Summary of Contents for Rigel Optics 2300
- Page 1 Rigel Optics 477 South 28 St., Suite 3 NIGHT VISION BINOCULAR Washougal, WA 98671 www.rigeloptics.com Rigel 2300 Tel 360-835-5629 User Manual...
- Page 2 Index 1. Introduction Section Page Congratulations and thank you for purchasing Rigel Optics Night Vision. With proper care Introduction and use this device can function properly for Care Guidelines many years. Technical Specifications Assembly Diagram Night Vision Technology works by first...
- Page 3 • Never open the device. Night Vision hardware contains high voltage electronics Rigel Optics and will cause electric shock. 477 South 28 St., Suite 3 Washougal, WA 98671 •...
- Page 4 Technical Specifications Magnification 3.6 x Field of View 11° Minimum viewing 3 meters distance Maximum viewing 200 meters distance of an animal [moose] at ¼ moonlight Maximum viewing 100-140 distance in total meters darkness with the aid of the IR Illuminator Resolution 30 lin./mm Power supply –...
- Page 5 Components as shown in Figure 1 5. Preoperation Body Battery Installation Eye-piece • Check that the lens cover (9) is on and the Focal length adjustment ring power switch (7) is in the OFF position Objective lens • Remove the battery compartment cover (8) Objective Lens Focus Ring •...
-
Page 6: Maintenance
Note: This device is equipped with an Maintenance additional photosensor to prohibit the unit from being turned on under a bright light source. If The user must take very good care of the the unit is to be tested in daylight with the lens scope, protect it from impacts, dust and raw covers on, the photocell must be covered up. -
Page 7: Troubleshooting Guide
Troubleshooting Guide This product is guaranteed for quality compliance of the device per the technical specifications when the device is used while observing the rules of operation, transportation, and storage. Problem Possible Cause Solution Absence of 1. The batteries are 1.
