ENFORCER VA-2101B-WQ Manual

ENFORCER VIDEO AMPLIFIER

Troubleshooting:

Video Amplifier does
not function correctly
Power LED indicator not lit
Also Available from SECO-LARM:
Passive VGA Balun Passive Video Balun
EVT-SBP-GQ
SECO-LARM has a complete line of security products.
Please visit www.seco-larm.com for more information.
WARRANTY This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM's obligation is
limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect,
repair, or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines
that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only,
at SECO-LARM's option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential
personal or property damages of any kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right
to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2008 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in
whole or in part, without the written permission of SECO-LARM.
SECO-LARM ®
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
4
• Make sure the power, input and output cables are
connected firmly to the distributor.
• Make sure the video input device is turned on.
• Make sure the video output device is turned on.
• Test the coaxial cable between the video input and the
amplifier to make sure it is functional.
• Test the coaxial cable between the video output and the
amplifier to make sure it is functional.
• Make sure power is connected to the amplifier.
BNC-to-VGA Converter
EVT-PB1Q VC-1BAQ
Website: www.seco-larm.com
@
E-mail: sales seco-larm.com
SECO-LARM U.S.A., Inc.
VA-2101B-WQ
1 Video Input
1 Video Output
The ENFORCER VA-2101B-WQ and VA-2404B-WQ Video Amplifiers are the ideal way
to boost the strength of video signals. Using the included 12VDC power adapter, video
signals are amplified for transmission distances of up to 3280' (1000m). Brightness and
sharpness adjustments can be made independently for each channel to provide fine-
tuning of video signals.
PITSW4
mi-VA-2X0XB-WQ.docx
MANUAL
Video Amplifiers

Transmission distance

up to 3280' (1000m)
VA-2404B-WQ
4 Video Inputs
4 Video Outputs
