MANUAL TRANSFER SWITCH
On the purchase of your new EmerGen Switch
Your new EmerGen Switch will provide you with a way to safely utilize
your generator power through your existing electrical wiring during a power
outage. You'll install your switch next to your home's electrical panel load
center and then you'll connect circuit breaker wires to the transfer switch's
circuits. Once you power up your portable generator, you will manually turn on
each switch and that generator energy is transferred as electrical power and
goes through the house circuits you have previously chosen.
Your EmerGen Switch is easy for a licensed electrician or qualified
professional to install, safe for a homeowner to operate, and will work with
120/240V single phase AC generators, factory equipped with NEMA type
receptacles L14-20R
Your EmerGen Switch will not permit connection to both utility and generator
power at the same time.
Table of Contents
Congratulations !
Gould premium quality product.
, another
®
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
Advertisement
Table of Contents
Related Manuals for Connecticut Electric EmerGen L14-20R
Summary of Contents for Connecticut Electric EmerGen L14-20R
- Page 1 On the purchase of your new EmerGen Switch Gould premium quality product. Your new EmerGen Switch will provide you with a way to safely utilize your generator power through your existing electrical wiring during a power outage. You’ll install your switch next to your home’s electrical panel load center and then you’ll connect circuit breaker wires to the transfer switch’s...
- Page 2 1. The National Electrical Code states the connection of a generator to any electrical circuit normally powered by an electrical utility, must be by means of an approved transfer switch so as to isolate the electrical circuit from the utility system when the generator is operating. Your EmerGen Switch is approved by a Nationally Recognized Testing Laboratory to accomplish the isolation this code is requiring.
-
Page 3: Installation Instructions
The wires can hang freely. 5. Without over-manipulating the flex conduit, secure your EmerGen Switch to the wall with fasteners appropriate for the wall’s construction. If you are mounting this unit flush to the wall, follow instructions included with the Flush Cover Kit. - Page 4 Wiring the EmerGen Switch to the Load Center From your plan, locate the circuit breaker that is to be connected to the EmerGen Switch circuit “A”. Turn that circuit breaker to the OFF position. Loosen the lug securing the wire and remove the wire.
- Page 5 2 pole circuit breaker. b) The black EmerGen Switch “C” wire and one of the hot wires from the circuit breaker are placed up the side of the load center. Insert both wires into a yellow wire connector and twist tightly.
-
Page 6: Completing The Installation
Cut and strip the wire appropriately. Insert the wire into the hole and tighten securely. 2) The EmerGen Switch green (ground) wire(s) needs to be installed into an unused hole in the ground bar in the load center. Select an unused hole in the ground bar in the load center. - Page 7 (some connectors do not twist). Align the female socket of the cord set into your EmerGen Switch, push it in and turn clockwise to lock.
-
Page 8: Trouble Shooting
GFCI breaker on 1. Neutral / Ground bond in Honda generator generator trips when connected to switch Trouble Shooting Cause 1. Reset circuit breaker. 2. Check and repair. 3. Select a different load or appliance that is in good condition.
