- Page 1 TRIPLETT CamView W35 Security Camera Wrist Monitor Instruction Manual 84-889 6-10 PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 2 • Thank you for purchasing the Triplett CamView W35 CCTV Monitor. Please read the complete manual carefully before using the product. • To assure safe use of this product, please read the section on Safety carefully, and observe any Cautions or Warnings posted there and throughout this manual.
-
Page 3: Table Of Contents
Table of Contents Safety Information ................1 Introduction ..................2 Features ....................3 Included Items ..................4 Controls and Indicators ................5 Battery Information ................6 Installing and Charging the Batteries ............7 General Instructions ................8 Specifications ………………………...........9 Troubleshooting .................10 Warranty ....................11 Page 2 PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor... -
Page 4: Safety Information
1: Safety Information Dear Customer: For greatest safety and reliable operation, please follow these guide- lines for use and care of the product. Please retain these instructions for future reference. 1. Do not expose the product to excessive dust or dirt, intense vibration, extreme humidity, or high temperatures. - Page 5 8. Do not drop, strike, bend, or crush the batteries. Do not place the batteries in a metal container. Failure to observe this precaution may result in a chemical leak, fire, or explosion. 9. Use only the charger provided with the product. Use of a different charger may result in fire or explosion.
- Page 6 16. Do not leave the product exposed to direct sunlight. 17. Do not allow children to use the product. 18. It is normal for the product to heat up while being used. 19. It is normal for the product to heat up while its batteries are charging.
-
Page 7: Introduction
6 hour NiMH rechargeable battery delivers extended runtime. All video settings (Brightness, Contrast, Saturation, Sharpness) are adjustable via an On Screen Menu. The Triplett CamView W35 is an efficient time saving test tool that will enhance any professional tool kit. -
Page 8: Features
• Tripod Thread • SilkGrip Finish • Carrying Case Included • Cables Included • 1 Year Warranty 4: Included Items • CamView W35 • RCA Audio/Video Input Cable • NiMH Batteries • RCA Audio/Video Output Cable • Battery Charger • Instruction Manual •... -
Page 9: Controls And Indicators
5: Controls and Indicators 1. Built-in 1 Watt speaker 2. Power / Charging Indicator, Bi-color LED (Red, Green) 3. MENU / Select Button 4. Increase Setting 5. Decrease Setting 6. MENU OFF 7. Charger Input (Power in) 8. Power Switch (OFF / ON) 9. -
Page 10: Battery Information
6: Battery Information To obtain the maximum battery life and avoid battery leaks, fire, or explosion, observe the following instructions and warnings. • Please charge the batteries before the first use of the product. • If the product is unused for several weeks, the batteries will slowly discharge by themselves. - Page 11 • Do not transport or store the batteries in a metal container or with other metal objects. • Do not throw batteries into a fire. They may explode. • Discard old batteries in an approved manner. Page 10 PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
-
Page 12: Installing And Charging The Batteries
6: Installing and Charging the Batteries • Refer to the following figures to install the batteries. Flip the Stand up, pull it up, and twist it around out of the way of the battery cover. Remove the battery cover, sliding it in the direction of the arrow molded in the plastic . - Page 13 Replace the battery cover and reposi- tion the Stand so it fits into the cover. • Plug the charger into the power source (wall outlet) then plug the charger cable into the connector (7) on the side of the product. Observe Indicator LED(2).
- Page 14 • Do not charge the batteries in a place where the temperature exceeds 140 degrees F. The batteries may be damaged or may explode. • Fully charged batteries will not charge again until they are depleted. Partially discharged batteries may be recharged at any time. •...
-
Page 15: General Instructions
When operating from batteries, the LED should light up green. The CamView W35 continually tests for the presence and type of video signals applied to its input. A few seconds after the power is turned... - Page 16 Connecting the Video and Audio Inputs: A video signal can be connected to the CamView W35 in two places. For the best durability, the BNC video input jack (11) should be used. The video input on the side of the W35 (9) uses a mini-plug and is more easily damaged that the BNC.
- Page 17 On Screen Display (OSD) The factory settings are defaulted to “50”. When the settings are changed, the CamView W35 will remember them, even when the power is turned off. To select a specific setting to be altered, observe the location of the yellow cursor bar and press and release the MENU key (3) repeatedly until the bar highlights the desired setting.
- Page 18 Using the Wristband: Refer to the following figures to attach and use the wristband. With the monitor face down, install the wristband through one slot as shown. The Velcro strips should be facing down. Put the end of the wristband through the other slot as shown.
- Page 19 Front view of monitor and wristband Place monitor against wrist or arm with wristband hanging over arm. Bring end of wristband around back of arm and insert it through the buckle from the back, pulling it all the way through. Fold and pull end of wristband back over itself, adjust- ing to the desired tension, and se- cure against the Velcro strips.
- Page 20 Using the Stand as a Belt Clip: Refer to the following figures to use the Stand as a Belt Clip. Pull the stand out and let it hang loose. Slip the end of the Stand over belt or waist of pants. Page 19 PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 21 Using the Stand: Refer to the following figures. Pull the stand out and let it hang loose. Pull Stand up (there is a spring inside) and rotate it by 90°. Release Prop monitor up using the Stand. Page 20 PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
- Page 22 Using the Mounting Thread: Attach the monitor to a tripod or mounting bracket (not supplied) as shown in the following figures. Mounting bracket with ¼ x 20 thread. Screw the bracket into the female thread on the bottom of the monitor. Attach the bracket to wall or other surface.
- Page 23 Standby and Low Battery: When the battery is low, the LED (2) won’t light when the power switch (8) is turned on. There is a narrow region of battery voltage where the LED will light up green, but the monitor won’t operate. This can be mistaken for the Standby mode.
-
Page 24: Specifications
9: Specifications Display 3.5” High Contrast Active Matrix TFT LCD Screen Video Formats Supported NTSC and PAL Resolution 320 x 240 Aspect ratio Viewing Angle 40/60/60/60 (up/down/left/right) Brightness 250cd/m Contrast 350:1 Response time 25ms Video Level and Impedance 1.0Vp-p 75ohm Audio Speaker Video Adjustments via Brightness, Contrast, Saturation (Color),... - Page 25 Connectors Audio/Video Input (3.5mm, 4 circuit), Audio/ Video Output (2.5mm, 3 circuit), Charger Input (mini USB), Video Input (BNC) Battery Life 6 Hours continuous operation, (with full charge) 12 Hours Standby Batteries AA 1.2V 2500mAH NiMH x 4 AC Charger Input 110 ~ 240V-50/60Hz-0.30A Output DC 12V/1.5A Battery Recharge Time...
- Page 26 Product dimensions 4 ¾” x 3 ¾” x 1 ¼” Weight 9 Ounces Page 25 PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
-
Page 27: Troubleshooting
10: Troubleshooting Problem Reason Solution Batteries discharged Charge battery Batteries installed Install batteries incorrectly correctly Won’t turn on Bad battery Clean the battery connections terminals Apply video signal No video signal input to the input Batteries discharged Charge battery Monitor turns off Video signal removed Reapply video signal Warm monitor... - Page 28 Problem Reason Solution Bad battery Clean the battery Indicator LED is connections terminals normal but battery Battery has been Replace with new doesn’t charge charged too many times batteries Check video source No video input and connections No video display Bad cables Replace cables Page 27...
-
Page 29: Warranty
Accessories, including batteries and fuses, not of our manufacture used with this product are not covered by this warranty. To register a claim under the provisions of this warranty, contact Triplett’s Cus- tomer Service Department for a Return Authorization Number (RMA) and return instructions. - Page 30 No representative of Triplett / Jewell Instruments or any other person is authorized to extend the liability of Triplett in connection with the sale of its products beyond the terms hereof.
- Page 31 PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor...
