Summary of Contents for Proxima DP2000s
- Page 1 PLEASE READ This manual is provided as a free service by Projector.com. We are in no way responsible for the contents of the manual. We do not guarantee its accuracy and we do not make any claim of copyright. The copyright remains the property of their respective owners.
- Page 2 DP2000s/DP2000x User’s Guide...
- Page 3 Declaration of Conformity FCC Warning Australian Certification C-tick mark Canada Safety Certifications Trademarks...
-
Page 4: Important Operating Considerations
4XL.N Table of Contents 6HWXS Important Operating Considerations Do not place objects in this area behind the projector... -
Page 6: Projector Components
Introduction Projector components keypad speaker zoom Included items focus projector foot release remote control receiver (IR) lens cap remote control receiver (IR) remote control power cord* computer cable documentation audio/video cable *country-dependent power cord audio cable leveling foot connector Online Registration www.infocus.com/register dust filters lamp door... -
Page 7: Optional Computer Connections
Connecting a computer connect computer cable Required computer connections Computer In connect power cord % Optional computer connections connect audio cable connect mouse cable connect monitor cable... -
Page 8: Displaying A Computer Image
Displaying a computer image remove lens cap Power press Power Power ? No startup screen? turn on computer Computer activate laptop’s external port ? No computer image? Auto Image... - Page 9 Using the projector with Windows 98 for the first time Next Next Next Next...
-
Page 10: Adjusting The Image
Adjusting the image adjust height adjust distance zoom adjust zoom and focus focus adjust keystone Keystone Keystone adjust Picture menu... -
Page 11: Connecting A Video Device
Connecting a video device Standard video connections connect A/V cable Video Audio In connect power cable NOTE connect S-video and A/V cables Optional video connections S-video... -
Page 12: Displaying A Video Image
Displaying a video image remove lens cap Power press Power Power ? No startup screen? turn on video device Video ? No video image? adjust height adjust distance... - Page 13 zoom adjust zoom and focus focus adjust keystone Keystone Keystone adjust volume adjust Picture menu...
-
Page 14: Shutting Down The Projector
Shutting down the projector Table 1: LED behavior and meaning LED color/behavior Meaning solid green The projector is plugged in, or the projector has been turned on and the software has initialized. The projector Settings>System has been turned off and the fans have stopped. -
Page 15: Startup Screen
Problem Solution Result Plug power cord in Remove lens cap No startup screen Correct image Press Power button startup screen Computer image projected Only startup screen appears Press the Computer button Activate laptop’s external port startup screen Restart laptop... - Page 16 Problem Solution Result No computer image, just the words “Signal out of Adjust computer refresh rate in Computer image projected range” Control Panel>Display>Settings>Advanced >Adapter (location varies by operating system) You may also need to set a different resolution on your computer, as shown in the following problem, “Image fuzzy or cropped.”...
- Page 17 Set your computer’s display resolution to Image clear and not cropped Image fuzzy or cropped the native resolution of the projector (Start>Settings>Control Panel>Display>Settings tab, select 800x600 for the DP2000s, 1024x768 for DP2000x) For a laptop, disable laptop monitor or turn-on dual- display mode...
- Page 18 Image not centered on screen Move projector, adjust zoom, adjust height Correct image zoom Adjust horizontal or vertical position in Picture>Advanced menu Adjust keystone on keypad Square image Image not square...
- Page 19 Adjust Sharpness in the Picture>Advanced Correct image Image not sharp menu Change aspect ratio to 16:9 in Correct image Image does not fit 16:9 screen Picture>Aspect ratio menu Turn on/off Ceiling in Settings>System Correct image Image upside down menu...
- Page 20 Image reversed left to right Turn on/off Rear in Settings>System menu Correct image Adjust color, tint, color temperature, Projected colors don’t match source Correct image brightness, contrast in the menus COLOR COLOR Make sure vents aren’t blocked, turn off the Lamp won’t turn on, LED blinking red Lamp turns on projector and allow it to cool for a minute...
-
Page 21: Still Having Problems
Lamp won’t turn on, LED blinking red, “Change If lamp hours > 2000, lamp must be Lamp turns on lamp” message appears at startup replaced. See page 34. blinks red startup Check lamp hours: should be less screen than 2000 hours in the Main>About menu Still having problems? -
Page 22: Using The Remote Control
Using the remote control button backlight cursor control mouse buttons Menu menu navigation Select buttons Power Volume Mute Video Computer Troubleshooting the remote Blank Effect... -
Page 23: Using The Audio
Using the audio connect audio cable Audio In Volume Mute Troubleshooting Audio adjust volume Mute Volume Using the keypad buttons Power Menu menu navigation buttons Select Up/Down arrows Auto Image Presets Keystone Volume Video Computer... -
Page 24: Optimizing Computer Images
Optimizing computer images Presentation features Effect Blank... -
Page 25: Optimizing Video Images
Optimizing video images Customizing the projector Settings>System Set- tings>System Effect... -
Page 26: Using The Menus
Using the menus Menu Main menu keypad navigation buttons Select Select Menu dots Picture menu Settings menu About menu... -
Page 27: Picture Menu
Picture menu Select Select increasing keystone decreasing keystone Keystone Picture menu Contrast Brightness Color NOTE Tint Aspect Ratio Aspect ratio... - Page 28 Presets Settings>Service Save User Settings Presets Room Lighting Room Lighting...
- Page 29 Advanced menu Sharpness Sharpness Advanced menu Color Temperature Color Temperature Phase Tracking Horizontal/Vertical Position...
-
Page 30: Settings Menu
Settings menu Sources>Startup Source: Sources Autosource Settings menu Computer Video Startup Source System Rear Ceiling System menu Display Messages Power Save Power Screen Save... - Page 31 Startup Logo: Blank screen Startup Logo Blank Screen Blank Effect Effect Select Blank Mute Aspect Ratio: Effect Source: Auto Image: Freeze: Zoom Effect Effect About:...
- Page 32 PiP: PiP size Picture in Picture PiP Position Mask: Language Language Service Factory Reset Reset Lamp Service Info menu Service menu Service Info Service Code About Effect About menu...
-
Page 34: Maintenance
Maintenance Cleaning the lens Cleaning the dust filter... -
Page 35: Replacing The Projection Lamp
Replacing the projection lamp Lamp hours used NOTE 60 minutes CAUTION... - Page 36 WARNING WARNING WARNING Power Settings>Service Reset Lamp...
- Page 37 Cleaning the lamp housing screens Using the security lock...
-
Page 38: Specifications
340-1029-xx Optics Focus Range 4.9 - 29 feet (1.5 - 8.9 m) Quick Setup card 009-0657-xx Lamp type 132-watt UHP lamp for DP2000s 150-watt UHP lamp for DP2000x User’s Guide with CD 010-0379-xx Safety card 009-0659-xx Input Power Requirements 100-240V 2.5-1 A, 50-60 Hz... -
Page 39: Projected Image Size
84” Diagonal Wall/Ceiling Mounted Screen HW-WALLSCR84 Table 3: Range of distance to the screen for a given screen size for Portable Projector Stand SP-STND DP2000x Replacement Lamp Module for DP2000s SP-LAMP-005 Distance to screen Diagonal Replacement Lamp Module for DP2000x SP-LAMP-007 Maximum... - Page 40 Index Blank 30 Brightness 26 A/V cable, connecting 10 About menu 31 cables accessories included 5 included 5 ordering 37, 38 ordering 37, 38 ceiling projection 29 activating laptop’s external video 7 cleaning Add New hardware Wizard 8 dust filters 33 adjusting lamp housing screens 36 Brightness 26...
- Page 41 desktop computer, viewing image on monitor 6 keypad buttons 22 Display Messages 29 keystone, adjusting 9 displaying computer image 7 languages 31 lamp onscreen menus 25 ordering 37 PiP 31 replacing 34 video image 11 lamp housing screens, cleaning 36 drivers, installing 8 Language 31 laptop computer, activating external video 7...
- Page 42 Phase 28 ratio, aspect 26 Picture in Picture 31 rear projection 29 Picture menu 26 refresh rate 15 PiP 31 registering your projector 5 Power button 22 remote control power cord, connecting 6 intalling batteries 21 Power Save 29 using 21 powering on the projector 7 replacing the projection lamp 34 presentation features 23...
- Page 43 Tint 26 Tracking 28 troubleshooting 13 turning off the projector 13 turning on the projector 7 USB mouse, connecting 6 using the menus 25 video device, connecting 10 video image displaying 11 optimizing 24 volume adjsuting 12 zoom 9, 30...
-
Page 44: Limited Warranty
Limited Warranty WARRANTY LIMITATION AND EXCLUSION Limited Warranty Alternatives: 2 Year Parts and Labor Product Warranty 1 Year Parts Only Accessory Warranty DISCLAIMER OF UNSTATED WARRANTIES 90 Day/500 Hour Replacement Lamp Warranty During the Warranty period for the Product, InFocus warrants that Replacement lamps, which are purchased at the time of projec- tor purchase, will have a 90-day or 500 hour warranty, whichever comes first, from the date the spare lamp is put into use. - Page 45 Limited Warranty Period LIMITATION OF LIABILITY To Be Eligible For Limited Warranty Coverage To Obtain Warranty Service Limitation on Bringing Action Governing Law Mandatory Arbitration...
