Installation - Honeywell Modutrol IV Motors Series 90 Product Data

a
Nominal Timing in sec
90° 160°
30 60
d d
15 /30 30 /60
30 60
60 120
a
Timings apply to all TRADELINE models. Some OEM models are available with non-standard timing/torque.
b
The torque rating for dual-ended shaft motors is the sum of the shaft torques (power-end torque plus auxiliary-end torque).
c
Breakaway torque is maximum torque available to overcome occasional large loads such as a seized damper or valve.
d
Low timing is for M9184D1005 only.
NOTE: Some 150 lb-in. and 300 lb-in. torque adjustable stroke motors have timings that are twice that of their fixed stroke
counterparts.
IMPORTANT
Never use a Modutrol Motor continuously at the Breakaway Torque rating.

INSTALLATION

When Installing this Product...
1. Read these instructions carefully. Failure to follow them
could damage the product or cause a hazardous
condition.
2. Check the ratings given in the instructions and on the
product to make sure the product is suitable for your
application.
3. Installer must be a trained, experienced service
technician.
4. After installation is complete, check out product
operation as provided in these instructions.
CAUTION
Electrical Shock or Equipment Damage Hazard.
Can shock individuals or short equipment
circuitry.
Disconnect all power supplies before installation.
Motors with auxiliary switches can have more than
one disconnect.
CAUTION
Equipment Damage Hazard.
Can damage the motor beyond repair.
Never turn the motor shaft by hand or with a wrench.
Forcibly turning the motor shaft damages the gear
train and stroke limit contacts.
IMPORTANT
Always conduct a thorough checkout when
installation is complete.
Location
Allow enough clearance for installing accessories and motor
servicing when selecting a location (see Fig. 1). If located
outdoors, use liquid-tight conduit connectors with the junction
box to provide NEMA 3 weather protection. If mounted
outdoors in a position other than upright, install a 4074ERU
Weatherproofing Kit and liquid-tight connectors to provide
NEMA 3 protection.
Table 5. Series 90 Modutrol Motor Timing and Torque Ratings.
Normal Running Torque
Spring Return
25 (2.8) 35 (4)
60 (6.8) 75 (8.5)
— 150 (17)
— 300 (34)
Rated Torque in lb-in. (N•m)
Non-Spring Return
50 (5.7)
120 (13.6)
—
—
CAUTION
Motor Damage Hazard.
Deteriorating vapors and acid fumes can damage
metal parts.
Install motor in areas free of acid fumes and other
deteriorating vapors.
In excessive salt environments, mounting base and screws
should be zinc or cadmium plated, not stainless steel or brass.
Use the 220738A Adapter Bracket for mounting on these
surfaces.
Mounting
CAUTION
Equipment Damage Hazard.
Can damage the motor beyond repair.
Always install motors with the crankshaft horizontal.
Improper motor mounting can result in inadequate
motor gear train lubrication.
Use the following guidelines for proper motor mounting:
• Always install motors with the crankshaft horizontal.
• Mounting flanges extending from motor housing base are
drilled for 1/4 inch (6.4 mm) machine screws or bolts.
• Non-Spring Return Motors are shipped from the factory in
the closed position (at the limit of counterclockwise
rotation, as viewed from the power end of the motor).
• Spring Return Motors are shipped from the factory in their
normal position:
— Normally closed models: shipped at limit of
counterclockwise rotation, as viewed from the power
end of the motor.
— Normally open models: shipped at limit of clockwise
rotation, as viewed from the power end of the motor.
NOTE: Refer to Fig. 2 for graphical representation of full
open and full closed.
5
SERIES 90 MODUTROL IV™ MOTORS
b
Breakaway Torque
Spring Return Non-Spring Return
70 (8)
150 (17)
300 (34)
600 (68)
c
63-2190—3
