when the Wireless Telephone
Alarm/Restore
cannot receive or place calls. You may be out-
side of the coverage area. Walk back into the
covered area. A restore tone indicates service is
re-established.
BATT Your Battery Pack charge is low. Your Battery
Beep
Pack needs to be recharged or replaced.
MSG
You have a voice mail message.
Note: The functions on your Wireless Telephone may differ from the
above. Contact your system administrator for custom setting information.
NetLink

Wireless Telephone

Ext. 123
Ext. 123
1
1 2 3 4 5 6 7 8 9
MSG
NO SVC BATT MSG
PWR START END
1 2 3
ABC DEF
4 5 6
GHI JKL MNO
7 8 9
PRS TUV WXY
0
#
HOLD FCN VOL LINE

User Guide

72-0064-00-F
Tips For Use
• Before you use the Wireless Telephone, the Battery Pack must be
charged. See Battery Packs.
• You can only use the Wireless Telephone with your facility's tele-
phone system. It is not a public cellular phone.
• The PWR key turns the Wireless Telephone on and off. The START
and END keys begin and end calls. When you finish a call, press the
END key, not the PWR key.
• Keep the Wireless Telephone away from your ear when it is ringing.
• The microphone is in the telephone's lower right corner. This is a
sensitive microphone that works well when the telephone is correctly
positioned on your ear. There is no need to speak directly into the
microphone, but do not cover it with your hand or cheek when talk-
ing on the Wireless Telephone.
• The Wireless Telephone's LCD panel displays information about the
status of your Wireless Telephone and prompts you about features.
• If the Wireless Telephone's Battery Pack is low, you will hear a soft
beep and see the BATT or Low Battery message in the display.
• Improper disposal of Battery Packs can damage the environment.
Dispose of batteries properly.
• You can control the Wireless Telephone's volume level and the type
of ring. See Setting User Preferences.
• To protect the Wireless Telephone, use a carrying case.
General Care of the Wireless Telephone and Chargers
The Wireless Telephone and Chargers have been designed to withstand
the wear and tear of normal use; however, avoid dropping the Wireless
Telephone or knocking it against hard surfaces. Carrying the Wireless
Telephone in a holster or carrying case will help to protect it.
There are no serviceable parts in the Wireless Telephone or Chargers.
You should not open the Wireless Telephone case nor disassemble the
Chargers. Doing so will void your warranty.
Turn off the Wireless Telephone and unplug the Charger before you
clean them. Never immerse either in water. Clean the exterior surfaces,
including the charging contacts, with a cloth that has been slightly mois-
tened with water. Take care not to exert undue pressure on the Charger
electrical contacts while wiping.
Wiping the handset surface with a water-dampened cloth or paper towel
will remove most films or residues. If the soiling is too stubborn for
plain water, a mild detergent solution may be used. Be sure to wipe
away any detergent residue with a clean water-dampened cloth.
The Wireless Telephone may be cleaned with any general-purpose house-
hold glass and surface-type cleaner. DO NOT SPRAY THE HANDSET
DIRECTLY! Isopropyl alcohol may be used occasionally applied by a
cloth or paper towel. When using alcohol, do not rub the keypad charac-
ters vigorously. Doing so will significantly degrade legibility.
Do not use any chemical cleaners. They can harm the plastic shell. If
necessary, a small amount of mild surface or window cleaner can be
applied to the cloth, but do not spray the cleaner onto the Wireless
Telephone or Charger.
It is recommended that standard acceptance procedures be followed prior to operating this
equipment in proximity of life-support systems.
To minimize risk of interference, pacemaker users should not carry the Wireless Telephone
next to the pacemaker.
Earpiece may retain magnetic objects.
Operation of the Wireless Telephone may produce an audible noise noticeable to hearing
aid users. It is recommended that a SpectraLink headset be used by hearing aid users.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
