Satechi Wireless Mini Router Quick Setup Manual

Hide thumbs
1
2
3

Advertisement

Table of Contents

WIRELESS
MINI ROUTER QUICK SETUP GUIDE
A. SETUP
Wireless-N
1.
Plug the Wireless Mini Router into the wall. After approximately one minute, the
WLAN light on the Mini Router will turn on — the Mini Router is now broadcasting a
wireless network called "Wireless-N." In your computer or other internet-accessible
device, go to your wireless settings and connect to the "Wireless-N" network. To do
this, you may have to disconnect from your current network. If your computer asks
for a PIN or to "set up" your network, click "connect without setting up."
2.
Once connected to "Wireless-N," in your internet browser navigate to the address
"192.168.10.253" If prompted to enter a username and password, enter "admin" in
both fi elds. This will direct you to the Mini Router's settings page.
3.
Click "Wizard" in the left sidebar. You will be directed to the mode select menu. Once
you select a mode, you will be guided through the setup process for that mode. After
mode setup is complete, you will need to disconnect from the "Wireless-N" network
and reconnect to your existing or newly-created network before you can use the
internet. More information about the Wireless Mini Router's modes can be found in
Section B "Modes" of this Quick Setup Guide.
User: admin
Pass: admin

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wireless Mini Router and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Satechi Wireless Mini Router

  • Page 1 A. SETUP Wireless-N Plug the Wireless Mini Router into the wall. After approximately one minute, the WLAN light on the Mini Router will turn on — the Mini Router is now broadcasting a wireless network called “Wireless-N.” In your computer or other internet-accessible device, go to your wireless settings and connect to the “Wireless-N”...

  • Page 2: Access Point

    B. MODES 1. Router Modem Internet 2. Repeater 2. Repeater Router Internet 3. Access Point Internet 4. Bridge SSID SSID Router Internet 5. Client Router Internet Router: In this mode, the Mini Router is connected to a modem via ethernet cable and broadcasts a wireless network with the SSID [network name] of your choosing.
  • Page 3 C. RESET If you wish to change the mode of your Wireless Mini Router or access the Router’s settings page, first you must reset the Router to its factory default. The following steps will guide you through this process. 1. With the Mini Router plugged into an outlet, locate the small “Reset” button on the side of the Router.
