c o n n e c t i n g

AirLancer Extender O-D9a

High-speed MIMO antenna

5-GHz polarisation diversity antenna for LANCOM 802.11n MIMO access points

Two antenna connectors for transmitting 2 spatial streams

Patch antenna with 9° directional beam and 23-dBi gain

For WLAN point-to-point connections up to 20 km

Mounting kit, cables and adapters included

The AirLancer Extender O-D9a directional antenna from LANCOM Systems is a high-end

product for connecting wireless LANs over long distances. With 23-dBi gain and two

transmission paths, point-to-point connections can be achieved with gross data rates of

up to 300 Mbps and covering ranges of up to 20 km.

y o u r

b u s i n e s s

Need help?

Do you have a question about the AirLancer 0-D9a and is the answer not in the manual?

Page 1 For WLAN point-to-point connections up to 20 km Mounting kit, cables and adapters included The AirLancer Extender O-D9a directional antenna from LANCOM Systems is a high-end product for connecting wireless LANs over long distances. With 23-dBi gain and two transmission paths, point-to-point connections can be achieved with gross data rates of...
Page 2 AirLancer Extender O-D9a Technical data Ranges / data rates 300 Mbps 1.200 m (Mast/mounting height 5 m) 90 Mbps 8.000 m (Mast/mounting height 16 m) 15 Mbps 20.000 m (Mast/mounting height 48 m) All specifications: Simulation with LANCOM Antenna Calculator for LANCOM L-310agn wireless access point with AirLancer Extender O-D9a, 30-dBm transmission power (EIRP), each with 2 x 1 m, SA-5L surge protection adapter, 10 dB “poor-weather reserve”, unobstructed line-of-sight and Fresnel zone, at the given mast/mount height.
Page 3 AirLancer Extender O-D9a Radiation characteristics Horizontal Vertical www.lancom.eu LANCOM Systems GmbH I Adenauerstr. 20/B2 I 52146 Wuerselen I Germany I E-mail sales@lancom.eu...
