Smart Solar 3081WRM1 Instruction Manual

ARCHITECTURAL GRADE SOLAR LED WALK LIGHT
Instruction Manual
Remove the battery cover by unscrewing the four screws as
shown in figure 3. Remove and replace the two AA – NiMh
For further information,
batteries as shown in figure 4. Re-assemble the unit in reverse
order and enjoy.
including parts, warranty
repair, or general
Notes: Be sure to check the unit is turned ON after the
inquiries, please
batteries are replaced See Section 5 above if you have any
contact Smart Solar:
questions about how to check this.
Used batteries must be disposed of carefully with regard to the
USA Corporate Office: environment and should NOT be put into the family waste.
7. FUNCTIONALITY PROBLEMS
Tel:
Light does not switch on in darkness.
877-550-8840
Check whether the switch is on "I" (on position).
Another light source (eg. streetlight) simulates daylight and
prevents the light from switching on automatically.
Website:
Position the module in a darker place.
smartsolar
www. .com
Light does not switch on at all or only for a short time even
though there has been a full day of sunshine.
Battery is flat. Replace the rechargeable battery pack.
8. TECHNICAL DATA
LED description:
LED brightness:
LED consumption:
LED voltage:
Solar panel (Voc):
Solar panel (Isc):
Battery size & type:
Battery capacity:
9. SPARE PARTS
Ni-Mh Battery - BPAA800
10. FULL 1 YEAR WARRANTY
If within 12 months from the date of purchase this
product fails due to a defect in material or workmanship,
Smart Solar will replace or repair it free of charge.
The warranty does not apply to:
Damage caused by accidents, abuse, poor handling, frost or
normal wear and tear. Products which have been subject to
unauthorized repair or modification or the batteries used in
this product. For further information please contact your
nearest service centre detailed on the last page of this
instruction manual.
Model 3081WRM1
1 super bright white LED
3.0Lm
27mA
3.2v
4v
75mA
AA 1.2v Ni-Mh (2x)
700mAh
MODEL 3081WRM1
Architectural Grade
Solar LED Walk Light
Solar powered illuminated garden accent light
Operates automatically during nightfall
