  • Page 2: Important Safety Notice

    IMPORTANT SAFETY NOTICE Proper service and repair is important to the safe, reliable operation of all Philips Consumer Electronics Company** Equipment. The service procedures recommended by Philips and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose.

  • Page 3: Fire And Shock Hazard

    FIRE AND SHOCK HAZARD 1. Be sure all components are positioned in such a way as to avoid the possibility of adjacent component shorts. This is especially important on those chassis which are transported to and from the service shop. 2.

  • Page 4: Leakage Current Cold Check

    LEAKAGE CURRENT COLD CHECK 1. Unplug the ac line cord and connect a jumper between the two prongs of the plug. 2. Turn on the power switch. 3. Measure the resistance value between the jumpered ac plug and all exposed cabinet parts of the receiver, such as screw heads, antennas, and control shafts.

  • Page 6: Tv Safety Notes

    TV SAFETY NOTES SAFETY CHECKS After the original service problem has been corrected, a complete safety check should be made. Be sure to check over the entire set, not just the areas where you have worked. Some previous servicer may have left an unsafe condition, which could be unknowingly passed on to your customer.

  • Page 7: Picture Tube Replacement

    The use of a substitute part which does not have the same safety characteristics as the Philips recommended replacement part shown in this service manual may create shock, fire, or other hazards.

  • Page 8: Prevention Of Electrostatic Discharge (Esd)

    PREVENTION OF ELECTROSTATIC DISCHARGE (ESD) Some semiconductor solid state devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices, Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).
  • Page 9 PRACTICAL SERVICE PRECAUTIONS IT MAKES SENSE TO AVOID EXPOSURE TO ELECTRICAL SHOCK. While some sources are expected to have a possible dangerous impact, others of quite high potential are of limited current and are sometimes held in less regard. ALWAYS RESPECT VOLTAGES. While some may not be dangerous in themselves, they can cause unexpected reactions –...

  • Page 10: General Information

    GENERAL INFORMATION Typical Models Standard Screen - Model: 27PT71 Flat Screen - Model: 27PT91...

  • Page 11: Technical Specifications

    Technical Specifications Supply Supply Voltage 90 – 140Vac Power Consumption 90 W max. Stand By consumption : 7 – 8W Supply Frequency : 50 - 60 Hz 5 % Tuning System Reception NTSC-M Sound System BTSC DBX Sound Output 2 x 5 W – 27”/32”/36” FSQ 2 x 5 W + 10W –...
  • Page 12 MON: CVBS (out) + L/R (out) Cinch CVBS (yellow) (1 V) Cinch Audio L (red) (0.2 - 2 V-RMS / 10 k ohm) Audio R (white) (0.2 - 2 V-RMS / 10 k ohm) YUV (in) Cinch Y (0.7Vpp/ 75 ohm) Cinch U (0.7Vpp/ 75 ohm) Cinch V...
  • Page 13 CBA Location Guide...
  • Page 14 Model to Module Listings MODEL PANEL 27PT31B/121 313917867841 Large Signal Panel 313917883531 Small Signal Panel 313917880521 M-Link Assembly (W/O M-Link) AVJ400A/001 Side Jack Panel 27PT41B/121 313917867851 Large Signal Panel 313917865621 Small Signal Panel AVJ400A/001 Side Jack Panel A10902A/001 M-Link Assembly A10904A/001 PIP Panel 27PT71B/121...
  • Page 15 32PT41B/121 313917868651 Large Signal Panel 313917865621 Small Signal Panel AVJ400A/001 Side Jack Panel A10902A/001 M-Link Assembly A10904A/001 PIP Panel 32PT71B/121 313917867861 Large Signal Panel 313917863191 Small Signal Panel AVJ400A/001 Side Jack Panel A10902A/001 M-Link Assembly A10901A/001 PIP Panel 310420710191 Receiver Assembly IR Board 32PT81S/128 313917888271 Large Signal Panel...
  • Page 16 32PT91S/121 313917865591 Large Signal Panel 313917865601 Small Signal Panel A10901A/001 PIP Panel (2 Tuner) A10902A/001 M-Link Assembly A10904A/001 PIP Panel 313917865661 Front Interface Panel 313917864271 Top Control Assembly 313917867911 Side Jack Panel 310420710191 Receiver Assembly IR Board 312123751431 Double Window PIP Assembly 313917857061 * Double Window PIP Panel 313917863791...
  • Page 17 33LP803/221 313917867861 Large Signal Panel 313917863191 Small Signal Panel AVJ400A/001 Side Jack Panel A10902A/001 M-Link Assembly A10901A/001 PIP Panel (2 Tuner) 310420710191 Receiver Assembly IR Board Model To Remote Transmitter Listing Model Part Ref. Part No. Transmitter Type 27PT91S/125 AC19 3128 147 12101 RC2037/01 Remote Transmitter 32PT91S/121...

  • Page 26: Mechanical Disassembly

    Mechanical Disassembly Rear Cover Removal & Replacement Removal of the Rear Cover 1. Remove all screws from the rear cover. 2. Remove the rear cover. Replacement of the Rear Cover Before replacing the Rear Cover, perform the following inspection: Ensure that AC Cord is placed correctly in the guide brackets. Ensure that all cables are placed in their original position.
  • Page 27 1. Remove the LSP-bracket from the bottom tray by sliding the bracket backward and then pull the bracket up and out of the bottom tray. 2. Place the Hooks (A) of the bracket in the first row of fixation holes of the cabinet bottom. In other words reposition the bracket hooks from position (1) to position (2).
  • Page 28 Service position for the Small Signal Board (SSB) There is not a predefined service position for the bottom (B-) side of the SSB. All relevant test points can be accessed in both LSB service positions. If IC's must be replaced: take the complete panel out of the SIMM-connector. 1.
  • Page 29 Access to the Side I/O Panel 1. Remove the two screws. 2. Remove the complete Side I/O-assembly. 3. Release the two clamps then lift the board out of the bracket.
  • Page 30 Access to the Mains Switch/LED Panel 1. Release the two clamps (1) by pulling them upward. 2. While pulling upward on the clamps, slide the complete assembly backward (2). 3. If it is necessary to remove the board, release the two clamps at the sides of the bracket and lift the board out (3). 1.
  • Page 31 Access to the PIP Panel 1. Release the two clamps (1) and remove the PIP CBA from the bracket. Access to the Guide+ Panel 1. Remove the two screws that secure the Guide+ assembly in place. This will release the complete Guide+ assembly. 2.
  • Page 32 Access to the M-Link 1. Release the two clamps at both sides and remove the board from the bracket. Access to the DC-shift/DAF panel 1. Release the clamps (1) and remove the board (2) from the bracket.

  • Page 33: Troubleshooting Tips

    Troubleshooting Tips Troubleshooting tips for the deflection and power supply circuitry. The Deflection Circuit: Measure for VBAT (140V) across 2939/2940 (Section - A1 POWER SUPPLY). If the voltage is not present, disconnect jumper 9936 and 9937 (see A1 Power Supply) The complete Line Deflection stage is now disconnected.
  • Page 34 Solving other problems TV switched off or changes channel without any user action Set switches off after “TV SWITCHING OFF” was displayed Auto standby switched the set off because: there was no ident signal for more than 15 minutes there was no remote control signal received or local key pressed for > 2 hours See Service Adjustments for a description of options to enable/disable auto standby.

  • Page 39: Electrical Adjustments

    H8 CHASSIS (A10) ADJUSTMENTS Electrical Adjustments Conditions All electrical adjustments should be performed under the following conditions: Supply voltage: 120V +/- (10%) Warm-up time: 10 minutes The voltages and oscilloscope waveforms are measured in relation to the tuner ground. Test probe: Ri > 10Meg Ohm; Ci < 2.5 pF. VG2 Adjustment Rough alignment Using a pattern generator displaying a circle pattern, adjust the VG2 potentiometer of LOT L5630 to obtain a normal picture.

  • Page 40: Focus Adjustment

    Focus Adjustment Using a pattern generator displaying a crosshatch pattern, adjust the focus potentiometer of LOT L5431 in such a way that the haze on the vertical lines at 2/3 from the left and right edges of the screen (just) disappears. PIP AGC Adjustment The Automatic Gain Correction adjustment prevents overdriving of the PIP-tuner if the input signal is too strong.
  • Page 41 PIP AFC Adjustment Connect a video generator with a color bar and a frequency of 61.25 MHz to the tuner. Connect a multimeter to the AFC output on pin 15 of IC 7914 – TDA9801 Use potentiometer R3944 to adjust the AFC output to 2.6 Volts. Software alignments (Service Alignment Mode) With the software alignments of the Service Alignment Mode, the geometry, white tone and tuner (IF) can be aligned.
  • Page 42 Tuner (Large Signal Panel and Double Window) AGC Adjustment Set pattern generator with gray scale video signal and connect to antenna input with RF signal amplitude - 10mV and set frequency to 63.25 MHz. Enter SAM (see Software alignments (Service Alignment Mode)). Press Cursor Down button to highlight the TUNER menu item.

  • Page 43: Geometry Adjustment

    Geometry Adjustment The geometry alignments menu contains 13 items for correct picture geometry alignment. In widescreen models, the GEOMETRY SW is available for separate alignments of the superwide (panorama) mode. The geometry alignments are: Initial set-up: Press the PICTURE button on the remote control repeatedly to change the Smart Picture setting to "SPORTS." Enter SAM (see Software alignments (Service Alignment Mode)).
  • Page 44 Geometry Submenu Item Descriptions SERV-BLK: - To turn on/off the blanking of the lower half of the screen (To be used in combination with the vertical slope alignment) VER-SLOPE - To adjust the picture so the proportions are the same at the top and bottom of the screen. (This alignment must be performed first, before all other vertical alignments) VER-AMPL - To align the picture height (other vertical alignments are NOT compensated)
  • Page 45 Option Codes for Single Tuner PIP, and 2 Tuner PIP...
  • Page 46 Option Codes for Models Without PIP...
  • Page 47 Option Codes for Double Window...
  • Page 48 Option bits/bytes Option bytes for NAFTA models (4:3 Standard Screen) with software named: A10_1US1. OB1 bits 8, 7, ..., 1: SBNP, CVI, C169, E149, SMCK, AV3, CBFL, and IPIX OB2 bits 8, 7, ..., 1: IPMU, VDBY, PLST, SOSD, BLMU, PIPC, PIPT, VSLC OB3 bits 8, 7, ..., 1: MLNK, SURF, CCAP, DNRM, VMUT, TIME, AAVL, FUNN OB4 bits 8, 7, ..., 1: SPKC, VCBK, VBNR, USRC, BNUM, ROTI, SNIC, TMWIN OB5 bits 8, 7, ..., 1: AOUT, INCF, APC, NVM, (res), (res), (res), (res)

  • Page 49: Test Points

    Service Modes & Error Messages The following topics are covered: Test points Service Modes and Dealer Service Tool (DST) Error code buffer and error codes The “blinking LED” procedure Trouble shooting tips Customer Service Mode Test points The H8 chassis is equipped with test points shown on the CBA and the schematic diagrams. Large Signal Panel PCB Test Point Guide...
  • Page 50 Small Signal Panel PCB Test Point Guide...
  • Page 51 CRT Panel PCB Test Point Guide Each test point has a reference number indicating the functional block in which it is located. A1-A2-A3, etc.: Test points for the audio processing circuitry [A6, C6] C1-C2-C3, etc.: Test points for the control circuitry [C8] F1-F2-F3, etc.: Test points for the frame drive and frame output circuitry [A3] I1-I2-I3, etc.: Test points for the Intermediate Frequency Circuitry [A4, C1] K1-K2-K3, etc: Test points for the Guide+ panel...
  • Page 52 Service Default Mode (SDM) Introduction The Service Default Mode (SDM) is a technical aid for the service technician. The Service Default Mode (SDM) establishes fixed, repeatable settings of customer controls, which allow consistent measurements to be made. The SDM also initiates the blinking LED procedure and, if necessary, overrides the 5V protection.
  • Page 53 Service Default Mode (SDM) Screen Special SDM functions Access to normal user menu Pressing the “MENU” button on the remote control switches between the SDM and the normal user menus (with the SDM mode still active in the background) Auto Program Press the Cursor Down button and highlight the "Install"...
  • Page 54 Service Alignment Mode (SAM) Introduction The Service Alignment Mode (SAM) is used to align the set and/or adjust the option settings and to display/clear the error code buffer values. Entering Service Alignment Mode To enter the Service Alignment Mode (SAM), press the following key sequence on the remote control transmitter: 0-6-2-5-9-6-STATUS Do not allow the display to time out between entries while keying the sequence It is also possible to enter the Service Alignment Mode by pressing the “VOLUME +”...
  • Page 55 SAM Screen and Menu Structure...
  • Page 56 Explanation notes/references: Operation Hours (Run Timer): This display indicates the accumulated total of operational hours. (Shown in hexadecimal format) Software identification of the main micro controller (A10US1-2.7) A10 is the engineering chassis name for the H8 chassis US1 is 2 letter and 1 digit combination to indicate the software type and the supported languages: US = USA 1 = Main Software language version number...
  • Page 57 upon automatic reset when content has not changed for 50 consecutive hours By leaving SDM or SAM via the power switch, the error buffer will not be reset. Examples: ERROR: 0 0 0 0 0 0 0 : No errors detected ERROR: 6 0 0 0 0 0 0 : Error code 6 is the last and only detected error ERROR: 9 6 0 0 0 0 0 : Error code 6 was first detected and error code 9 is the last detected (newest) error The contents of the error buffer can also be displayed by use of the “blinking LED”...
  • Page 58 Error 4 = +5V protection 5V protection active; set is switched to protection; error code 4 is placed in the error buffer; the LED will blink 4 times (repeatedly). A 5V failure can cause a drop in the 5V-supply output, resulting in an undefined behavior of the set. Therefore, all I 2 C devices connected to the 5V supply are constantly monitored.
  • Page 59 Error 16 = PIP/DW Tuner I 2 C error. The Tuner (TEDE9 – item 1900) on the PIP-panel does not respond to the micro controller. Error 17 = PIP IC – M65669SP I 2 C failure (item 7803) or Double Window IC SAB9081 I 2 C failure. Error18 = I/O expander IC –...

  • Page 60: The Blinking Led Procedure

    The Blinking LED Procedure The contents of the error buffer can also be made visible through the “blinking LED” procedure. This is especially useful when there is no picture. When the SDM is entered, the LED will blink the number of times, equal to the value of the error code. Upon entry into the SDM, the LED will blink the contents of the error-buffer.
  • Page 61 The Customer Service Mode information screen Upon entry into the Customer Service Mode the following screen will appear. CSM Menu Screen The Customer Service Menu shows the following information: Line 1 : “HRS : nnnnn” and SWID : “A10BBC-X.Y” HRS: Indicates the accumulated total of operational hours.
  • Page 62 Line 6 : “TIMER ON ” Indicates that the on/off timer is running. The following Complaints may be caused by the activation of the sleep timer: The set may turn on from standby or may switch to a different channel without using either the remote control or the local keyboard.

  • Page 63: Power Supply

    H8 Technical Training INTRODUCTION The H8 TV Chassis is designed for the 2000-2001 model years. It comes in three screen sizes, which are 27, 32, and 36 inch. All Chassis versions have a Side Jack Panel, a Component Input, and Surround Speaker Jacks.
  • Page 64 The Power Supply is a Switching type supply. The Power Supply begins operating as soon as AC power is applied to the set. AC power is applied to the Large Signal Board through Fuse 1900 and applied to the Bridge Rectifier 6915.
  • Page 65 The voltage from jumper 9964 (approximately 8 volts) is used to produce the 3.3 volt standby, 5 volt standby, 5 volt remote control, and switched 8 volt supplies. The voltage is applied to transistor 7965 to produce the 3.3- volt Standby supply. When the set is in the Standby mode, transistor 7944 is turned On, turning 7922 On, providing a extra current drive for the 3.3 volt regulator.
  • Page 66 Power Down and Front Detect Figure 4 The Power-Down and Front Detect circuits signal the Microprocessor in case power is removed from the set. The Microprocessor will store the customer settings before shutting the set down. Diode 6942 produces a negative voltage to turn transistor 7987 On, keeping the Power-Down line High.

  • Page 67: Horizontal And Vertical Drive

    SWEEP AND SHUTDOWN CIRCUITS Horizontal and Vertical Drive Figure 5 The 3.3 volts Standby supply provides power to 7301 on Pin 14 for a Horizontal Soft Start. The Standby line from the Microprocessor turns the +8 volt supply On to provide power for the Sync circuits when the set is turned On.
  • Page 68 Horizontal Output and Shutdown Figure 6 Horizontal Drive (LINEDRIVE1) is fed to transistor 7481 and coupled through transformer 5406 to the Horizontal Output transistor 7410. In sets with the Very Flat CRT and larger screen sizes, an East West Drive circuit is present.

  • Page 69: Vertical Output

    Vertical Output Figure 7 Positive and Negative Vertical drive from the Small Signal Board is fed to the Vertical Output IC7501 which drives the Vertical Yoke. The Vertical Pulse on Pin3 drives 7513 to produce the VFB (Vertical Feedback signal) for the Small Signal Board.
  • Page 70 NON PIP Video Signal Flow Figure 8 The first version to be discussed is the Non PIP chassis video path. The Main Tuner, AV1, AV2, and Component Inputs are located on the Large Signal panel. The AV3 input is located on the Side Jack Panel. All of these inputs are fed to the Small Signal Board, SSB, which plugs into the Large Signal panel.
  • Page 71 Standard CRT Drive Figure 9 The CRT drive signal is fed to 7830, which drives the CRT. As mentioned previously, a Test Signal is sent to 7830 and to the CRT. The Waveform on the left shows this Test Signal. When 7830 senses the correct current flow in the CRT, the Test Signal is sent to the SSB via the CUTOFF line.
  • Page 72 PIP (Picture in Picture) Video Flow Figure 10 There are two PIP chassis versions which are the Single Tuner and Two Tuner sets. Video Signal flow for the Single Tuner PIP version is the same as the Two Tuner version, except the Composite Video from Pin 16 of 7301 is routed through the Large Signal Board (LSB) to the PIP module and back to the 1333 Sound Trap in the Two Tuner version.
  • Page 73 PIP Circuit Figure 11 The PIP comes in two versions, Single Tuner with no tuner on the PIP panel and two tuner versions with the second tuner located on the PIP module. Output of the second tuner is fed to the SAW FILTER 1901, and to the Signal Processor 7914.

  • Page 74: Pip Switching

    PIP Switching Figure 12 Control for the PIP panel is performed by 7910 via the I2C buss. SEL_TUNER1 and SEL_TUNER2 control the composite switching to the SSB panel. S1, S2, and S3 control the tuner aux switching IC 7801.PIP...
  • Page 75 Power Supply Figure 13 The PIP panel is powered by +5 volt, +8 volt, and +33 volt supplies from the Large Signal Board (LSB). A 3.3 volt regulator supplies power to the PIP processor, 7803.
  • Page 76 Video Signal Flow with Double Window Figure 14 The XXPT91 versions of the H8 chassis have the DOUBLE WINDOW panels. This allows for both a single PIP window and a split screen. Each Time the PIP On/Off button on the remote is selected, the PIP window goes from a small window to a large window and then to a split screen.
  • Page 77 Double Window Tuner and Video Switching Figure 15 The PIP/Double Window panel allows for both a standard PIP window and a split screen. The PIP/Double Window module has a separate Tuner, SAW filter, and Signal Processor. The output of the Signal Processor, 7301, on Pin 16 is fed to switching IC 7402 which selects between the PIP Tuner and Composite Video from the SSB for feedback to the SSB on Pin 15 or Video for the PIP window on Pin 14.
  • Page 78 Double Window Output Figure 16 The PIP or Double Window YUV signal is fed to the PIP/DW processor, 7801. The I2C buss controls the IC from the Microprocessor on the SSB. The PIP/DW processor outputs YUV for the PIP window or Split Screen to the YUV switch 7803 where it is mixed with the YUV signal from the SSB for the main picture.

  • Page 79: Double Window Control And Power Supply

    Double Window Control and Power Supply Figure 17 The PIP/Double Window module is controlled by the I2C buss through 7403 on the PIP module. Pins 4, 5, 6, and 7 perform Video selection functions. Pin 10 produces a reset signal for the Guide Plus module. Pin 12 controls the +5VS and +8VS supplies.Very...
  • Page 80 Flat CRT Drive Circuit Figure 18 The CRT panel for the Very Flat CRT's has an SVM circuit to sharpen the transitions from dark to light and light to dark. The RGB signals are combined and fed to 7860 which performs impedance matching. The signal is then buffered by 7861.

  • Page 81: Audio Signal Path

    AUDIO SIGNAL PATH Audio Signal Processing Figure 19 All Audio Processing is performed by 7651, which is located on the SSB. The Sound IF is fed to Pin 50 and to the Sound Demodulator for decoding. The internal Switch selects between AV1, AV2, and AV3. The Audio is digitally processed inside the IC to separate the Second Audio Program and process volume levels to maintain a constant audio level if the user selects the AVL feature.

  • Page 82: Audio Amplifier

    Audio Amplifier Figure 20 Audio from the SSB is fed to the Audio Amplifier on the LSB. Left Channel Audio is fed to Pin 2 of 7702 while Right Channel Audio is fed to Pin 5. Audio is output to the speakers on Pins 12 and 7. Left and Right outputs are also fed to the Surround Sound Speaker Jack.

  • Page 83: Headphone Amplifier

    Headphone Amplifier Figure 21 Headphone audio from the SSB is fed to the Headphone Amplifier, 7703-A, located on the LSB. The Audio is then output to the Side Jack panel. This circuit is powered by the +5 volt supply.

  • Page 84: Side Jack Panel

    Side Jack Panel Figure 22 The Side Jack panel is the AV3 input in the Customer Menu. It has a Composite Video Input, SVHS Input, and a Stereo Audio input. It also has a headphone output. If an SVHS connector is plugged into the Side Jack panel, the Composite Video input is muted.
  • Page 85 Microprocessor Figure 23 The Microprocessor, 7064, is located on the SSB. User control of the Microprocessor is accomplished via the Keyboard or Remote. In case of Overcurrent or a failure in the Horizontal sweep circuit, The PROT-UP line will go High turning transistor 7276 On, placing a Low on Pin 5 of the Keyboard line. The Microprocessor will then shut the set Off.
  • Page 86 Customer Control Interface Figure 24 The Keyboard line is a voltage level controlled input. With no buttons pressed, this line should read approximately 3.38 volts when the set is On. It will be approximately 0.2 volts higher when the set is in Standby. In the XXPT31 versions, the Keyboard Switches are located on the LSB.

  • Page 87: Service Modes

    SERVICE MODES All of the adjustments in the set are performed via the On-Screen Service mode. There are three different Service Modes. The SDM (Service Default Mode) allows Error Codes to be read through an On-Screen menu or from a blinking Power light. It also pre-sets certain conditions and disables certain functions. The next Service mode is the SAM (Service Adjustment Mode).
  • Page 88 Service Alignment Mode (SAM) Figure 25 The Service Alignment Mode is used to read Error Codes, Reset Error Codes, Set Option Codes, and perform Service Alignments. Pressing 0-6-2-5-9-6-Status on the remote control transmitter enters the SAM. To save the Error Codes, remove AC power to the set without turning it Off. When power is reapplied and the set is turned On, the SAM will still be active.
  • Page 89 Customer Service Mode (CSM) The Customer Service Mode allows the Customer to read the Error codes upon instruction form the Technician. Pressing the Mute button on the Remote Control and any key on the set Keyboard at the same time can enter the Customer Service Mode.

  • Page 90: Wiring Diagrams

    Wiring Diagrams...

  • Page 92: Block Diagrams

    Block Diagrams...
  • Page 96 27H8(7592)
  • Page 97 27H8(7592)
  • Page 98 27H8(7592)
  • Page 99 27H8(7592)
  • Page 100 27H8(7592)
  • Page 101 27H8(7592)
  • Page 102 All Models (7592) - H8 Chassis - Circuit Board Location Guide...
  • Page 103 All Models (7592) - LSP Panel: Power Supply - A1...
  • Page 104 All Models (7592) - LSP Panel: Line Deflection - A2...
  • Page 105 All Models (7592) - LSP Panel: Frame Deflection - A3...
  • Page 106 All Models (7592) - LSP Panel: Tuner - A4...
  • Page 107 All Models (7592) - LSP Panel: Cinch - A5...
  • Page 108 All Models (7592) - LSP Panel: Audio - A6...
  • Page 109 All Models (7592) - LSP Panel: Front Control / Rotation / Headphone - A7...
  • Page 110 All Models (7592) - CRT Panel - B...
  • Page 111 All Models (7592) - SSB Panel: IF, Video, Sync & Chroma - C1...
  • Page 112 All Models (7592) - SSB Panel: Video Features - C2...
  • Page 113 All Models (7592) - SSB Panel: Microcontroller - C3...
  • Page 114 All Models (7592) - SSB Panel: Memory - C4...
  • Page 115 All Models (7592) - SSB Panel: Audio Processing - C5...
  • Page 116 All Models (7592) - SSB Panel: Audio Processing - C6...
  • Page 117 All Models (7592) - SSB Panel: SSB Conector - C7...
  • Page 118 All Models (7592) - Side Jack Panel - D, Top Control Panel - E...
  • Page 119 All Models (7592) - Double Window Panel: Control - F1, Tuner Panel - F2...
  • Page 120 All Models (7592) - Double Window Panel: I/O Processing - F3...
  • Page 121 All Models (7592) - Double Window Panel: IF-Video-Sync - F4...
  • Page 122 All Models (7592) - Double Window Panel: V Chip Processor - F5, NV ROM - F6...
  • Page 123 All Models (7592) - DC Shift & DAF Panel - G...
  • Page 124 All Models (7592) - M-Link Interface / Matrix Surround - I...
  • Page 125 All Models (7592) - Front Interface Panel - J...
  • Page 126 All Models (7592) - Guide Plus+ Panel - K1...
  • Page 127 All Models (7592) - Guide Plus+ Panel - K2...
  • Page 128 All Models (7592) - 2nd Front End PIP Panel - L1...
  • Page 129 All Models (7592) - PIP Color - L2...
  • Page 130 All Models (7592) - Front Interface & Headphone Panel - Q...
  • Page 131 All Models (7592) - DAF Panel & Inner Pin Cushion Correction Panel - W...
  • Page 132 All Models (7592) - [A] Large Signal Panel PCB (Top View)
  • Page 133 All Models (7592) - [A] Large Signal Panel PCB (Bottom View)
  • Page 134 All Models (7592) - [B] CRT Panel PCB (Top View)
  • Page 135 All Models (7592) - [B] CRT Panel PCB (Bottom View)
  • Page 136 All Models (7592) - [C] Small Signal Panel PCB (Top View)
  • Page 137 All Models (7592) - [C] Small Signal Panel PCB (Bottom View)
  • Page 138 All Models (7592) - [D] Side Jack Panel, [E] Top Control Panel (Top View)
  • Page 139 All Models (7592) - [D] Side Jack Panel, [E] Top Control Panel (Bottom View)
  • Page 140 All Models (7592) - [F] Double Window PIP Panel PCB (Top View)
  • Page 141 All Models (7592) - [F] Double Window PIP Panel PCB (Bottom View)
  • Page 142 All Models (7592) - [G] DC Shift & DAF Panel (Top View only)
  • Page 143 All Models (7592) - [I] M-Link Interface / Matrix Surround (Top View)
  • Page 144 All Models (7592) - [I] M-Link Interface / Matrix Surround (Bottom View)
  • Page 145 All Models (7592) - [J] Front Interface Panel PCB (Top View only)
  • Page 146 All Models (7592) - [K] Guide Plus+ Panel PCB (Top View only)
  • Page 147 All Models (7592) - [L] 2nd Front End PIP Panel PCB (Top View)
  • Page 148 All Models (7592) - [L] 2nd Front End PIP Panel PCB (Bottom View)
  • Page 149 All Models (7592) - [Q] Front Interface & Headphone PCB (Top View)
  • Page 150 All Models (7592) - [Q] Front Interface & Headphone PCB (Bottom View)
  • Page 151 All Models (7592) - [W] DAF Panel & Inner Pin Cushion Correction Panel PCB...
  • Page 153 27PT31B121 - Manual no. 7592 2430 Cap, 15n, ±10%, 50v, Polyester ..3198 014 01530 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2434 Cap, 47u, ±20%, 160v, Electrolytic . .
  • Page 154 27PT31B121 (continued) 2967 Cap, 100u, ±20%, 10v, Electrolytic . . 3198 025 11010 3481 Res, 10K, 5%, 1/6W, Carbon Film..3198 011 01030 2968 Cap, 22u, ±20%, 50v, Electrolytic. . . 3198 025 52290 3482 Res, 10K, 1%, 3/5W, Metal Film ..2322 156 21003 2970 Cap, 1n, ±10%, 50v, Ceramic.
  • Page 155 27PT31B121 (continued) 3966 Res, 470 ohm, 5%, 1/10W, Metalized Glas 3198 021 54710 4403 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3967 Res, 330 ohm, 5%, 1/6W, Carbon Film. . 3198 011 03310 4404 Res, Zero ohm, "Chip"...
  • Page 156 27PT31B121 (continued) 6461 Diode, Rect, BYD33D ..9337 234 00133 9207 Jumper ....0322 179 00003 6463 Diode, Signal.
  • Page 157 27PT31B121 (continued) 9417 Jumper ....0322 179 00003 1327 Crystal Resonator, 12MHz ..2422 543 01095 9418 Jumper ....0322 179 00003 1451 SAW Filter, 45.75MHz .
  • Page 158 27PT31B121 (continued) 2461 Cap, 10u, ±20%, 16v, Electrolytic. . . 3198 030 41090 3307 Res, 390 ohm, 5%, 1/16W, Metalized Glas 3198 021 33910 2462 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3311 Res, 27K, 5%, 1/16W, Metalized Glass . 3198 021 32730 2463 Cap, 10n, +80/-20%, 50v, Ceramic .
  • Page 159 27PT31B121 (continued) 3606 Res, 27K, 5%, 1/16W, Metalized Glass . 3198 021 32730 3619 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 M-Link Assembly (With Matrix) 3621 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 M-Link Assembly (With Matrix) 3665 Res, 2K2, 5%, 1/16W, Metalized Glass .
  • Page 160 27PT41B121 - Manual no. 7592 2416 Cap, 1n5, ±10%, 2000v, Ceramic ..2020 558 90489 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2417 Cap, 470p, ±10%, 500v, Ceramic ..
  • Page 161 27PT41B121 (continued) 2961 Cap, 1n, ±10%, 500v, Ceramic ..3198 019 41020 3445 Res, 1 ohm, 5%, 1/2W, Metal Film . . . 2306 207 03108 2962 Cap, 4u7, ±20%, 16v, Electrolytic. . . 2020 012 93456 3446 Res, 1 ohm, 5%, 1/2W, Metal Film .
  • Page 162 27PT41B121 (continued) 3957 Res, 1K8, 5%, 1/10W, Metalized Glass . 3198 021 51820 4292 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3958 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 4293 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3959 Res, 10K, 5%, 1/10W, Metalized Glass .
  • Page 163 27PT41B121 (continued) 6440 Diode, Signal... . . 3198 010 10010 9032 Jumper ....0322 179 00003 6442 Diode, Signal.
  • Page 164 27PT41B121 (continued) 9404 Jumper ....0322 179 00003 9986 Jumper ....0322 179 00003 9406 Jumper .
  • Page 165 27PT41B121 (continued) 2425 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3062 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 2427 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3064 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 2428 Cap, 10n, +80/-20%, 50v, Ceramic .
  • Page 166 27PT41B121 (continued) 3472 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 3473 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 Guide Plus Panel 3474 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 Guide Plus Panel 3477...
  • Page 167 27PT41B121 (continued) 3826 Res, 150 ohm, 5%, 1/10W, Metalized Glas 3198 021 51510 9803 Jumper ....0322 179 00003 3827 Res, 330 ohm, 5%, 1/10W, Metalized Glas 3198 021 53310 9804 Jumper .
  • Page 168 27PT41B121 (continued) 3288 Res, 10 ohm, 5%, 1/6W, Carbon Film . . 3198 011 01090 3289 Res, 1K8, 5%, 1/6W, Carbon Film..3198 011 01820 3291 Res, 1K, 5%, 1/6W, Carbon Film ..3198 011 01020 3292 Res, 47K, 5%, 1/10W, Metalized Glass .
  • Page 169 27PT71B121 - Manual no. 7592 2417 Cap, 470p, ±10%, 500v, Ceramic ..3198 019 44710 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2419 Cap, 220n, ±5%, 250v, Metalized Polypro pylene .
  • Page 170 27PT71B121 (continued) 2962 Cap, 4u7, ±20%, 16v, Electrolytic. . . 2020 012 93456 3446 Res, 1 ohm, 5%, 1/2W, Metal Film . . . 2306 207 03108 2963 Cap, 220n, ±10%, 16v, Ceramic..2238 780 15654 3447 Res, 1 ohm, 5%, 1/2W, Metal Film .
  • Page 171 27PT71B121 (continued) 3958 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 4293 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3959 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 4294 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3961 Res, 1K, 5%, 2 1/2W, Metal Film.
  • Page 172 27PT71B121 (continued) 6440 Diode, Signal... . . 3198 010 10010 9032 Jumper ....0322 179 00003 6442 Diode, Signal.
  • Page 173 27PT71B121 (continued) 9404 Jumper ....0322 179 00003 9986 Jumper ....0322 179 00003 9406 Jumper .
  • Page 174 27PT71B121 (continued) 2424 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3061 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 2425 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3062 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 2427 Cap, 10n, +80/-20%, 50v, Ceramic .
  • Page 175 27PT71B121 (continued) 3474 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 3477 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 PIP Panel (2 Tuner) 3478 Res, 10 ohm, 5%, 1/16W, Metalized Glass 3198 021 31090 PIP Panel (2 Tuner) 3483 Res, 560 ohm, 5%, 1/10W, Metalized Glas 3198 021 55610...
  • Page 176 27PT71B121 (continued) 3818 Res, 15K, 5%, 1/10W, Metalized Glass . 3198 021 51530 4810 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3819 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 4812 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3820 Res, 1K, 5%, 1/10W, Metalized Glass.
  • Page 177 27PT71B121 (continued) 4701 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 AC19 Remote Transmitter ..3139 128 75991 4702 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 AC20 Speaker, 16 ohm, 5 Watt (2 Used) .
  • Page 178 27PT81S125 - Manual no. 7592 2442 Cap, 100n, +80/-20%, 25v, Ceramic. . . 3198 023 21040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2445 Cap, 22u, ±20%, 250v, Electrolytic . . 2020 012 93596 2447 Cap, 470u, ±20%, 16v, Electrolytic .
  • Page 179 27PT81S125 (continued) 3201 Res, 150 ohm, 5%, 1/6W, Carbon Film. . 3198 011 01510 3487 Res, 1 ohm, 5%, 1/2W, Metal Film . . . 2306 207 03108 3202 Res, 220K, 5%, 1/10W, Metalized Glass. 3198 021 52240 3488 Res, 100 ohm, 5%, 1/6W, Carbon Film. . 3198 011 01010 3203 Res, 1K, 5%, 1/6W, Carbon Film .
  • Page 180 27PT81S125 (continued) 4012 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 4711 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 4013 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 4712 Res, Zero ohm, "Chip"...
  • Page 181 27PT81S125 (continued) 6929 Diode, Rect, BYD33D ..9337 234 00133 9232 Jumper ....0322 179 00003 6932 Diode, Signal.
  • Page 182 27PT81S125 (continued) 9495 Jumper ....0322 179 00003 2302 Cap, 330p, ±5%, 50v, Ceramic ..3198 016 33310 9497 Jumper ....0322 179 00003 2303 Cap, 4n7, ±10%, 50v, Ceramic .
  • Page 183 27PT81S125 (continued) 2638 Cap, 330p, ±10%, 50v, Ceramic..3198 017 33310 3349 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 2639 Cap, 330p, ±10%, 50v, Ceramic..3198 017 33310 3358 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 2640...
  • Page 184 27PT81S125 (continued) 4451 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 3861 Res, 3K3, 5%, 1/10W, Metalized Glass . 3198 021 53320 4455 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 3862 Res, 3K3, 5%, 1/10W, Metalized Glass .
  • Page 185 27PT81S125 (continued) 2806 Cap, 220u, ±20%, 10v, Electrolytic . . 3198 025 12210 3845 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2807 Cap, 47p, ±5%, 50v, Ceramic..3198 016 04790 3849 Res, 1K, 5%, 1/10W, Metalized Glass.
  • Page 186 27PT81S125 (continued) 7804 Transistor, NPN, BC847B(COL) ..3198 010 42030 0167 Cable Asm....3139 110 38951 7805 Transistor, NPN, BC847B(COL) ..3198 010 42030 0224 6 Pin Connector.
  • Page 187 27PT81S125 (continued) AC18 Quick Use Guide... . 3135 015 21351 AC19 Remote Transmitter ..3139 128 76191 AC20 Speaker, 16 ohm, 5 Watt (2 Used) . . . 3139 128 76071 AC25 Power Button .
  • Page 188 27PT91S125 - Manual no. 7592 2419 Cap, 360n, ±5%, 250v, Metalized Polypro Large Signal Panel 0114 Heatsink, Bridge Rectifier ..3139 121 61782 pylene ....
  • Page 189 27PT91S125 (continued) 2977 Cap, 100u, ±20%, 10v, Electrolytic . . 3198 025 11010 3476 Res, 4K7, 5%, 1/6W, Carbon Film..3198 011 04720 3037 Res, 1K8, 5%, 1/10W, Metalized Glass . 3198 021 51820 3477 Res, 12K, 5%, 1/6W, Carbon Film..3198 011 01230 3038 Res, 1K8, 5%, 1/10W, Metalized Glass .
  • Page 190 27PT91S125 (continued) 3989 Res, 330K, 5%, 1/10W, Metalized Glass. 3198 021 53340 4412 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3991 Res, 22K, 5%, 1/6W, Carbon Film..3198 011 02230 4502 Res, Zero ohm, "Chip"...
  • Page 191 27PT91S125 (continued) 6481 Zener Diode, 33 volt ..3198 010 53390 9218 Jumper ....0322 179 00003 6505 Diode, Rect, BYD33D .
  • Page 192 27PT91S125 (continued) 9430 Jumper ....0322 179 00003 2016 Cap, 100n, ±10%, 16v, Ceramic..3198 017 31040 9431 Jumper ....0322 179 00003 2017 Cap, 100n, ±10%, 16v, Ceramic.
  • Page 193 27PT91S125 (continued) 2443 Cap, 10n, ±10%, 50v, Ceramic ..3198 017 31030 3057 Res, 10K, 5%, 1/16W, Metalized Glass . 3198 021 31030 2444 Cap, 10n, ±10%, 50v, Ceramic ..3198 017 31030 3058 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 2445...
  • Page 194 27PT91S125 (continued) 3429 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 6419 Diode, Regulator ... 9322 112 83685 3430 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 6420 Diode, Regulator .
  • Page 195 27PT91S125 (continued) 3881 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2345 Cap, 47p, ±5%, 50v, Ceramic..3198 016 04790 3882 Res, 220 ohm, 5%, 1/6W, Carbon Film. . 3198 011 02210 2348 Cap, 47p, ±5%, 50v, Ceramic.
  • Page 196 27PT91S125 (continued) 2874 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 3508 Res, 10M, 5%, 1/16W, Metalized Glass . 3198 021 31060 2876 Cap, 47n, ±10%, 16v, Ceramic ..3198 017 34730 3509 Res, 100 ohm, 5%, 1/10W, Metalized Glas 3198 021 51010 2877...
  • Page 197 27PT91S125 (continued) 5501 Coil, 6u8....3198 018 66880 2115 Cap, 100n, +80/-20%, 25v, Ceramic. . . 3198 023 21040 5816 Inductor, Fixed 100MHz 120ohm..3198 018 90070 2116 Cap, 100n, +80/-20%, 25v, Ceramic.
  • Page 198 27PT91S125 (continued) 2501 Cap, 22p, ±5%, 50v, Ceramic..3198 016 02290 3125 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 2502 Cap, 8p2, ±6%, 50v, Ceramic..3198 016 38280 3126 Res, 100 ohm, 5%, 1/10W, Metalized Glas 3198 021 51010 2503...
  • Page 199 27PT91S125 (continued) 4702 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 6751 Diode, Signal... . . 9322 112 83685 27PT91S/125 CABINET PARTS 6752 Diode, Signal... . . 9322 112 83685 27PT91S/125 CABINET PARTS 6753...
  • Page 200 27RF70S125 - Manual no. 7592 2714 Cap, 100p, ±5%, 50v, Ceramic ..3198 016 01010 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2715 Cap, 100u, ±20%, 50v, Electrolytic . .
  • Page 201 27RF70S125 (continued) 3272 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 3723 Res, 3K3, 5%, 1/10W, Metalized Glass . 3198 021 53320 3273 Res, 22K, 5%, 1/10W, Metalized Glass . 3198 021 52230 3724 Res, 4K7, 5%, 1/10W, Metalized Glass . 3198 021 54720 3274 Res, 150K, 5%, 1/10W, Metalized Glass.
  • Page 202 27RF70S125 (continued) 4248 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 5936 Inductor, Fixed, Bead, 100MHz, 50ohm . 3198 018 90010 4249 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 5939 Coil, 27u.
  • Page 203 27RF70S125 (continued) 7932 Transistor, NPN, BC847B(COL) ..3198 010 42030 9274 Jumper ....0322 179 00003 7942 IC ....9337 220 80682 9275 Jumper .
  • Page 204 27RF70S125 (continued) 9966 Jumper ....0322 179 00003 2380 Cap, 10u, ±20%, 16v, Electrolytic. . . 3198 030 41090 9968 Jumper ....0322 179 00003 2381 Cap, 100n, +80/-20%, 25v, Ceramic.
  • Page 205 27RF70S125 (continued) 3024 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 3418 Res, 560 ohm, 5%, 1/10W, Metalized Glas 3198 021 55610 3030 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 3419 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 3031 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 3422...
  • Page 206 27RF70S125 (continued) 7407 IC ....9351 750 00118 6835 Diode, Signal... . . 3198 010 10070 7412 Transistor, NPN, BC847BS .
  • Page 207 27RF70S125 (continued) 2892 Cap, 47u, ±20%, 25v, Electrolytic. . . 3198 025 34790 4810 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2893 Cap, 220u, ±20%, 25v, Electrolytic . . 3198 025 32210 4812 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2894 Cap, 10n, ±10%, 50v, Ceramic .
  • Page 208 27RF70S125 (continued) 7752 Transistor, NPN, BC847B(COL) ..3198 010 42030 7753 Transistor, PNP, BC857B(COL) ..3198 010 42150 7754 Transistor, NPN, BC847B(COL) ..3198 010 42030 M-Link Assembly (With Matrix)..3139 178 89081 M-Link Assembly (W/O M-Link) M-Link Assembly (W/O M-Link)
  • Page 209 29LP602221 - Manual no. 7592 2417 Cap, 470p, ±10%, 500v, Ceramic ..3198 019 44710 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2419 Cap, 220n, ±5%, 250v, Metalized Polypro pylene .
  • Page 210 29LP602221 (continued) 2962 Cap, 4u7, ±20%, 16v, Electrolytic. . . 2020 012 93456 3446 Res, 1 ohm, 5%, 1/2W, Metal Film . . . 2306 207 03108 2963 Cap, 220n, ±10%, 16v, Ceramic..2238 780 15654 3447 Res, 1 ohm, 5%, 1/2W, Metal Film .
  • Page 211 29LP602221 (continued) 3958 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 4293 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3959 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 4294 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3961 Res, 1K, 5%, 2 1/2W, Metal Film.
  • Page 212 29LP602221 (continued) 6440 Diode, Signal... . . 3198 010 10010 9032 Jumper ....0322 179 00003 6442 Diode, Signal.
  • Page 213 29LP602221 (continued) 9404 Jumper ....0322 179 00003 9986 Jumper ....0322 179 00003 9406 Jumper .
  • Page 214 29LP602221 (continued) 2424 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3061 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 2425 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3062 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 2427 Cap, 10n, +80/-20%, 50v, Ceramic .
  • Page 215 29LP602221 (continued) 3474 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 3477 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 PIP Panel (2 Tuner) 3478 Res, 10 ohm, 5%, 1/16W, Metalized Glass 3198 021 31090 PIP Panel (2 Tuner) 3483 Res, 560 ohm, 5%, 1/10W, Metalized Glas 3198 021 55610...
  • Page 216 29LP602221 (continued) 3818 Res, 15K, 5%, 1/10W, Metalized Glass . 3198 021 51530 4810 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3819 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 4812 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3820 Res, 1K, 5%, 1/10W, Metalized Glass.
  • Page 217 29LP602221 (continued) 4701 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 AC18 Quick Use Guide... . 3135 015 17711 4702 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 AC19 Remote Transmitter .
  • Page 218 32PT41B121 - Manual no. 7592 2411 Cap, 390p, ±10%, 2000v, Ceramic..2020 558 90482 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2415 Cap, 11n, ±5%, 1600v, Polypropylene. . 2222 375 90155 2416 Cap, 1n8, ±10%, 2000v, Ceramic .
  • Page 219 32PT41B121 (continued) 2941 Cap, 1n, ±10%, 500v, Ceramic ..3198 019 41020 3441 Res, 6K8, 5%, 1/6W, Carbon Film..3198 011 06820 2942 Cap, 220n, ±10%, 50v, Polyester..3198 014 02240 3442 Res, 1M, 5%, 1/10W, Metalized Glass.
  • Page 220 32PT41B121 (continued) 3911 Positive Temperature Coefficient, DC, 1 4269 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 20V, 3ohm, P3... . . 2120 661 00025 4270 Res, Zero ohm, "Chip"...
  • Page 221 32PT41B121 (continued) 6266 Diode, Signal... . . 3198 010 10630 7990 Transistor, PNP, BC857B(COL) ..3198 010 42150 6267 Zener Diode, 8.2 volt..9322 150 07685 7991 Transistor, NPN, BC847B(COL) .
  • Page 222 32PT41B121 (continued) 9280 Jumper ....0322 179 00003 9972 Jumper ....0322 179 00003 9281 Jumper .
  • Page 223 32PT41B121 (continued) 2401 Cap, 1u, +80/-20%, 10v, Ceramic..3198 017 41050 3034 Res, 47K, 5%, 1/16W, Metalized Glass . 3198 021 34730 2402 Cap, 1u, +80/-20%, 10v, Ceramic..3198 017 41050 3035 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 2403 Cap, 1u, +80/-20%, 10v, Ceramic.
  • Page 224 32PT41B121 (continued) 3423 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 7425 Transistor, NPN, BC847BW(COL)..3198 010 42310 3424 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 7442 Transistor, NPN, BC847BW(COL)..3198 010 42310 3425 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010...
  • Page 225 32PT41B121 (continued) 3807 Res, 1K5, 5%, 1/10W, Metalized Glass . 3198 021 51520 7804 Transistor, NPN, BC847B(COL) ..3198 010 42030 3812 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 7805 Transistor, NPN, BC847B(COL) ..3198 010 42030 3813 Res, 15K, 5%, 1/10W, Metalized Glass .
  • Page 226 32PT41B121 (continued) 0240 11 Pin Connector ... 2422 025 12485 1254 Socket, Phone... . . 2422 026 04747 1255 Socket ....2422 026 05026 1256 Socket .
  • Page 227 32PT41B129 - Manual no. 7592 2442 Cap, 100n, +80/-20%, 25v, Ceramic. . . 3198 023 21040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2445 Cap, 22u, ±20%, 250v, Electrolytic . . 2020 012 93596 2447 Cap, 470u, ±20%, 16v, Electrolytic .
  • Page 228 32PT41B129 (continued) 2050 Cap, 100p, ±5%, 50v, Ceramic ..3198 016 31010 2629 Cap, 10u, ±20%, 16v, Electrolytic. . . 3198 030 41090 2051 Cap, 100n, ±10%, 16v, Ceramic..3198 017 31040 2635 Cap, 1u, +80/-20%, 10v, Ceramic.
  • Page 229 32PT41B129 (continued) 3340 Res, 560 ohm, 5%, 1/10W, Metalized Glas 3198 021 55610 4402 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3341 Res, 150 ohm, 5%, 1/16W, Metalized Glas 3198 021 31510 4403 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3342 Res, Zero ohm, "Chip"...
  • Page 230 32PT41B129 (continued) 2812 Cap, 47u, ±20%, 25v, Electrolytic. . . 3198 025 34790 3914 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2813 Cap, 10u, ±20%, 50v, Electrolytic. . . 3198 025 51090 3915 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2814 Cap, 10n, ±10%, 50v, Ceramic .
  • Page 231 32PT41B129 (continued) 9923 Jumper ....3198 036 90010 S AC01 AC Power Cord... . . 3135 010 03831 PIP Panel.
  • Page 232 32PT71B121 - Manual no. 7592 2409 Cap, 100n, ±10%, 50v, Polyester..3198 014 01040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2411 Cap, 390p, ±10%, 2000v, Ceramic..
  • Page 233 32PT71B121 (continued) 2939 Cap, 47u, ±20%, 160v, Electrolytic . . 2020 021 91358 3440 Res, 100K, 5%, 1/10W, Metalized Glass. 3198 021 51040 2941 Cap, 1n, ±10%, 500v, Ceramic ..3198 019 41020 3441 Res, 6K8, 5%, 1/6W, Carbon Film..3198 011 06820 2942 Cap, 220n, ±10%, 50v, Polyester.
  • Page 234 32PT71B121 (continued) 3902 Res, 2M2, 5%, 1/2W, Metalized Glass. . 2322 242 13225 4268 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3911 Positive Temperature Coefficient, DC, 1 4269 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 20V, 3ohm, P3.
  • Page 235 32PT71B121 (continued) 6208 Zener Diode, 12 volt ..3198 020 51290 7971 IC ....9322 116 23682 6238 Diode, Signal.
  • Page 236 32PT71B121 (continued) 9278 Jumper ....0322 179 00003 9968 Jumper ....0322 179 00003 9279 Jumper .
  • Page 237 32PT71B121 (continued) 2380 Cap, 10u, ±20%, 16v, Electrolytic. . . 3198 030 41090 3024 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 2381 Cap, 100n, +80/-20%, 25v, Ceramic. . . 3198 023 41040 3030 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 2382 Cap, 47u, ±20%, 16v, Electrolytic.
  • Page 238 32PT71B121 (continued) 3423 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 7425 Transistor, NPN, BC847BW(COL)..3198 010 42310 3424 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 7442 Transistor, NPN, BC847BW(COL)..3198 010 42310 3425 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010...
  • Page 239 32PT71B121 (continued) 2931 Cap, 100n, ±10%, 16v, Ceramic..3198 017 01040 3957 Res, 330 ohm, 5%, 1/10W, Metalized Glas 3198 021 53310 2932 Cap, 100n, ±10%, 16v, Ceramic..3198 017 01040 3958 Res, 120 ohm, 5%, 1/10W, Metalized Glas 3198 021 51210 2933 Cap, 100n, ±10%, 16v, Ceramic.
  • Page 240 32PT71B121 (continued) IR Blaster ....3104 207 10191 S AC01 AC Power Cord... . . 3135 010 03831 S AC02 Anode Clip .
  • Page 241 32PT71B129 - Manual no. 7592 2415 Cap, 12n, ±5%, 1600v, Polypropylene. . 2222 375 90156 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2416 Cap, 1n5, ±10%, 2000v, Ceramic ..
  • Page 242 32PT71B129 (continued) 2942 Cap, 220n, ±10%, 50v, Polyester..3198 014 02240 3442 Res, 1M, 5%, 1/10W, Metalized Glass. . 3198 021 51050 2943 Cap, 3u3, ±20%, 16v, Electrolytic. . . 3198 026 23320 3445 Res, 1 ohm, 5%, 1/2W, Metal Film . . . 2306 207 03108 2945 Cap, 3u3, ±20%, 16v, Electrolytic.
  • Page 243 32PT71B129 (continued) 3913 Res, 100K, 5%, 1W, Metal Film..2322 193 53104 4272 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3917 Res, 2K2, 5%, 1/10W, Metalized Glass . 3198 021 52220 4273 Res, Zero ohm, "Chip"...
  • Page 244 32PT71B129 (continued) 6268 Zener Diode, 8.2 volt..9322 150 07685 7992 Transistor, NPN, BC847B(COL) ..3198 010 42030 6271 Diode, Signal... . . 3198 010 10630 8111 LED.
  • Page 245 32PT71B129 (continued) 9281 Jumper ....0322 179 00003 9973 Jumper ....0322 179 00003 9283 Jumper .
  • Page 246 32PT71B129 (continued) 2401 Cap, 1u, +80/-20%, 10v, Ceramic..3198 017 41050 3034 Res, 47K, 5%, 1/16W, Metalized Glass . 3198 021 34730 2402 Cap, 1u, +80/-20%, 10v, Ceramic..3198 017 41050 3035 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 2403 Cap, 1u, +80/-20%, 10v, Ceramic.
  • Page 247 32PT71B129 (continued) 3426 Res, 820 ohm, 5%, 1/16W, Metalized Glas 3198 021 38210 7630 IC ....9351 874 90118 3427 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 7651 IC .
  • Page 248 32PT71B129 (continued) 2934 Cap, 100n, ±10%, 16v, Ceramic..3198 017 01040 3961 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 2935 Cap, 100u, ±20%, 25v, Electrolytic . . 3198 025 31010 3962 Res, 4K7, 5%, 1/10W, Metalized Glass . 3198 021 54720 2936 Res, Zero ohm, "Chip"...
  • Page 249 32PT71B129 (continued) 0028 MLINK BRACKET-V0 ... 3139 124 32651 AC04 Cabinet Back ... . . 3139 124 32641 0167 Cable Asm....3139 110 38951 AC05 Cabinet Front.
  • Page 250 32PT81S121 - Manual no. 7592 2409 Cap, 100n, ±10%, 50v, Polyester..3198 014 01040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2411 Cap, 1n2, ±10%, 2000v, Ceramic ..
  • Page 251 32PT81S121 (continued) 2963 Cap, 220n, ±10%, 16v, Ceramic..2238 780 15654 3441 Res, 6K8, 5%, 1/6W, Carbon Film..3198 011 06820 2964 Cap, 1n, ±10%, 500v, Ceramic ..3198 019 41020 3442 Res, 560K, 5%, 1/8W, Metalized Glass .
  • Page 252 32PT81S121 (continued) 3961 Res, 1K, 5%, 2 1/2W, Metal Film..3198 012 31020 4292 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3962 Res, 5K6, 5%, 1/10W, Metalized Glass . 3198 021 55620 4293 Res, Zero ohm, "Chip"...
  • Page 253 32PT81S121 (continued) 6442 Diode, Signal... . . 3198 010 10010 9032 Jumper ....0322 179 00003 6445 Diode, Rect, BYD33J .
  • Page 254 32PT81S121 (continued) 9406 Jumper ....0322 179 00003 9996 Jumper ....0322 179 00003 9407 Jumper .
  • Page 255 32PT81S121 (continued) 2431 Cap, 27p, ±5%, 50v, Ceramic..3198 016 32790 3082 Res, 10K, 5%, 1/16W, Metalized Glass . 3198 021 31030 2432 Cap, 10u, ±20%, 16v, Electrolytic. . . 3198 030 41090 3083 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 2435 Cap, 10u, ±20%, 16v, Electrolytic.
  • Page 256 32PT81S121 (continued) 3489 Res, 390 ohm, 5%, 1/16W, Metalized Glas 3198 021 33910 2843 Cap, 2n2, ±10%, 2000v, Ceramic ..2020 558 90559 3490 Res, 390 ohm, 5%, 1/16W, Metalized Glas 3198 021 33910 2860 Cap, 100u, ±20%, 25v, Electrolytic . . 3198 025 31010 3491 Res, 820 ohm, 5%, 1/16W, Metalized Glas 3198 021 38210...
  • Page 257 32PT81S121 (continued) CRT M-Board....3139 127 20831 3802 Res, 100 ohm, 5%, 1/10W, Metalized Glas 3198 021 51010 3805 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 SUB-ASSEMBLY 3806 Res, 1K5, 5%, 1/10W, Metalized Glass .
  • Page 258 32PT81S121 (continued) 3969 Res, 330 ohm, 5%, 1/10W, Metalized Glas 3198 021 53310 0167 Cable Asm....3139 110 38951 3970 Res, 390 ohm, 5%, 1/10W, Metalized Glas 3198 021 53910 0224 6 Pin Connector.
  • Page 259 32PT81S121 (continued) AC16 Owner's Manual ... . 3135 015 21381 AC17 Owner's Manual for M-Link..3135 015 21201 AC18 Quick Use Guide... . 3135 015 21371 AC19 Remote Transmitter .
  • Page 260 32PT81S127 - Manual no. 7592 2409 Cap, 100n, ±10%, 50v, Polyester..3198 014 01040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2411 Cap, 1n, ±10%, 2000v, Ceramic..
  • Page 261 32PT81S127 (continued) 2962 Cap, 4u7, ±20%, 10v, Electrolytic. . . 2020 021 91501 3438 Res, 470K, 5%, 1/10W, Metalized Glass. 3198 021 54740 2963 Cap, 220n, ±10%, 16v, Ceramic..2238 780 15654 3439 Res, 1K, 5%, 1/6W, Carbon Film ..3198 011 01020 2964 Cap, 1n, ±10%, 500v, Ceramic .
  • Page 262 32PT81S127 (continued) 3957 Res, 1K8, 5%, 1/10W, Metalized Glass . 3198 021 51820 4287 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3958 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 4288 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3959 Res, 10K, 5%, 1/10W, Metalized Glass .
  • Page 263 32PT81S127 (continued) 6420 Diode, Rect, BYD33D ..9337 234 00133 9027 Jumper ....0322 179 00003 6439 Zener Diode, 27 volt .
  • Page 264 32PT81S127 (continued) 9401 Jumper ....0322 179 00003 9990 Jumper ....0322 179 00003 9402 Jumper .
  • Page 265 32PT81S127 (continued) 2427 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3064 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 2428 Cap, 10n, +80/-20%, 50v, Ceramic . . . 3198 017 41030 3065 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 2429 Cap, 10n, +80/-20%, 50v, Ceramic .
  • Page 266 32PT81S127 (continued) 3478 Res, 10 ohm, 5%, 1/16W, Metalized Glass 3198 021 31090 2460 Cap, 10u, ±20%, 160v, Electrolytic . . 2020 012 93321 3483 Res, 560 ohm, 5%, 1/10W, Metalized Glas 3198 021 55610 2464 Cap, 2n2, ±10%, 500v, Ceramic..2020 557 90447 3484 Res, 1K, 5%, 1/16W, Metalized Glass.
  • Page 267 32PT81S127 (continued) 2892 Cap, 47u, ±20%, 25v, Electrolytic. . . 3198 025 34790 3938 Res, 2R2, 5%, 1/6W, Carbon Film..3198 011 02280 2893 Cap, 220u, ±20%, 25v, Electrolytic . . 3198 025 32210 3939 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2894 Cap, 10n, ±10%, 50v, Ceramic .
  • Page 268 32PT81S127 (continued) 9821 Jumper ....0322 179 00003 3095 Res, 3K3, 5%, 1/10W, Metalized Glass . 3198 021 53320 9822 Jumper ....0322 179 00003 3096 Res, 1K5, 5%, 1/10W, Metalized Glass .
  • Page 269 32PT81S128 - Manual no. 7592 2442 Cap, 100n, +80/-20%, 25v, Ceramic. . . 3198 023 21040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2445 Cap, 22u, ±20%, 250v, Electrolytic . . 2020 012 93596 2447 Cap, 470u, ±20%, 16v, Electrolytic .
  • Page 270 32PT81S128 (continued) 2964 Cap, 1n, ±10%, 500v, Ceramic ..3198 019 41020 3476 Res, 4K7, 5%, 1/6W, Carbon Film..3198 011 04720 2966 Cap, 100u, ±20%, 10v, Electrolytic . . 3198 025 11010 3477 Res, 12K, 5%, 1/6W, Carbon Film.
  • Page 271 32PT81S128 (continued) 3892 Vage Dependent Resistor, DC, 1mA/ 50Vol 4272 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 t, Max 115 ....2322 593 13507 4273 Res, Zero ohm, "Chip"...
  • Page 272 32PT81S128 (continued) 6420 Diode, Rect, BYD33D ..9337 234 00133 9021 Jumper ....0322 179 00003 6439 Zener Diode, 27 volt .
  • Page 273 32PT81S128 (continued) 9294 Jumper ....0322 179 00003 9990 Jumper ....0322 179 00003 9295 Jumper .
  • Page 274 32PT81S128 (continued) 2430 Cap, 68p, ±5%, 50v, Ceramic..3198 016 36890 3066 Res, 8K2, 5%, 1/16W, Metalized Glass . 3198 021 38220 2431 Cap, 27p, ±5%, 50v, Ceramic..3198 016 32790 3081 Res, 4K7, 5%, 1/16W, Metalized Glass .
  • Page 275 32PT81S128 (continued) 3489 Res, 390 ohm, 5%, 1/16W, Metalized Glas 3198 021 33910 0201 10 Pin Connector ... 2422 025 12484 3490 Res, 390 ohm, 5%, 1/16W, Metalized Glas 3198 021 33910 0205 10 Pin Connector .
  • Page 276 32PT81S128 (continued) 3856 Res, 1K, 5%, 1/10W, Metalized Glass. . 3198 021 51020 0025 SHIELD 56P 8 ... . . 3139 121 26532 3859 Res, 47K, 5%, 1/10W, Metalized Glass . 3198 021 54730 0162 Cable Asm.
  • Page 277 32PT81S128 (continued) 3853 Res, 3K3, 5%, 1/10W, Metalized Glass . 3198 021 53320 0028 MLINK BRACKET-V0 ... 3139 124 32651 3854 Res, 15K, 5%, 1/10W, Metalized Glass . 3198 021 51530 0167 Cable Asm.
  • Page 278 32PT81S128 (continued) 1008 LED....9322 050 99682 2001 Cap, 100u, ±20%, 25v, Electrolytic . . 3198 025 31010 3001 Res, 470 ohm, 5%, 1/6W, Carbon Film. . 3198 011 04710 3003 Res, 680 ohm, 5%, 1/6W, Carbon Film.
  • Page 279 32PT91S121 - Manual no. 7592 2281 Cap, 220p, ±5%, 50v, Ceramic ..3198 016 02210 Large Signal Panel 0114 Heatsink, Bridge Rectifier ..3139 121 61782 2282 Capacitor, Ceramic, 47nF, 50V ..
  • Page 280 32PT91S121 (continued) 2943 Cap, 3u3, ±20%, 16v, Electrolytic. . . 3198 026 23320 3417 Res, 680 ohm, 5%, 1/6W, Carbon Film. . 3198 011 06810 2945 Cap, 3u3, ±20%, 16v, Electrolytic. . . 3198 026 23320 3430 Res, 22 ohm, 5%, 2 1/2W, Metal Film. . 3198 012 32290 2961 Cap, 1n, ±10%, 500v, Ceramic .
  • Page 281 32PT91S121 (continued) 3944 Res, 22K, 5%, 1/6W, Carbon Film..3198 011 02230 4281 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3947 Res, 1K, 1%, 1/8W, Metalized Glass . . 2322 734 61002 4282 Res, Zero ohm, "Chip"...
  • Page 282 32PT91S121 (continued) 6276 Diode, Signal... . . 3198 010 10630 9017 Jumper ....0322 179 00003 6279 Zener Diode, 5.6 volt.
  • Page 283 32PT91S121 (continued) 9294 Jumper ....0322 179 00003 9984 Jumper ....0322 179 00003 9295 Jumper .
  • Page 284 32PT91S121 (continued) 2407 Cap, 100n, ±10%, 16v, Ceramic..3198 017 31040 3004 Res, 8K2, 5%, 1/16W, Metalized Glass . 3198 021 38220 2408 Cap, 100n, ±10%, 16v, Ceramic..3198 017 31040 3007 Res, 8K2, 5%, 1/16W, Metalized Glass .
  • Page 285 32PT91S121 (continued) 3393 Res, 27K, 5%, 1/10W, Metalized Glass . 3198 021 52730 4642 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 3394 Res, 18K, 5%, 1/16W, Metalized Glass . 3198 021 31830 5040 Coil, 4u7....3198 018 64780 3397 Res, 10 ohm, 5%, 1/16W, Metalized Glass 3198 021 31090...
  • Page 286 32PT91S121 (continued) 3834 Res, 1K, 20%, 1/2W, Carbon Film..3198 013 01020 3461 Res, 100K, 5%, 1/6W, Carbon Film . . . 3198 011 01040 3835 Res, 100 ohm, 5%, 1/6W, Carbon Film. . 3198 011 01010 3462 Res, 6K8, 5%, 1/6W, Carbon Film.
  • Page 287 32PT91S121 (continued) 2415 Cap, 220n, +80/-20%, 16v, Ceramic. . . 3198 017 42240 3333 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 2431 Cap, 100n, ±10%, 16v, Ceramic..3198 017 31040 3334 Res, Zero ohm, "Chip" Jumper ..3198 021 90030 2432 Cap, 100n, ±10%, 16v, Ceramic.
  • Page 288 32PT91S121 (continued) 3828 Res, 220 ohm, 5%, 1/16W, Metalized Glas 3198 021 32210 7411 Transistor, NPN, BC847BW(COL)..3198 010 42310 3829 Res, 220 ohm, 5%, 1/16W, Metalized Glas 3198 021 32210 7412 Transistor, NPN, BC847BW(COL)..3198 010 42310 3831 Res, 220 ohm, 5%, 1/16W, Metalized Glas 3198 021 32210...
  • Page 289 32PT91S121 (continued) 2204 Cap, 100u, +80/-20%, 5.5v, Electrolytic 2020 025 90023 2831 Cap, 1u, +80/-20%, 16v, Ceramic..3198 017 21050 2207 Cap, 100n, +80/-20%, 25v, Ceramic. . . 3198 023 21040 2832 Cap, 1u, +80/-20%, 16v, Ceramic..3198 017 21050 2209 Cap, 100n, +80/-20%, 25v, Ceramic.
  • Page 290 32PT91S121 (continued) 3155 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 0161 Cable Assm ....3139 131 00731 3202 Res, 27K, 5%, 1/10W, Metalized Glass . 3198 021 52730 0240 11 Pin Connector .
  • Page 291 32RF50S127 - Manual no. 7592 0121 Deflection, Heatsink ..3139 121 62071 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 0122 Sanken Heatsink... .
  • Page 292 32RF50S127 (continued) 2447 Cap, 470u, ±20%, 16v, Electrolytic . . 3198 025 24710 3029 Res, 4K7, 5%, 1/10W, Metalized Glass . 3198 021 54720 2450 Cap, 470u, ±20%, 16v, Electrolytic . . 3198 025 24710 3030 Res, 1K2, 5%, 1/10W, Metalized Glass . 3198 021 51220 2462 Cap, 100u, ±20%, 50v, Electrolytic .
  • Page 293 32RF50S127 (continued) 3476 Res, 4K7, 5%, 1/6W, Carbon Film..3198 011 04720 3987 Res, 10K, 5%, 1/10W, Metalized Glass . 3198 021 51030 3477 Res, 12K, 5%, 1/6W, Carbon Film..3198 011 01230 3989 Res, 330K, 5%, 1/10W, Metalized Glass.
  • Page 294 32RF50S127 (continued) 4408 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 6916 Diode, Rect, BYV10-40 ..9337 432 70133 4410 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 6921 Zener Diode, 33 volt .
  • Page 295 32RF50S127 (continued) 9222 Jumper Wire....3198 036 90010 9434 Jumper Wire....3198 036 90010 9226 Jumper Wire.
  • Page 296 32RF50S127 (continued) 2867 Cap, 680p, ±5%, 50v, Ceramic ..3198 016 06810 9401 Jumper Wire....3198 036 90010 2868 Cap, 100p, ±5%, 50v, Ceramic ..3198 016 01010 2869 Cap, 100n, ±10%, 100v, Polyester .
  • Page 297 33LP803221 - Manual no. 7592 2409 Cap, 100n, ±10%, 50v, Polyester..3198 014 01040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2411 Cap, 390p, ±10%, 2000v, Ceramic..
  • Page 298 33LP803221 (continued) 2939 Cap, 47u, ±20%, 160v, Electrolytic . . 2020 021 91358 3440 Res, 100K, 5%, 1/10W, Metalized Glass. 3198 021 51040 2941 Cap, 1n, ±10%, 500v, Ceramic ..3198 019 41020 3441 Res, 6K8, 5%, 1/6W, Carbon Film..3198 011 06820 2942 Cap, 220n, ±10%, 50v, Polyester.
  • Page 299 33LP803221 (continued) 3902 Res, 2M2, 5%, 1/2W, Metalized Glass. . 2322 242 13225 4268 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3911 Positive Temperature Coefficient, DC, 1 4269 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 20V, 3ohm, P3.
  • Page 300 33LP803221 (continued) 6208 Zener Diode, 12 volt ..3198 020 51290 7971 IC ....9322 116 23682 6238 Diode, Signal.
  • Page 301 33LP803221 (continued) 9278 Jumper ....0322 179 00003 9968 Jumper ....0322 179 00003 9279 Jumper .
  • Page 302 33LP803221 (continued) 2380 Cap, 10u, ±20%, 16v, Electrolytic. . . 3198 030 41090 3024 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 2381 Cap, 100n, +80/-20%, 25v, Ceramic. . . 3198 023 41040 3030 Res, 1K, 5%, 1/16W, Metalized Glass. . 3198 021 31020 2382 Cap, 47u, ±20%, 16v, Electrolytic.
  • Page 303 33LP803221 (continued) 3423 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 7425 Transistor, NPN, BC847BW(COL)..3198 010 42310 3424 Res, 4K7, 5%, 1/16W, Metalized Glass . 3198 021 34720 7442 Transistor, NPN, BC847BW(COL)..3198 010 42310 3425 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010...
  • Page 304 33LP803221 (continued) 2931 Cap, 100n, ±10%, 16v, Ceramic..3198 017 01040 3957 Res, 330 ohm, 5%, 1/10W, Metalized Glas 3198 021 53310 2932 Cap, 100n, ±10%, 16v, Ceramic..3198 017 01040 3958 Res, 120 ohm, 5%, 1/10W, Metalized Glas 3198 021 51210 2933 Cap, 100n, ±10%, 16v, Ceramic.
  • Page 305 33LP803221 (continued) IR Blaster ....3104 207 10191 S AC01 AC Power Cord... . . 3135 010 03831 S AC02 Anode Clip .
  • Page 306 36PT41B129 - Manual no. 7592 2409 Cap, 100n, ±10%, 50v, Polyester..3198 014 01040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2411 Cap, 680p, ±10%, 2000v, Ceramic..
  • Page 307 36PT41B129 (continued) 2929 Cap, 2n2, ±20%, 250v, Ceramic..2020 554 90158 3435 Res, 39K, 5%, 1/6W, Carbon Film..3198 011 03930 2932 Cap, 22n, ±10%, 50v, Ceramic ..3198 017 02230 3436 Res, 39K, 5%, 1/6W, Carbon Film.
  • Page 308 36PT41B129 (continued) 3843 Res, 1K5, 20%, 1/2W, Carbon Film . . . 3198 013 01520 4258 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3845 Res, 330K, 5%, 1/6W, Carbon Film . . . 3198 011 03340 4259 Res, Zero ohm, "Chip"...
  • Page 309 36PT41B129 (continued) 6203 Zener Diode, 12 volt ..3198 020 51290 7944 Transistor, NPN, BC847B(COL) ..3198 010 42030 6204 Zener Diode, 12 volt ..3198 020 51290 7950 Transistor, NPN, BC847B(COL) .
  • Page 310 36PT41B129 (continued) 9273 Jumper ....0322 179 00003 9937 Jumper ....0322 179 00003 9274 Jumper .
  • Page 311 36PT41B129 (continued) 2374 Cap, 22n, ±10%, 25v, Ceramic ..3198 017 32230 3019 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 2375 Cap, 1n, ±5%, 25v, Ceramic ..3198 016 31020 3021 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 2376...
  • Page 312 36PT41B129 (continued) 3414 Res, 1K5, 5%, 1/16W, Metalized Glass . 3198 021 31520 7331 Transistor, NPN, BC857BW(COL)..3198 010 42320 3415 Res, 1K5, 5%, 1/16W, Metalized Glass . 3198 021 31520 7368 Transistor, NPN, BC847BW(COL)..3198 010 42310 3416 Res, 560 ohm, 5%, 1/10W, Metalized Glas 3198 021 55610...
  • Page 313 36PT41B129 (continued) 2935 Cap, 100u, ±20%, 25v, Electrolytic . . 3198 025 31010 5890 Coil, 10u....3198 018 21090 2936 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 5891 Coil, 10u.
  • Page 314 36PT41B129 (continued) 0028 Matrix Bracket, W/O MLINK ASSY - GY. . 3139 137 98781 0167 Cable Asm....3139 110 38951 0224 6 Pin Connector... . 2422 025 10738 0245 4 Pin Connector.
  • Page 315 36PT71B129 - Manual no. 7592 2409 Cap, 100n, ±10%, 50v, Polyester..3198 014 01040 Small Signal Panel 7064 IC Micro, 1US1, v4.45, SAA5647 . . . 4835 310 57608 2411 Cap, 680p, ±10%, 2000v, Ceramic..
  • Page 316 36PT71B129 (continued) 2939 Cap, 47u, ±20%, 160v, Electrolytic . . 2020 021 91358 3439 Res, 1K, 5%, 1/6W, Carbon Film ..3198 011 01020 2941 Cap, 1n, ±10%, 500v, Ceramic ..3198 019 41020 3440 Res, 100K, 5%, 1/10W, Metalized Glass.
  • Page 317 36PT71B129 (continued) 3901 Res, 4M7, 5%, 1/2W, Metalized Glass. . 2322 242 13475 4263 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3902 Res, 2M2, 5%, 1/2W, Metalized Glass. . 2322 242 13225 4268 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 3911 Positive Temperature Coefficient, DC, 1...
  • Page 318 36PT71B129 (continued) 6207 Zener Diode, 12 volt ..3198 020 51290 7968 IC ....9322 137 01682 6208 Zener Diode, 12 volt .
  • Page 319 36PT71B129 (continued) 9277 Jumper ....0322 179 00003 9966 Jumper ....0322 179 00003 9278 Jumper .
  • Page 320 36PT71B129 (continued) 2377 Cap, 1n, ±5%, 25v, Ceramic ..3198 016 31020 3023 Res, 8K2, 5%, 1/16W, Metalized Glass . 3198 021 38220 2380 Cap, 10u, ±20%, 16v, Electrolytic. . . 3198 030 41090 3024 Res, 1K, 5%, 1/16W, Metalized Glass.
  • Page 321 36PT71B129 (continued) 3422 Res, 470 ohm, 5%, 1/16W, Metalized Glas 3198 021 34710 7421 Transistor, NPN, BC847BW(COL)..3198 010 42310 3423 Res, 100 ohm, 5%, 1/16W, Metalized Glas 3198 021 31010 7425 Transistor, NPN, BC847BW(COL)..3198 010 42310 3424 Res, 4K7, 5%, 1/16W, Metalized Glass .
  • Page 322 36PT71B129 (continued) 2930 Cap, 100n, ±10%, 16v, Ceramic..3198 017 01040 3956 Res, Zero ohm, "Chip" Jumper ..3198 021 90020 2931 Cap, 100n, ±10%, 16v, Ceramic..3198 017 01040 3957 Res, 330 ohm, 5%, 1/10W, Metalized Glas 3198 021 53310 2932...
  • Page 323 36PT71B129 (continued) IR Blaster ....3104 207 10191 S AC01 AC Power Cord... . . 3135 010 03831 S AC02 Anode Clip .

Table of Contents
