Electro-Voice PolarChoice 12 Specifications

Description
The PolarChoice ™ 12 and PolarChoice
are back-electret condenser gooseneck
podium microphones designed for sound
reinforcement systems where sound clarity
and gain-before-feedback are of major
importance. The flat-bladed screwdriver
activated rotary selector switch has the
following settings:
Switch Setting Polar Pattern
0 Omnidirectional
1 Cardioid
2 Supercardioid
3 Hypercardioid
Altering the polar pattern does not change
the on-axis sonic character of the micro-
phone; therefore changes in equalizer set-
tings are unnecessary.
™
The PolarChoice 12 and PolarChoice
are acoustically designed for high-quality
sound reinforcement and broadcast applica-
tions. The frequency response is tailored for
wide-range sound reproduction with very
natural sound pick-up for either distant or
close-up use. The small-diameter gooseneck
has two supple joints and a rigid center tube.
The rigid tube prevents unsightly twisting
of the gooseneck but permits the user to ex-
actly position the microphone. The electron-
ics housing's 3/4-inch diameter base is ter-
™ 18 minated with an XLR-type 3-pin connector
which allows the microphone to be plugged
directly into an existing panel-mount XLR
receptacle. The housing is machined steel
for ruggedness and superior EMI/RFI
attenuation. The PolarChoice
™
PolarChoice 18 are designed to be phan-
tom-powered with a wide voltage range of
9-52V dc (DIN Standard 45 596).
Applications
™
The PolarChoice
can be used on lecterns, podiums, desk and
table-tops, or other applications which re-
quire a quick plug-in gooseneck microphone.
To maximize gain-before-feedback the
™
PolarChoice 's multipolar design has three
directional polar patterns which allow the
™
18 user to pick the directional polar pattern for
optimum effect. For those applications
where gain-before-feedback is not a prob-
lem an omnidirectional pattern is included.
Applications requiring speaking close to the
microphone at podiums, lecterns, or pulpits
normally require a windscreen to control
breath noise and P-popping or, in some cases,
wind noise from circulating air. A small
external foam windscreen is included with
™
12 and
™
12 and PolarChoice 18
PolarChoice
PolarChoice
• Four polar patterns: Omnidirec-
tional, Cardioid, Supercardioid,
and Hypercardioid.
• Consistent on-axis response.
• Available in 12 or 18 inch versions.
• Shielded pre-amp is highly-resistant
to electrical noise and radio fre-
quency interference.
• Non-reflecting black finish.
• Three-pin male XLR-type output
connector.
• Phantom powered backed electret
condenser
™
the PolarChoice 12 and PolarChoice
microphones for those applications.
Architectural & Engineering
Specifications
™
PolarChoice 12
The microphone shall be a back-electret con-
denser type with a frequency response of 75
Hz to 15 kHz. The microphone shall have a
nominal, balanced output impedance of 200
ohms. The microphone shall have four
selectable polar patterns: omnidirectional,
cardioid, supercardioid, and hypercardioid.
The microphone shall have an output power
level of -44 dB, where 0 dB = 1 milliwatt
per pascal, and outputs shall not be appre-
ciably affected by the following temperature
and humidity extremes: -29° to 74° C (-20°
to 165° F) when the relative humidity is
0-50%; -29° to 57°C (-20° to 135°F) when
the relative humidity is 0-95%.
Dimensions shall be 20 mm (0.79 in.) diam-
eter and 409.7 mm (16.1 in.) long. The mi-
crophone shall include a 298.5 mm (11.8 in.)
gooseneck with professional XLR-type 3-pin
style terminating connector and an external
windscreen. The microphone shall have a
nonreflecting black finish. Termination to
the electronics module shall be a 3-pin male
XLR type connector. The microphone shall
™ 12
™
18
™
18
