TABLE OF CONTENTS
IMPORTANT ..............................................................................
TOOLS & PARTS ..........................................................................
PRECAUTIONS.............................................................................
ASSEMBLY INSTRUCTIONS ..........................................................
GAS REQUIREMENTS & LEAK TESTING .........................................
SAFETY CHECKS .........................................................................
LOCATING HEATER FOR USE .......................................................
LIGHTING / SHUTDOWN ................................................................
STORAGE / BURNER REMOVAL......................................................
BURNER INSTALLATION / PILOT CLEANING ....................................
BURNER REMOVAL ......................................................................
TROUBLE SHOOTING ...................................................................
PARTS LIST .................................................................................
WARRANTY .................................................................................
READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE SURE YOUR PATIO HEATER IS
PROPERLY INSTALLED, ASSEMBLIED AND CARED FOR. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE. IF
YOU HAVE QUESTIONS CONCERNING ASSEMBLY OR OPERATION, CONSULT YOUR
DEALER, GAS APPLIANCE SERVICE REPRESENTATIVE OR YOUR GAS COMPANY.
NOTE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH THE CONSUMER AFTER INSTALLATION.
NOTE TO THE CONSUMER:
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE
STOP
DO NOT RETURN TO PLACE OF PURCHASE
OUTDOOR PATIO HEATER
INSTALLATION, OPERATION
MAINTENANCE INSTRUCTIONS
®
GAS-FIRED INFRARED
PAGE
1
2
3
4
7
8
9
10
12
13
14
15
16
17
Advertisement
Table of Contents
Related Manuals for Kirkland Signature PTH106SS-3G
Summary of Contents for Kirkland Signature PTH106SS-3G
-
Page 1: Table Of Contents
GAS-FIRED INFRARED OUTDOOR PATIO HEATER INSTALLATION, OPERATION MAINTENANCE INSTRUCTIONS ® FOR MODEL PTH106SS-3G TABLE OF CONTENTS PAGE IMPORTANT …………………………………………………………………… TOOLS & PARTS ……………………………………………………………….. PRECAUTIONS………………………………………………………………….. ASSEMBLY INSTRUCTIONS …………………………………………………. GAS REQUIREMENTS & LEAK TESTING ………………………………….. SAFETY CHECKS ………………………………………………………………. LOCATING HEATER FOR USE ………………………………………………. -
Page 2: Important
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. IMPORTANT WARNING * * * * * * For outdoor use only (outside any enclosure) Improper operation, installation, adjustment, alteration, servicing or maintenance can cause severe property damage or serious injury or death. -
Page 3: Hardware Bag
TOOLS AND PARTS NEEDED FOR ASSEMBLY NOTE: 20 pound (7.87kgs), 5 Gallon ( 18.9 litres ) LPG Tank is not supplied Tools Needed: Phillips Head Screwdriver Adjustable Opening Wrench Spray Bottle of Soapy Water (To check for leaks) Parts Supplied: Reflector (3) Dome Cap (1) Reflector Plate (1) -
Page 4: Tools & Parts
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. PRECAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY Do not use this space heater in an explosive atmosphere. Keep heater away 2. The heater does not reach temperature. from areas where gasoline or other 3. -
Page 6: Assembly Instructions
﹡﹡﹡ IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. ASSEMBLY INSTRUCTIONS STEP 1. Attach Table Legs Attach the post socket to the top of the tank enclosure using four 1/4” flat washers and four 1/4”... -
Page 7: Dome
﹡﹡﹡ IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. ASSEMBLY INSTRUCTIONS STEP 2. Attach Reflector STEP 2 Combine the three pieces of the reflector together Tighten up with three 5/32” x 8mm screws. Put the reflector plate on reflector then tighten up with three 1/4”x 10mm truss head screws from the bottom up. - Page 8 ﹡﹡﹡ IMPORTANT NOTICE: D O NOT return to place of purchase!!! P lease contact Customer Service hotline at 800-913-8999 for help. lease contact Customer Service hotline at 800-913-8999 for help. ASSEMBLY INSTRUCTIONS STEP 4: Gas Tank Open tank enclosure door. Secure the gas tank with the tank hook by attaching to the bracket of tank enclosure, as show in diagram.
-
Page 9: Gas Requirements & Leak Testing
﹡﹡﹡ IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. GAS REQUIREMENTS & LEAK TESTING NEVER CONNECT AN UNREGULATED GAS SUPPLY TO THE HEATER PRECAUTIONS Periodically check the whole gas system for A dented, rusted or damaged propane tank leaks or immediately check if the smell of may be hazardous and should be checked by your... -
Page 10: Safety Checks
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. SAFETY CHECKS STEP 1: 1. Check connection of the regulator to the propane tank STEP 1. connection. Remember, the POL adapter is a left-hand thread. -
Page 11: Locating Heater For Use
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase !!! Please contact Customer Service hotline at 800-913-8999 for help LOCATING HEATER FOR USE BE CAREFUL: When certain materials or items are left under this heater, while in use, they will be subjectok to radiant heat and could be seriously damaged. -
Page 12: Lighting/Shutdown
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase !!! Please contact Customer Service hotline at 800-913-8999 for help LIGHTING/SHUTDOWN BEFORE TURNING THE GAS SUPPLY ‘ON’: Visually inspect the hose assembly for evidence of excessive abrasion cuts or wear. If the hose leaks it must be replaced prior to use. - Page 13 ﹡﹡﹡ IMPORTANT NOTICE: DO NOT return to place of purchase !!! Please contact Customer Service hotline at 800-913-8999 for help LIGHTING/SHUTDOWN WHEN HEATER IS ON: ● The emitter screen will become bright due to intense heat. The color is more visible at night. ●...
-
Page 14: Storage/Burner Removal
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase !!! Please contact Customer Service hotline at 800-913-8999 for help STORAGE/BURNER REMOVAL WHEN STORING THE HEATER THE CONNECTION BETWEEN THE PROPANE TANK AND THE HEATER MUST BE DISCONNECTED AND THE PROPANE TANK REMOVED FROM THE ENCLOSURE AND STORED INDOORS IN A WELL VENTILATED AREA OR IN ACCORDANCE WITH CHAPTER 5 OF THE STANDARD FOR THE STORAGE AND HANDLING OF LIQUEFIED GASES, ANSI/NFPA 58-1998. -
Page 15: Burner Installation/Pilot Cleaning
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase !!! Please contact Customer Service hotline at 800-913-8999 for help BURNER INSTALLATION/PILOT CLEANING BURNER INSTALLATION: Install the burner assembly by reversing the four (4) steps used for disassembly making certain the burner assembly stands centered when complete. -
Page 16: Burner Removal
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase !!! Please contact Customer Service hotline at 800-913-8999 for help BURNER REMOVAL START DISASSEMBLY FOR CLEANING BY: STEP 1 1. Remove the valve panel to gain access to the pilot. Thermocouple Pilot 2. -
Page 17: Trouble Shooting
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase!!! Please contact Customer Service hotline at 800-913-8999 for help. TROUBLE SHOOTING Problem Possible Causes Correction Pilot won’t Air in gas line Purge gas line and repeat ignition operation light Lowe gas pressure Check gas pressure Gas line turned ‘OFF’... -
Page 18: Parts List
﹡﹡﹡IMPORTANT NOTICE: DO NOT return to place of purchase !!! Please contact Customer Service hotline at 800-913-8999 for hel PARTS LIST Parts List Description Reflector Nut Reflector Dome Cap Threaded Ends Stud Reflector Emitter Grid Main Burner Assembly Emitter base Pilot Assembly Control Housing Front Panel Lighting Instruction Plate... -
Page 19: Warranty
LIMITED WARRANTY FOR MODEL PTH-106SS-3G GAS-FIRED INFRARED OUTDOOR PATIO HEATER Nexgrill Industries, Inc warrants to the original consumer purchaser of each Outdoor Patio Heater that when subject to normal residential use, it is free from defects in workmanship and materials under normal conditions of use in a commercial application for a period of 90 days from purchase and in a residential application for a period of 1 year.
