SAFETY PRECAUTIONS IMPORTANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
SERVICING PRECAUTIONS CAUTION: Before servicing receivers covered by this service unit under test. manual and its supplements and addenda, read and follow the 2. After removing an electrical assembly equipped with ES SAFETY PRECAUTIONS on page 3 of this publication. devices, place the assembly on a conductive surface such as NOTE: If unforeseen circumstances create conflict between the aluminum foil, to prevent electrostatic charge buildup or...
Page 5
IC Remove/Replacement Some chassis circuit boards have slotted holes (oblong) through Circuit Board Foil Repair which the IC leads are inserted and then bent flat against the Excessive heat applied to the copper foil of any printed circuit circuit foil. When holes are the slotted type, the following technique board will weaken the adhesive that bonds the foil to the circuit should be used to remove and replace the IC.
SPECIFICATION NOTE : Specifications and others are subject to change without notice for improvement. 1. Application range 3. Test and Inspection Method This specification is applied to AL-04DA chassis. 3.1 Performance : LGE TV test method followed. 2. Requirement for Test 3.2 Demanded other specification.
Page 7
5. External Input Format Component Video Input (Y, C Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed 640 x 480 15.73 SDTV ,DVD 480I 704 x 480 31.47 59.94 SDTV 480P 1280 x 720 45.00 60.00 HDTV 720P 1280 x 720 44.96 59.94 HDTV 720P 1920 x 1080...
Page 9
6. General spec(Module) Item Unit Remark Active Screen Size 800.4(diagonal) 31.51 inches Outline Dimension 760(H) x 450(V) x 48(D) Typ. Pixel Pitch 170.25 x 510.75 x RGB Pixel Format 1366(H)x768(V) RGB stripe arrangement Color Depth 8bit 16.7 Mbit Luminance ,White cd/m2 Center 1 point Viewing Angle (CR>10)
ADJUSTMENT INSTRUCTION 1. Applicability 3. Full assembly process adjustment These specifications are applicable for all LCD TV models with an AL-04DA chassis that are manufactured by the <Precaution> Manufacturing Group of the Display Business Division, or Each PCB assembly must be checked using the check jig set any of its related manufacturers.
Page 11
3.2.4. Adjustment method 3.3.3. Manual White Balance Adjustment A) When entering the component, input 100% When adjusting after carrying out zero calibration for Horizontal Color Bar Pattern (HozTV30Bar) of the CA-100, the sensor should be tightly fixed on the supportable 720P mode, and select Component 1 LCD module surface.
SVC REMOCON FUNTION REAMARK To turn the TV on or off POWER To turn the TV on automatically if the power is supplied to the TV. (Use the POWER ON POWER key to deactivate): It should be deactivated when delivered. To activate the mute function.
1.1. Stationl Menu Display - Decide to enter 'Station Menu' or not in the 'Main Menu' by setting 'Station Menu Display' as Yes(Enter Possible) orNo(Enter Impossible) on the "LG Hotel Mode" OSD. 1.2. Programl Change - Decide to change channel or not by setting 'Program Change' as Yes(Change Possible) or No(Change Impossible) when present source is TV.
Page 14
1.3. Input Source Change - Decide to change input source or not by setting 'Input Source Change' as Yes(Change possible) or No(Change impossible). - When 'Input Source Change' is set to No(Change impossible), TV/AV key and Multimedia key doesn't work, and entering 'Input' item in the 'Main Menu OSD' is impossible.
Page 15
1.10. Program - Decide to turn on TV as set channel or last memorized channel or not by setting 'Channel' as On(Work) or Off(Do Not Work). - When 'Power On Operation' is set to Yes(Work), then user can enter 'Channel' and set the value. - When 'Power On Operation' is set to On(Work), setting 'Channel' value of ''Power On Operation' is possible and TV always turns on as set 'Channel' value.
TROUBLESHOOTING No power Check the condition of power Connect the connectors Related connectors. FAIL PASS Check the Measure the power board stand_by voltage : Digital ref. voltage : D_board P1401 5 th pin FAIL Power board CN804 ST_ 6V 1th pin 24V FAIL PASS Replace Power_board...
Page 17
No raster Standby Check No power voltage check : Replace D_board (Go to No power) D_board P1401 FAIL PASS 5th 6V PASS Measure Check No power Standby voltage : Replace A_board (Go to No power) A_board P804 7th 6V PASS FAIL PASS Measure...
Page 18
No sound Measure Check Sound supply : A_power board trans output: Replace power board A_board P804 #1 18V 18V at power_board FAIL FAIL CN803 #1 PASS Check If A_board 18V is short-circuited. Replace A_board Resistance btween A_board PASS P821 Pin No.2 and 3 infnity? Check output to the Speaker :...
Page 20
BLOCK DIAGRAM DESCRIPTION In this system there are 2 tuners - ATSC/NTSC tuner(TDVS-H701P) and NTSC-only tuner.(TAFM-H103P) So it is impossible to have a digital (main)/digital (sub) PIP. CXA2181Q is the AV switch for the component signals and CXA2069Q is the AV switch for the composite signals. The audio signals which separated by CXA2069 are sent to MSP4440.
REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN, CH : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit in the CQ : Polyestor RS : Metal Oxide Film P/No. means as follows; CE : Electrolytic RN : Metal Film CF : Fixed Film RH : CHIP, Metal Glazed(Chip)
