SERVICE MANUAL
Differences Manual
• This Service Manual shows only the differences from SLV-679HF (US model).
Refer to the Service Manual (9-921-709-11) of SLV-662HF/679HF also for repair.
• Main Differences
1. Changed of SERVO/SYSTEM CONTROL IC (IC160)
2. Changed of Remote Commander
• Differences Table
Remote Commander
MA-341 Board, Complete
Front Panel
MICROFILM
SLV-679HF (US)
SLV-669HF
RMT-V266
RMT-V266A
A-6791-734-A
A-6713-521-A
X-3949-201-1
X-3949-993-1
SPECIFICATIONS
SLV-669HF
Refer to the SERVICE MANUAL of VHS
MECHANICAL ADJUSTMENT
MECHANICAL ADJUSTMENTS. (9-921-647-11)
VIDEO CASSETTE PLAYER
RMT-V266A
US Model
S MECHANISM
