Honeywell T7300F Series Specification
Series 2000 commercial thermostat and communicating subbase
Hide thumbs
Also See for T7300F Series:
- Installation instructions manual (13 pages) ,
- Manual specification (8 pages) ,
- Product data (40 pages)
Advertisement
Quick Links
APPLICATION
The T7300F Series 2000 Commercial Thermostat and
Q7300H Communicating Subbase control 24 Vac commercial
single-zone multistage heating, ventilating and air conditioning
(HVAC) equipment. Additionally, the Q7300H Subbase allows
remote access and the sharing of clock, schedule, setpoints,
bypass and other system parameters with other devices in a
®
L
W
network.
ON
ORKS
® U.S. Registered Trademark
Copyright © 2001 Honeywell • All Rights Reserved
Commercial Thermostat and
Q7300H Communicating Subbase
T7300F Series 2000
FEATURES
T7300F
• For use with multistage conventional or heat pump
applications.
• Proportional plus Integral (P+I) control eliminates
temperature fluctuations.
®
• Intelligent Recovery
control automatically optimizes
equipment start times based on building load.
®
• Intelligent Fan
feature energizes fan continuously in
the Occupied periods. Fan can also be configured for
conventional heat or electric heat fan operation.
• 7-day programmable with four periods per day.
• Configurable reversing valve operation.
• Selectable automatic or manual changeover.
• Remote sensor capability.
• Keypad lockout available.
• Auxiliary contacts can interface with C7400/W7459
Economizer System for total rooftop control
integration.
Q7300H
• Provides networking capability on a L
using a Free Topology Transceiver (FTT).
ARK ®
• Conforms to L
M
ON
• Dial-in capability allows remote monitoring and control
of key variables such as time, schedule, setpoints,
mode, fan status.
• Communicates schedule information to other network
devices.
• Selects fan operation and system mode using a remote
T7300F Thermostat.
• Shares information such as time-of-day, temporary
setpoint and occupancy status with multiple T7300 or
Excel 10 controllers.
• Installer setup may be done locally from the T7300
keypad or from a local or remote personal computer.
• Fully integrated with Honeywell's light commercial
building solutions to provide enhanced alarming,
trending, scheduling and dial-out capabilities.
®
®
SPECIFICATION DATA
W
Bus
ON
ORKS
thermostat functional profile.
63-1281-1
Advertisement
Related Manuals for Honeywell T7300F Series
Summary of Contents for Honeywell T7300F Series
- Page 1 Q7300H Communicating Subbase APPLICATION The T7300F Series 2000 Commercial Thermostat and Q7300H Communicating Subbase control 24 Vac commercial single-zone multistage heating, ventilating and air conditioning (HVAC) equipment. Additionally, the Q7300H Subbase allows remote access and the sharing of clock, schedule, setpoints, bypass and other system parameters with other devices in a ®...
-
Page 2: Specifications
T7300F SERIES 2000 COMMERCIAL THERMOSTAT AND Q7300H COMMUNICATING SUBBASE SPECIFICATIONS Models Available: Q7300H Subbase: The Q7300H Series 2000 Communicating Subbase includes terminals for connection to the L ORKS jack for quick access by personal computer based tools. Additionally, a communications service-pin pushbutton is provided to simplify startup. - Page 3 T7300F SERIES 2000 COMMERCIAL THERMOSTAT AND Q7300H COMMUNICATING SUBBASE 6-11/16 (170) 3-3/16 (77) 7-5/16 (186) Set Tempera ture Set Program Occupied Unoccupied Occupied Program Start Time Start Time Temp Set Current Temporary Clear Copy Day/Time Occupied Start Time Continous System Unoccupied Fig.
- Page 4 T7300F SERIES 2000 COMMERCIAL THERMOSTAT AND Q7300H COMMUNICATING SUBBASE Fig. 2. Functional Profile Number 8060—L (Thermostat profile variables not used are grayed). NOTE: For additional information on the L Guidelines and the L Functional Profile: Thermostat. Both documents are available from L address: www.lonmark.org.
