LG LMDN095HV Specification

Job Name/Location:
Date:
PO No.:
Architect:
Engr:
Rep:
(Company)
LMDN095HV
Flex Multi Ceiling Concealed Duct
9,000 Btu/h Indoor Unit
Performance:
Nominal Capacity (Btu/h)
Cooling Nominal Test Conditions:
Indoor: 80°F DB/67°F WB
Outdoor: 95°F DB/75°F WB
Electrical:
Power Supply (V¹/Hz/Ø)
Rated Amps (A)
Piping:
Liquid Line (in, OD)
Vapor Line (in, OD)
Drain OD, ID (in)
Temperature Sensor
Max Length Each Pipe (ft)
Max Elevation between ODU and IDU (ft)
Max Elevation between IDU and IDU (ft)
Features:
•2 Thermistor control •Internal Condensate Pump
•Auto opera on •Inverter
•Auto restart (variable speed fan)
•Control lock func on
Included Accessories:
•Simple Controller with Mode (White) PQRCVCL0QW
Optional Accessories (sold separately)
7 Day Programmable Controller (Black) PQRCVSL0
7 Day Programmable Controller (White) PQRCVSL0QW
Simple Controller with Mode (Black) PQRCVCL0Q
Simple Controller without Mode (Black) PQRCHCA0Q
Simple Controller without Mode (White) PQRCHCA0QW
AC Smart II PQCSW320A1E
ACP without DIgital I/O PQCPA11A03
ACP with Digital I/O PQCPB11A0E
LonWorks Gateway PQNFB16A1
BACnet Gateway PQNFB17B0
AC Ez PQCSZ250S0
Dry Contact Unit Dry Contact Unit (1 contact, 24 VAC external power) PQDSB1
Dry Contact Unit Dry Contact Unit (2 input, power from indoor unit) PQDSBC
Dry Contact for third party thermostat PQDSBNGCM1
For continual product development, LG reserves the right to change specifications without notice.
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. "LG Life's Good" is a registered trademark of LG Corp. /www.lghvac.com
For:
File
Approval
GC:
Mech:
(Project Manager)
9,000
Heating Nominal Test Conditions:
Indoor: 70°F DB/60°F WB
Outdoor: 47°F DB/43°F WB
208 230/60/1
0.25
1/4
3/8
1 1/4, 1
Thermistor
82
49.2
24.6
Tag #:
Resubmit
Other
Operating Range:
Cooling Max (°F WB)
Heating Min (°F DB)
Unit Data:
Refrigerant Type
Refrigerant Control
Sound Pressure H/M/L (±3 dB(A))
Primary Filter
Net Unit Weight (lbs)
Shipping Weight (lbs)
Communication Cable (No x AWG)
Fan:
Type
Quantity
Motor/Drive
Airflow Rate H/M/L (CFM)
Max External Static Pressure (in wg)
Dehumidification Rate (pts/h)
Standard Features:
•Limited Warranty with LG Cer fied Installa on
•Limited Two Year Func onal Parts Warranty
Notes:
1.Acceptable opera ng voltage: 187V 253V.
2.See Engineering Manual for sensible and latent capaci es.
3.Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4.All communica on cable to be minimum 18 American wire gage (AWG), 2 conductor,
stranded, shielded and must comply with applicable local and national code.
5.Power wiring cable size must comply with the applicable local and na onal code.
6.This unit comes with a dry helium charge.
7.This data is rated 0 above sea level, with 24.6
a 0 ft level difference between outdoor and indoor units. All capacities are net with a
combination ratio between 95 – 105%.
8.Must follow installa on instruc ons in the applicable LG installa on manual.
PQRCVCL0QW
R410A
32/26/25
Washable Pre filter
4 x 18
Sirocco
Brushless Digitally Controlled/Direct
300/265/229
of refrigerant line per indoor unit and
DFS SB AD 008 US 012M17 Page 1 of 2
76
59
EEV
46
50
3
0.157
2.1
