CRESCENT CUBER
EISMASCHINE FÜR SICHELFÖRMIGE EISWÜRFEL
PRODUCTOR DE FORMAS DE HIELO
DISTRIBUTEUR DE CUBELETS EN DEMI-LUNE
CUBETTATRICE MEZZALUNA
HALVE-MAANVORMIGE IJSMACHINE
INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
NOTICE D'UTILISATION
MANUALE DI ISTRUZIONI
GEBRUIKSAANWIJZING
FOR END USER
FÜR DEN ENDBENUTZER
PARA EL USUARIO FINAL
POUR L'UTILISATEUR FINAL
PER L'UTENTE FINALE
VOOR EINDGEBRUIKER
89/336
ISSUED: April 11, 2008
73/23
REVISED: October 29, 2008
HOSHIZAKI
KM-320MAH-E
KM-515MAH-E
KM-650MAH-E
KM-1301SAH-E
91A1NK10B
