LevelOne WAB-7400 Brochure & Specs

Dual Radio PoE
Mesh Access Point
H/W Version: 1
Superior Wireless Mesh Performance
The LevelOne WAB-7400 is a dual-radio wireless
mesh access point that was developed to tackle the
professional-level wireless challenges any systems
integrator will face. Whether it's creating an industrial
grade wireless mesh network for a factory or
warehouse, or building a flexible network on a large
corporate campus, the LevelOne WAB-7400 does the
job with simplicity and ease.
Dual Band Technology
When a client needs to transmit surveillance data
around the premises, but they also want wireless
internet access at each access point, what do you
do? The LevelOne WAB-7400 comes dual-radio
technology, allowing both requirements to be
Key Features
- IEEE 802.11a/b/g standard compliant operates on
the 2.4 GHz/5 GHz unlicensed ISM spectrum
- Self-configuration and healing Mesh network
- Advanced OLSR (Optimal Link State Routing)
protocols find the optimal routing path once the link
status is changed or broken
- Support 802.1x (EAP-TLS/TTLS/SIM/PEAP) and
802.11i (WPA/WPA2, AES) high security level
- Support 802.1Q VLAN
- Support WMM extension and bandwidth control
- 802.3af PoE power supply and data transmission
- Support SNMP v1/v2c/v3
- IP-65 Weather proof design

1 2
fulfilled. The 5 GHz radio creates a robust auto-
forming and self-healing line of sight backhaul
network to handle high-bandwidth data, voice, and
surveillance streams. The 2.4 GHz radio allows users
to connect via the broadcast SSIDs for internet surfing
or accessing resources on the LAN. Since each chipset
operates on a different frequency, both networks offer
professional-class performance with no overlapping
interference.
Power over Ethernet (PoE)
With PoE functionality, system installers can deploy
WAB-7400 in tight spots on the roof of tall buildings
because all power and data is transferred using a
single Cat.5 cable.
1. WLAN 2 connector
2. WLAN 1 connector
3. Ethernet 10/100 RJ45 port
3
Works Well With
OAN-2150
15dBi Omni-Directional Outdoor
Antenna
OAN-0600
Dual-Band Omni-Directional
Antenna
WAB-7400
