Summary of Contents for gfm DP-1500B
-
Page 2: Table Of Contents
Listening to MP3 music ................14 Using the FILE option ..................15 Copying and Deleting Files ................15 Using the SETUP option ................17 Technical Support ..................18 Frequently asked questions ...............18 Specifications ...................22 Maintenance and Precaution .................23 Cleaning the LCD screen ................23 Regulatory Compliance..................24 GFM Guarantee…………………………………………………………………..25... -
Page 3: Introduction
Introduction Before operating the unit, please read this manual thoroughly, and retain it for future reference. This manual will help you use many of the exciting and useful features that will make your Digital Picture Frame viewing more enjoyable. This Digital Picture Frame lets you view digital pictures directly from your camera's memory cards. -
Page 4: Getting Started
Getting Started Package Contents Digital Picture Frame and stand User Guide AC/DC Adapter Remote control USB Cable... -
Page 5: Installing Your Unit
Installing your unit • Open the package and remove the protective foam. Remove the protective sleeve from the unit. • Install the Digital Picture Frame stand as the back of the unit. • Plug in the AC adapter into power outlet. Plug the other end into the unit. -
Page 6: Controls
Controls 1. Up 5. Right 2. Down 6. Exit 3. Enter 4. Left... -
Page 7: Using Your Remote Control
Using your Remote Control The following table briefly describes the remote control functions Button Description On/Off Switch on/off the frame Mode Mode Change Vol - Decrease volume Vol + Increase Volume Slideshow Start the slideshow Display the photo menu Menu Display the main menu Rotate Rotate the current... -
Page 8: Inserting Memory Cards
Inserting Memory Cards The Digital Picture Frame is compatible with the following memory cards: • Secure Digital Card (SD) • Secure Digital High Capacity Card (SDHC) • MultiMedia Card (MMC) • Memory Stick • CompactFlash (CF) Card • XD Picture Cards Insert the memory card with the front label facing AWAY from you. -
Page 9: Main Menu
Main menu Upon turning on the Digital Picture Frame, the slideshow will automatically start. Press the “MENU” button to show the following menu: Use the left and right arrows to move inside the menu and then press “Enter” to continue Note: In all menus, pressing the “Menu”... -
Page 10: Viewing Pictures
Viewing Pictures Make sure you have at least one picture on your memory card/ USB flash drive or internal memory. When this is done: • Highlight the “PHOTO” option from the main menu and press “ENTER” • Select the desired flash media. (SD/xD/CF/MS/USB/ Internal Memory) •... - Page 11 Once a slideshow is playing or a picture is being shown, press the OSD button. (In a slideshow, using the remote control press “Pause” then “OSD” to change settings on a specific picture). The following menu will appear: Previous Play previous picture in the picture list Play or Pause Play or pause the current slideshow.
-
Page 12: Watching Video
Watching video The Digital Picture Frame supports the following video formats: • Motion JPEG (avi): video format used by most digital cameras MPEG-I • MPEG-2 • MPEG 4 Make sure you have at least one video on your memory card or your USB flash drive. - Page 13 Once a movie is playing, press the OSD button on the remote control. The following menu will appear: Previous Play the previous movie in the play list Fast Forward Play forward the movie by 2/3/4 times. Play or Pause Play or Pause the movie. Fast Backward Play backward the movie by 2/3/4 times.
-
Page 14: Listening To Mp3 Music
Listening to MP3 music Make sure you have at least one MP3 file on your memory card/USB flash drive or internal memory. When this is done: • Choose the “MUSIC” option from the main menu and press “ENTER” • Select the desired flash media. (SD/xD/CF/MS/USB/Internal Memory) •... -
Page 15: Using The File Option
Using the FILE option With the FILE function you can Copy/Delete files. Copying and Deleting Files To copy and delete files on your memory card/ USB drive or internal memory: Copy: • Select the desired flash media that you want to copy from. (SD/xD/CF/MS/USB/ NAND Internal Memory) •... - Page 16 Delete: • Select the desired flash media on main menu. (SD/xD/CF/MS/USB/NAND-Internal Memory) • Select the “FILE” option from the menu and press “ENTER” • A list of available files will be displayed. Use the up and down arrows to highlight your required file and press the right arrow to highlight the desired file.
-
Page 17: Using The Setup Option
Using the SETUP option The following options can be changed by using the “SETUP” option from the main menu: Function Description Language Includes English, French, Spanish, Deutsch, Greece,Italian,Swedish,Turkce Slideshow time Slideshow speed: 3s/5s/15s/1mins/15mins/1hr Slideshow mode Off, Random, Fading, Bottom_to_top, Top_to_bottom, Left_to right, Right_to_left, Door_close, Door_open, Hori_cross, Verti_cross Music Repeat... -
Page 18: Technical Support
Technical Support Frequently asked questions 1) Q: Can I use touch-enabled technology for my Digital Picture Frame? A: The LCD screen does not support touch-enabled technology. Please use the buttons to control the Digital Picture Frame. 2) Q: If I keep showing the same photo for a long time, will it damage the LCD screen? A: No. - Page 19 A. Connect one end of the supplied USB cord into your computer and connect the other end to the digital frame. Drag and drop the desired photo, music, and movie files into the frame’s internal memory. 5) Q: What is the maximum picture size? A: The Digital Picture Frame is able to display pictures up to 12 Mega Pixels.
- Page 20 Troubleshooting Symptom Cause Corrective Actions Digital Picture Frame doesn’t The POWER connector to the Make sure you connect the power on unit is not securely inserted. AC adapter to the frame properly. When you connect the AC adapter to the frame and power up the unit, even without a memory card, you should see a blank...
- Page 21 high-speed memory card to play video files. Small video size on the screen Low Video Resolution Most digital cameras take video in 320x240 or lower resolution. The best supported resolution of a photo or video is 640 x 480. Use the Zoom button on the remote control to enlarge it.
-
Page 22: Specifications
Specifications Type 15inch Digital Picture Frame Resolution 1024 x 768 Alimentation 12 V Consumption 15Watts Working Temperature -20 to +65 degrees Luminosity 350cd/m max. Contrast 300:1 Viewing Angle 70/70/70/40 (CR=10) Response Time 25ms Display Mode Photo Changing 3s/5s/15s/1mins/15mins/1hr Interval File Format JPEG, MPEG1, MPEG2, MP3, MPEG4 Photo Size 12 Mega Pixels... -
Page 23: Maintenance And Precaution
Maintenance and Precaution • The Digital Picture Frame is for indoor use only. • To reduce the risk of fire or electric shock; do not expose this appliance to rain or moisture. • Do not block the ventilation holes on the back of the Digital Picture Frame at any time. -
Page 24: Regulatory Compliance
FCC Declaration of Conformity Model Number: DP-1500B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
