Summary of Contents for Mobridge Bluetooth Gateway
- Page 1 Bluetooth Gateway for Audi User Manual...
- Page 3 Welcome Congratulations on purchasing a mObridge Bluetooth Gateway for your Audi.The mObridge Bluetooth Gateway allows for full hands-free phone control using the existing radio and steering wheel controls in your Audi vehicle. 2010 Fiberdyne Systems Pty Ltd...
- Page 4 About this Manual This booklet contains important information and warnings on using your mObridge Bluetooth kit in your Audi. The booklet is designed to fit into your Audi User Manual folder.We recommend adding this booklet to your Audi User Manual folder for further reference.
-
Page 5: Table Of Contents
Contents Getting Started Operation: Head Unit Supported Equipment Making a phone call from the phonebook Features Dialing a telephone number Steering wheel controls Accepting an incoming call Head-Unit Control Ending a telephone call Base Model Radios Sending DTMF tones Call Lists Pairing your Bluetooth Phone Software Updates Connecting &... -
Page 6: Getting Started
Getting Started Supported Equipment Features The mObridge Bluetooth kit supports Hands free functionality the following equipment: Dial Numbers RNS-E Access your phone book BNS 5.0 Answer and Reject Incoming Calls Chorus II+, Chorus III On-board DSP (digital signal processor) for advanced noise-free audio. -
Page 7: Steering Wheel Controls
Steering Wheel Controls Applies to vehicles: with steering wheel controls. The mObridge Bluetooth kit can be controlled via the steering wheel controls in your vehicle. An example of the steering wheel controls is found in the diagram below. Your controls may differ slightly from shown, but the basic operation will remain the same. -
Page 8: Head-Unit Control
A maximum of 5 Bluetooth devices can be paired Using the Bluetooth features of your with the mObridge system at any time. To pair phone, perform a search for new devices. an additional device, one or more of the existing... -
Page 9: Connecting & Disconnecting The Phone
– for these phones you will need to connected. It will do this until a connection manuallyconnect tomObridgeusing the controls has been made. When ignition is switched on your phone. off and the key is removed, mObridge will PAIRING YOUR BLUETOOTH PHONE... -
Page 10: Operation: Combi-Instrument Display
O peration: Combi-instrument Display Applies to vehicles: with DIS display Menu Structure Applies to vehicles: All – except A4(B8), A5, Q5 Main Menu The following menus are available in the Telephone menu on the combi-instrument. When a phone is connected the entire menu is available. Phonebook See page 08 NOTE... -
Page 11: Making A Phone Call From The Phonebook
Making a Telephone Call From the Phonebook Applies to vehicles: All It is possible to dial a number from the phonebook of the connected phone using the steering wheel buttons. NOTES If there are more than 1 phone numbers associated with this entry, select the Your Bluetooth phone must support phonebook number use wish to dial using the Scroll sync to use this feature. -
Page 12: Accessing Call Lists
Accessing Call Lists Using the Steering Wheel Applies to vehicles: All mObridge will synchronize the Last Dialled, Missed, and Answered Call lists with your phone. If a number is known from your phonebook, then the caller name will be displayed in addition to the number. -
Page 13: Changing System Settings
Volume level of ringing. phone is connected. Prompt Volume. 01 - 15 It is also possible to use the “mObridge Volume level of prompt beeps. Wizard” to change the system settings over a USB or Bluetooth connection. Please 01 - 63 consult the install manual for details. -
Page 14: Operation: Head Unit
O peration: Head Unit Applies to vehicles: with RNS-E, BNS 5.0, Concert III, Symphony III Making a telephone call from the phonebook Applies to vehicles: with RNS-E, BNS 5.0, Concert III, Symphony III Select the phonebook menu. Select the phonebook entry and number Memory Telephone - Mobiles you wish to dial... -
Page 15: Accepting An Incoming Call
Accepting/Rejecting an Incoming Call Applies to vehicles: with RNS-E, BNS 5.0, Concert III, Symphony III Select Answer to answer the call. Memory Telephone - Mobiles Select Reject to reject the call to voice mail. Telephone 0419376599 Dialling Phone Book John End call 11:33 Dial... -
Page 16: Call Lists
Call Lists Applies to vehicles: with RNS-E, BNS 5.0, Concert III, Symphony III Enter the phonebook menu, and select the call list you wish to view. In the call list, select the number to dial it. Memory Telephone - Mobiles NOTES Call List Cameron - 0417128642... -
Page 17: Software Updates
Your mObridge audio interface is warranted against any manufacturing defects for a period of 12 months from purchase.Any part of the mObridge audio interface may be replaced or repaired at the discretion of the manufacturer after such part is deemed to have a manufacturing fault. -
Page 18: Index
Any changes or modifications not expressly in a particular installation. If this equipment approved by mObridge, Inc. could void the user’s does cause harmful interference to radio or authority to operate this equipment. television reception, which can be determined... - Page 20 NORTH AMERICA Address 800 South Pacific Coast Highway Suite 8 - #348 Redondo Beach California 90277 Phone 1-888-766-2743 Inquiries sales@mobridge-usa.com ASIA-PACIFIC Address 2/88 Northgate Drv Thomastown Melbourne VIC 3074 Phone +61 3 9013 9758 Inquiries sales@mobridge.com.au EUROPE Address Marconiweg 15 3899 BR, Zeewolde The Netherlands...
