Summary of Contents for Sound Ordnance B-8P
- Page 1 b-8pt...
-
Page 2: Table Of Contents
Thank you for purchasing Sound Ordnance You re now ready to win the battle for great sound. To ensure safe operation, always follow the instructions and guidelines in this manual. Keep this manual handy for reference. www.soundordnance.com All rights reserved. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS The product s warranty is rendered void in cases of damage resulting from failure to comply with safety and operating instruc- tions. We do not accept any liability for consequential damages. We do not accept any liability for personal injury or damage to property caused by incorrect handling of the device or failure to observe the safety and operating instructions. -
Page 4: Setup And Installation
SETUP AND INSTALLATION To ensure proper operation, please read these instructions carefully before installing and using this powered subwoofer. These installation instructions do not cover all possible installation issues. If you re not conÛdent about installing your powered sub- woofer, call us at 1-800-955-9094. 1. -
Page 5: Connections
CONNECTIONS Do not use both low and high level inputs at the same time - connect only one or the other. Never run any wires underneath or outside the vehicle. NOTE: Be sure to follow speciÛc instructions included with your am- pliÛer installation kit (not included with this powered subwoofer). - Page 6 B-8P Connections and Controls FREQUENCY PHASE LEVEL 70Hz 200Hz 0° 180° HIGH LEVEL LINE IN INPUT POWER L– R– GND REM +12V FUSE 7.5A B-8PT Connections FUSE HIGH POWER LEVEL INPUT REMOTE LEVEL INPUT GND REM +12V CH1– –CH2 CH1+...
-
Page 7: Wiring
WIRING B-8P/B-8PT GND (ground) CAR STEREO RECEIVER – battery fuse RCA cables LEVEL INPUT GND REM +12V... -
Page 8: Controls And Setup
CONTROLS AND SETUP POWER MODE Set the switch to AUTO MODE is your system setup doesn’t have a remote wire, as with stock head units. (AUTO MODE) The subwoofer will turn on automatically when it detects an incoming signal (this feature only avail- able on the B8-PT). - Page 9 TROUBLESHOOTING PROBLEM CAUSE ACTION Unit will not • BAT+ wire not connected or • Check connections for turn on (no incorrect voltage REM wire proper voltage (11~16VDC) power LED not connected or incorrect indicator) voltage • GND wire not connected •...
-
Page 10: Specifications
SPECIFICATIONS B-8P B-8PT Maximum Output Power 160 W 250 W Continuous Output Power 80 W 120 W Frequency Response 20-200Hz 40-200Hz W Crossover Frequency 70-200Hz 80-200Hz Crossover Slope 6dB/octabe 18dB/octave Phase 0-180 degrees 0-180 degrees Fuse 1 x 7.5 amp... - Page 11 To ensure safe operation, always follow the instructions and guidelines in this manual. Keep this manual handy for reference. www.soundordnance.com All rights reserved. Manual revised December, 2010.
- Page 12 ™ Virtual Gateways LLC Limited Warranty (Valid Only in the U.S.A. and Canada) Virtual Gateways LLC (“Virtual”) warrants this Product (expressly excluding any accessories) against defects in material or workmanship as follows: Terms of warranty coverage: This warranty covers the product during the warranty period so long as the product is owned by the same individual whose name appears on the invoice received upon purchase of the product.
