Mach M72I Specifications

M M72I
ACH
K F
EY EATURES
• Horizontal and vertical flying
• Speakon terminal with link option
• Modular crossover
• 19 mm MDF cabinet
• 2mm extruded aluminum profiles
• Thermal protection of the tweeter
• Build-in handles
• 8" mid device
• 1" horn tweeter cooled with magnetic oil
D
ESCRIPTION
The M72i is the smallest enclosure in the Installation Series. Despite its
physical dimensions, the M72i is capable of reproducing hi-fi-like sound at
medium SPL's.
With a wide dispersion, the M72i is a near-field speaker, suitable for bars,
café's and smaller clubs or as in-fill in seating areas.
The robust bass reflex cabinet is designed around an extruded 2mm
aluminium profile. It houses a 8" mid-unit with a very extended frequency
response and a 1" soft dome cooled by magnetic oil. It is a dedicated
top-box, designed to be supported by the M151i subwoofer below 100
Hz.
The M72i offers four built-in flying points for easy horizontal or vertical
fixing. A customised multi bracket is available as well. The trapezoidal
cabinet shape allows flexible and discrete fixing in low ceiling
applications. The M72i can be fittet with an external top-hat adapter.
This model is also available in white.
Martin Professional A/S · Olof Palmes Allé 18 · DK-8200 Aarhus N · Phone: +45 87 40 00 00 · Fax: +45 87 40 00 10 · Internet: www.martin.dk
S
PECIFICATIONS
Power rating IEC268:
Power rating peak:
Sensitivity 1w/1m:
Max SPL, calculated long term:
Max SPL, peak:
Frequency range +/-3dB:
Nominal impedance:
Recommended amplifier:
Weight & Measurements:
Dimensions (HxWxD):
Net weight:
Finish:
Grille:
Input connectors:
Top-hat adapter:
Rigging hardware:
A S
RCHITECTURAL PECIFICATIONS
The loudspeaker system shall be a two-way reflex loaded top-box with an
IEC268 power handling of 150 watt and a frequency response from 80-
20kHz with crossover frequencies at 4 kHz. The loudspeaker system shall
have an 8" low/mid driver and a 1" soft dome tweeter cooled with mag-
netic oil, each with an 8-ohm load. The loudspeaker shall also have six
rear mounted M10 attachment points for a customized bracket and an M8
attachment point in top and bottom plates, which shall be protected with
the SafeCoat surface. The enclosure shall be constructed of 19mm
Medium Density Fiber, built around an aluminum frame, equipped with
internal metal bracing, trapezoidal in shape with a 15 degree angle and
shall be 40cm(16in) high, 33cm(13in) wide and 35cm(14in) deep with a
weight of 12kg(26lbs). The loudspeaker system shall be the Mach M72i.
NOTE: Mach is continually working in reseach and production improvements,
which can be introduced into existing products without notice. The products will
always equal or exceed the original design specifications unless otherwise stated.
150 watt
600 watt
94 dB
117 dB
123 dB
80 Hz - 20 kHz
8 ohm
200 watt in 8 ohm
40x33x35 cm (16x13x14 in)
12 kg / 26 lbs
Black SafeCoat coating
2 mm steel with foam backing
2 x Speakon® NL 4
External 93943007
Eyebolt part no. 93940002
U-bracket (fixed) part no.
93943008
Multi bracket part no. 93943012
