etyBLU Dual Mode Noise-Isolating Headset User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Dual Mode

Noise-Isolating

Headset

U s e r M a n u a l

Table of Contents

Need help?

Do you have a question about the Dual Mode Noise-Isolating Headset and is the answer not in the manual?

Questions and answers

Summary of Contents for etyBLU Dual Mode Noise-Isolating Headset

Page 1 Dual Mode Noise-Isolating Headset U s e r M a n u a l...
Page 3: Table Of Contents
Table of Contents Introduction................4 Included..................5 Bluetooth Profiles ..............5 Identification ................6 Dual Modes–Two Ways to Use..........7 Pairing ..................8 Charging .................. 9 Earpiece Insertion/Removal............10 BLUmaxx Connect/Disconnect ..........11 Multi-Function Button (MFB)..........12-13 Earpiece Filter ................14 Caution ..................15 FCC Info ................16-17 Proper Care ................18 About Etymotic Research............19 Warranty ................19 LED Chart ................20...
Page 4: Introduction
The etyBLU headset was developed by Etymotic Research for use in high levels of background noise. Another Etymotic first.
Page 5: Included
Included • etyBLU Dual-Mode Noise-Isolating Headset • BLUmaxx Quick-Connect Mic • Earloop • Assorted eartips • Windscreen • Filter changing tool with replacement filter • Storage case • USB charging cable Bluetooth Profiles Compliant with Bluetooth® Core Specification 2.1, Headset 1.1 and Handsfree 1.5 profiles (supports Bluetooth 1.1 and...
Page 6: Identification
Identification etyBLU with BLUmaxx connected and earloop No boom, no earloop Internal Microphone A. Eartip B. Speaker C. Multi-Function Button (MFB) Noise-Canceling D. Volume Up/Down Microphone E. Optional Earloop F. Earloop Holder G. Jack for BLUmaxxMic and Charging Cable H. Quick-Connect BLUmaxxMic...
Page 7: Dual Modes-Two Ways To Use
Dual Modes—Two Ways to Use Internal Mic Mode The earpiece is designed to be self-supporting in the ear canal, so the earloop is optional. Push the earloop through the earloop holder and adjust for a secure fit. BLUmaxx Mic Mode Exceptional clarity in noisy environments.
Page 8: Pairing
5 minutes. • Activate the search for BT and/or audio devices on the phone • When the etyBLU is found, the phone will display “etyBLU.” Scroll to it and press OK to confirm pairing.
Page 9: Charging
80% charge: 1 hour Charging with the USB connecter (included) • Remove the BLUmaxx Mic prior to charging • Plug the connector into the etyBLU headset as shown. • Plug USB end of the charging cable into a computer USB port as shown.
Page 10: Earpiece Insertion/Removal
Insertion Important: Sound quality and noise isolation depend on a good eartip seal. • Carefully insert the earpiece while pulling up and out on the back of the ear. For a video on proper • Twist the earpiece while inserting earphone insertion go to www.etymotic.com until outside noise is blocked out.
Page 11: Blumaxx Connect/Disconnect
BLUmaxx Connect/Disconnect NOTE:The BLUmaxx Mic can quickly connect or disconnect without disconnecting a call. Hold here to connect/disconnect Connector Noise-canceling microphone To Connect 1.The plug on the BLUmaxx Mic is designed to connect to the headset only one way. Do not force the plug into the jack.
Page 12: Multi-Function Button (Mfb)
Multi-Function Button (MFB) Power ON PRESS the MFB for 4 seconds to Power On. Blue LED is solid for one second while powering ON. Blue LED blinks when the headset is ON. Power OFF PRESS the MFB for 4 seconds to Power Off.
Page 13: Multi-Function Button (Mfb)
Multi-Function Button (MFB) The following features depend on phone support: Redial PRESS and HOLD the MFB (long press) for one second. Voice Call PRESS the MFB quickly (short press) to make a voice call. Voice Call works when the unit is in standby. Transfer a Call Double PRESS the MFB (two quick presses to the Handset...
Page 14: Earpiece Filter
Earpiece Filter The earpiece in the etyBLU headset has a special filter that smoothes the frequency response and prevents earwax from entering the earphone.The filter is located at the end of the earphone and is visible when the eartip is removed.
Page 15: Caution
Consult an audiologist or physician if you have excessive ear wax, difficulty inserting the eartips, or discomfort after prolonged use.The etyBLU dual-mode headset excludes most external sounds. Always use extreme caution while using any headset when operating a motorized vehicle.
Page 16: Fcc Info
FCC & Other Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation.These limits are designed to provide reasonable protection against harmful...
Page 17 FCC & Other Information FCC Health and Safety Information Your device is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
Page 18: Proper Care
Proper Care • Do not expose the headset to extreme temperatures. • Avoid dropping and strong impact. • Leave an eartip on the headset for shock protection. Cleaning/replacement of eartip • Clean or replace a flanged eartip prior to use by others. •...
Page 19: About Etymotic Research
About Etymotic Research Etymotic Research has spent twenty-five years developing in-ear technology for auditory research, precision monitoring and critical listening.Etymotic has developed many innovative hearing technologies available today. Etymotic’s products are used by musicians and others who insist on superior sound quality. Etymotic means“true to the ear.”...
Page 20: Led Chart
Charge complete Yellow LED off ETYMOTIC RESEARCH INC. 61 Martin Lane • Elk Grove Village, IL 60007 www.etymotic.com • 1-888-389-6684 ©2008. etyBLU and BLUmaxx are trademarks of Etymotic Research, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc. ER089401 03/10...
