- Page 1 ® DAC-3MKII INSTRUCTIONS DIGITAL TO ANALOG CONVERTER...
-
Page 2: Digital To Analog Converter
COPY RIGHT The copyright is in procession of CHENGDU XINDAK ELECTRONIC (XINDAK). Without permission in written from Xindak, anyone can not copy or spread any content in this manual in any form. TRADEMARK: All the trademark and names which are mentioned in this manual are in procession of Xindak. -
Page 3: Important Safety Instruction
DAC-3MKII Chapter 1 Important Safety Instruction CAUTION Dangerous Voltage The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 4: Before Use
22. Never operate this product in an explosive atmosphere. 2.2 Check Accessory Unpack your DAC-3MKII products and keep all packing materials for future transport or service, locate and remove all accessory items from the accessory box within the controller shipping carton. -
Page 5: Product Features
Introduction 3.1 Product Features Dear user, thank you for purchasing our DAC-3MKII Digital D/A Converter. This is a specially-designed model for the audiophiles who have high requirements on the sound-reproduction ability. As a 24Bit/96KHz high quality stereo Digital/Analog Audio Converter, it has both transistor and tube outputs, extremely suitable for the owners of VCD, DVD and CD player as well as computer owners to upgrade their current audio system. -
Page 6: Block Diagram
DAC-3MKII Chapter 3 Introduction 3.2 Block Diagram DIGITAL ANALOG CONVERTER 3.3 Front panel Digital to Analogue Converter DAC-3MKⅡ Power Button: Power Indicator: Press this button, this unit will be switched on. This indicator will be light when this unit is switched on. -
Page 7: Rear Panel
DAC-3MKII Chapter 3 Introduction 3.4 Rear Panel Right Balanced Audio Output Terminal Output the balanced audio signal (analog stereo)amplified by transistor to the input port on the amplifier. Audio Output Terminal Output the analog stereo audio signal amplified by tube to the input port on the amplifier. -
Page 8: Specification
DAC-3MKII Specification Chapter 4 4.1 Dimensions 430mm Digital to Analogue Converter DAC-3MKⅡ Volume Power Selector... - Page 9 DAC-3MKII Chapter 4 Specification 4.2 Specification System: Stereo audio digital to analog converter ° ° Temperature: C~+35 Humidity 5%~85% Power specifications Specified on rear panel decal Power consumption max. 25W Frequency range 20Hz-20KHz, 0.5dB Dynamic range 113dB Harmonic distortion+Noise(THD+N) -101dB...
- Page 10 No.126, Section 2, East 1 Round Chengdu, Sichuan, China P.C. 610051 You can find your nearest authorized distributor and more product information on our website: www.xindak.com XD3.834.046sms...
