Advance Multimedia Internet Technology CDW530AM Specifications

Specifications
Hardware & Port Configuration
Wireless WAN USB 2.0 for external HSPA modem
Ethernet WAN 1 x WAN RJ-45 port, 10/100Mbps
Ethernet LAN 1 x LAN RJ-45 port, 10/100Mbps
Antenna For 1.8 dBm di-pole antenna
WPS Button For WPS connection
Reset Button Reset router setting to factory default
LED Indication 3G / LAN / WAN / WiFi
Power Jack Power Jack, DC 5V/2A
Wireless LAN (WiFi)
Standard IEEE 802.11b/g/n (1x1) compliance
SSID SSID broadcast or in stealth mode
Channel Auto-selection, manually
Security WEP, WPA-PSK, WPA2-PSK
WPS WPS (Wi-Fi Protected Setup)
Functionality
PPP (for WCDMA/HSxPA/EVDO/Blackberry Phone)
Wireless WAN PPPoE (for iBurst)
DHCP Client (for Flash-OFDM/WM Phone)
Ethernet WAN PPPoE, DHCP client, Static IP, PPTP, L2TP
WAN Connection Auto-reconnect, dial-on-demand, manually
One-to-Many NAT Virtual server, special application, DMZ
SPI Firewall IP/Service filter, URL blocking, MAC control
DoS Protection DoS (Deny of Service) detection and protection
Management SNMP, UPnP IGD, syslog
Administration
Web-based UI, remote login, backup/restore setting
Environment & Certification
Device dimension (mm)
Package Information Package dimension (mm)
Package weight (g)
Operation Temp. Temp.: 0~40oC, Humidity 10%~90% non-condensing
Storage Temp. Temp.: -10~70oC, Humidity: 0~95% non-condensing
CE, FCC CE/FCC compliance
RoHS RoHS compliance
*Specifications are subject to change without prior notice.
Advance Multimedia Internet Technology Inc.
Tel: +886 (0)6 505 8026 Fax: +886 (0)6 505 3865
Web: http://www.zalip.com.tw For ODM biz: sales@amit.com.tw
No.28, Lane 31, Sec.1, Huandung Rd., Tainan Science Park, Sinshih Township, Tainan county 741, Taiwan (R.O.C.)
LOHASmart CDW V1.0
CDW530AM
1
1
1
1
1
1
1
(Optional)
(Optional)
129.5x 121x30
TBD
TBD
For Channel biz: info@zalip.com.tw
LOHASmart
WiFi Combo Gateway
CDW530AM
