- Page 1 WT-2000PCI 802.11g Turbo Wireless LAN PCI Card User’s Manual AirLive WT-2000PCI User’s Manual...
- Page 2 4. Consult the dealer or an experienced radio technician for help. FCC Caution This equipment must be installed and operated in accordance with provided instructions and a minimum 20 cm spacing must be provided between computer AirLive WT-2000PCI User’s Manual...
- Page 3 Netherlands, Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. EU Countries Not intended for use None. AirLive WT-2000PCI User’s Manual...
-
Page 4: Table Of Contents
3.2.1.3 802.1x Setting-Certification ..........21 3.2.1.4 802.1x Setting-CA Server ..........23 3.3 Link Status ....................24 3.4 Statistics ....................... 25 3.5 Advance......................25 3.6 About ......................28 3.7 Turbo Mode....................28 3.8 WMM Function ..................... 29 TROUBLESHOOTING ................32 AirLive WT-2000PCI User’s Manual... -
Page 5: Introduction
This card is cost-effective, together with the versatile features; it is the best solution for you to build your wireless network. AirLive WT-2000PCI User’s Manual... -
Page 6: Features
Weight: 46g • Temperature: 32~131°F (0 ~ 55°C) • Humidity: Max. 95% (NonCondensing) • Certification: FCC, CE 1.3 Package Contents Before you begin the installation, please check the items of your package. The package should include AirLive WT-2000PCI User’s Manual... - Page 7 • One PCI Card • One CD (Driver/Utility/User’s Manual.) • One Quick Guide If any of the above items is missing, contact your supplier as soon as possible. AirLive WT-2000PCI User’s Manual...
-
Page 8: Installation Procedure
Secure the antenna to the antenna connector of the card. Turn on the computer. 2.2 Install the Driver and Utility “Found New Hardware Wizard” is displayed after the PCI card is installed and the computer is restarted. Click “Cancel”. AirLive WT-2000PCI User’s Manual... - Page 9 Insert the Installation CD to your CD-ROM Drive. Execute the “setup” program. Click “Next” to process the installation if you accept the license agreement. The system starts to install the software of the card. AirLive WT-2000PCI User’s Manual...
- Page 10 The system will automatically detect the card and display “Hardware Installation” screen. Click “Install” to continue. Please click “Finish” to complete the installation. AirLive WT-2000PCI User’s Manual...
-
Page 11: Configuration Utility
Use Zero Configuration as Configuration Utility Select “Use Zero Configuration as Configuration Utility” to use Windows XP built-in wireless configuration utility (Windows Zero Configuration) to configure the card. Exit Select “Exit” to close the Configuration Utility tool. AirLive WT-2000PCI User’s Manual... - Page 12 First Way Right click the icon in the system tray and select “Use RaConfig as Configuration Utility”. Second Way Right-click the icon and select “View Available Wireless Networks”. Click “Advanced”. AirLive WT-2000PCI User’s Manual...
- Page 13 Uncheck “Use Windows to configure my wireless network settings” to enable the utility for the card. Note: If “Wireless Zero Configuration” is enabled, you can only configure the advance setting or check the link status and statistics from the configuration utility of the card. AirLive WT-2000PCI User’s Manual...
-
Page 14: Site Survey
Rescan Button Click “Rescan” button to collect the new information of all the wireless networks nearby. Connect Button Click “Connect” to connect to the selected network. Add to Profile Button Add the selected network to Profiles list. AirLive WT-2000PCI User’s Manual... -
Page 15: Profile
This sign indicates the activated profile is not been connecting. Add/Delete/Edit Button Click these buttons to add/delete/edit the selected profiles. Activate Button Click “Activate” to connect to the selected profile. When a profile is activated, the card will be initially connected to the profile. AirLive WT-2000PCI User’s Manual... -
Page 16: 1Configure The Profile
3.2.1 Configure the Profile AirLive WT-2000PCI User’s Manual... -
Page 17: Configuration
802.11 G only – This card can be compatible with both 802.11g and 802.11b wireless stations. If there are only 802.11g wireless stations in the network, you can set the card to this mode. Preamble The preamble defines the length of the CRC block for communication AirLive WT-2000PCI User’s Manual... - Page 18 256 to 2346 bytes. Minor change is recommended. Channel This setting is only available for Ad Hoc mode. Select the number of the radio channel used for the networking. The channel setting should be the same with the network you are connecting to. AirLive WT-2000PCI User’s Manual...
-
Page 19: Authentication And Security
Standard (AES). AES is required to the corporate user or government users. The difference between WPA and WPA2 is that WPA2 provides data encryption via the AES. In contrast, WPA uses Temporal Key Integrity Protocol (TKIP). AirLive WT-2000PCI User’s Manual... - Page 20 For example: “0123456aef“ or “test1”. 128-bit – Input 26-digit Hex values (in the “A-F”, “a-f” and “0-9” range) or 13-digit ASCII characters (including “a-z” and “0-9”) as the encryption keys. For example: “01234567890123456789abcdef“ or “administrator”. AirLive WT-2000PCI User’s Manual...
- Page 21 Access Point Windows 2000 IAS (Internet Authentication Service) (1) Client requests to login the (3) Send username, password to network. RADIUS server. (4) Approve or deny user (2) Login with username, login to the LAN. password. AirLive WT-2000PCI User’s Manual...
-
Page 22: 802.1X Setting-Certification
A client certificate is required for TLS, and is optional for TTLS and PEAP. This forces a client certificate to be selected from the appropriate Windows Certificate Store and made available to the RADIUS server for certification. AirLive WT-2000PCI User’s Manual... - Page 23 <name of the user>@<user’s home realm>. The user’s home realm is optional and indicates the routing domain. Password The password used for authentication. It may contain up to 63 ASCII characters and is case sensitive. AirLive WT-2000PCI User’s Manual...
-
Page 24: 802.1X Setting-Ca Server
(e.g. zeelans.com, where the server is blueberry.zeelans.com) but it may be any name used in the certificate name field. AirLive WT-2000PCI User’s Manual... -
Page 25: Link Status
This indicator helps to find the proper position of the wireless device for quality network operation. Noise Level Display the noise level in the wireless environment. AirLive WT-2000PCI User’s Manual... -
Page 26: Statistics
This option enables you to view the statistic information of the connection including transmit statistics and receive statistics. You may reset the counters by clicking ”Reset Counter”. Advance This option enables you to configure more advanced settings, for example: wireless mode, protection mode and etc. AirLive WT-2000PCI User’s Manual... - Page 27 When the wireless mode is “802.11 B only”, the maximum data rate is 11Mbps (11b) so that there are only “Auto/1/2/5.5/11Mbps” options you can select. Tx BURST Tx Burst enables the card to deliver the better throughput in the same period and environment. AirLive WT-2000PCI User’s Manual...
- Page 28 The Cisco AP can perform monitoring measurements through the Measurements CCX-compliant clients on the non-serving channels when this parameter is enabled. It limits the channel measurement time. The default value is 250 Limit xxx milliseconds (0-2000) milliseconds. AirLive WT-2000PCI User’s Manual...
-
Page 29: About
Mode) enables higher throughput than IEEE 802.11g standard (Up to 54Mbps). When the card is connecting to the Routers or APs with the proprietary Turbo Mode feature, the Turbo Mode will be enabled automatically without any configuration. AirLive WT-2000PCI User’s Manual... -
Page 30: Wmm Function
When the card is connected to the AP or Router with WMM function, you can enable the function of the card by following the steps below. In the Desktop of the computer, right click “My Network Places” and select “Properties”. AirLive WT-2000PCI User’s Manual... - Page 31 Right Click the “Wireless Network Connection” and select “Properties”. Click “Configure…”. Select “Advanced” page, enable the “WMM Capable”. AirLive WT-2000PCI User’s Manual...
- Page 32 AirLive WT-2000PCI User’s Manual...
-
Page 33: Troubleshooting
SOHO operation. What is Infrastructure？ An integrated wireless and wireless and wired LAN is called an Infrastructure configuration. Infrastructure is applicable to enterprise scale for wireless access to central database, or wireless application for mobile workers. AirLive WT-2000PCI User’s Manual... - Page 34 Even if one or more bits in the chip are damaged during transmission, statistical techniques embedded in the radio can recover the original data without-the need for retransmission. To an unintended receiver, DSSS appears as low power wideband noise and is rejected (ignored) by most narrowband receivers. AirLive WT-2000PCI User’s Manual...
- Page 35 If a receiver is not tuned to the right frequency, a spread –spectrum signal looks like background noise. There are two main alternatives, Direct Sequence Spread Spectrum (DSSS) and Frequency Hopping Spread Spectrum (FHSS). AirLive WT-2000PCI User’s Manual...
