ASSEMBLY & INSTALLATION
INSTRUCTIONS
WASHSTAND
9440.000
Thank you for selecting our products...products which have been the benchmarks of fine quality for over 100 years.
To help insure that the installation process will proceed smoothly, please read these instructions carefully before you
begin. Also, review the recommended tools and materials list; carefully unpack and examine your new plumbing fixture.
Recommended Tools & Materials
Adjustable Wrench
Channel Locks
Plumbers' Putty or
Caulking
Phillips Screwdriver
Regular Screwdriver
Tape
Measure
Pipe Wrench
Hacksaw
Drill
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
© A m e r i c a n S t a n d a r d I n c . 2 0 0 3
"
0283.008
9441.000
Level
Putty Knife
STANDARD WASHSTAND TOP
WASHSTAND TABLE LEGS
10-1/4
(260mm)
FINISHED
WALL
SUPPLIES AS
REQUIRED
36
1-1/4 O.D.
(914mm)
8-1/2
(216mm)
17-15/16
(456mm)
FINISHED
FLOOR
- 1 -
13
(330mm)
8
(203mm)
1-3/4" DIA.
STD. DRAIN
OUTLET
26-3/4
(680mm)
WASTE
8
(203mm)
22-5/8
(575mm)
3-7/8
(98mm)
3/4
(19mm)
20
(508mm)
7-1/2
(191mm)
28-1/2
(724mm)
22
(559mm)
24
(610mm)
7 3 08 0 5- 1 00
