Summary of Contents for MicroVision SHOWWX+
-
Page 3: Table Of Contents
Contents Important Safety Information Package Contents SHOWWX+ Laser Pico Projector ™ Introduction Getting Started Install Battery Charge Battery Power ON or OFF Connect to a Video Source How To Connect To An iPod, iPhone, or iPad Connecting To Other Composite (TV-Out) VideoSources Usage Guidelines Advanced Controls Menu Controls... -
Page 4: Important Safety Information
Intended tement Use Sta The SHOWWX+™ laser pico projector is designed to operate with the MicroVision specified battery and MicroVision battery charger in a normal office and home environment within the following parameters: » Operating Temperature: 10° - 30° C, ( 50° - 86° F) »... - Page 5 To avoid risks associated with fire and explosion: » Do not immerse the projector or battery in any liquid or allow either to get wet. » Use only AC adapter and battery provided by MicroVision. » Do not disassemble the battery or modify it in any way.
-
Page 6: Safety Labels
Safety Labels The SHOWWX+™ Laser Pico Projector is a CLASS 2 LASER PRODUCT as defined in IEC 60825-1, 2007-03. MicroVision has designed the SHOWWX+ to be safe for general use as a mobile projector. IEC and CDRH Statements of Compliance The SHOWWX+ complies with IEC 60825-1, 2007-03. -
Page 7: Product Disposal
Specifications subject to change without notice. Copyright & Trademarks ® ©2010 MicroVision, Inc. All rights reserved. PicoP and SHOWWX+™ are trademarks of MicroVision Inc. iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered... -
Page 8: Package Contents
Package Contents Please make sure you have received all items included with the product. For missing items contact customer support. SHOWWX+ SHOWWX+ SHOWWX+ Rechargable Battery Laser Pico Projector Wall Charger SHOWWX+ Cable for iPod, iPhone, and iPad SHOWWX+ Micro-USB Cable Composite Adapter Storage Pouch User Guide... -
Page 9: Showwx
SHOWWX+ Laser Pico Projector ™ Window Down/Hot Key 2 Up/Hot Key 1 Power Button Menu/Select Button LED Indicators Micro-USB/Power Input Video Input 3.5 mm Audio Jack Wrist Strap Holder... -
Page 10: Introduction
Introduction Thank you for purchasing the MicroVision SHOWWX+ laser ™ pico projector. The SHOWWX+ projects big, bright, and colorful images that are always in focus, yet is small enough to fit in your pocket. Connect the SHOWWX+ to a video output-capable device to spontaneously share photos and videos, presentations and more, in a big screen experience. -
Page 11: Charge Battery
Charge Battery Plug Wall Charger Into Outlet Connect To Micro-USB/Power Input Orange LED: Battery charging Green LED: Battery fully charged Note: » Allow for a minimum of 4 hours charging before first time use. » The wall charger will not charge the battery while the SHOWWX+ is powered ON. »... -
Page 12: Connect To A Video Source
Adapter (NTSC/PAL) RCA Video out connection SHOWWX+ VGA Dock Laptop and PC devices To see compatible devices with the SHOWWX: http://www.MicroVision.com/showwx/compatibility.html How to Connect to an iPod, iPhone, or iPad Power on the projector Connect the cable to the projector Connect the cable to the iPod, iPhone, Wait to see “Ready To Use”... -
Page 13: Connecting To Other Composite (Tv-Out) Videosources
Connecting to Other Composite (TV-out) Video Sources The SHOWWX+ can connect to other video sources that have Composite (TV/Video-Out) using the included Composite adapter. To display content, make sure the source device has TV/Video-Out set to “ON” or “Enabled”. To learn if your video source device is capable of TV/Video-Out and how to enable, refer to its User Guide. -
Page 14: Usage Guidelines
Usage Guidelines There are two main factors to consider when using the SHOWWX+. Ambient light » It is recommended to shut blinds, close curtains and turn lights down to make the room dark so the projected image looks the best. Distance from screen »... -
Page 15: Advanced Controls
Advanced Controls Menu Controls The SHOWWX+ was designed as a plug-and-play device, however, some users may want to make adjustments to the settings such as change colors, adjust aspect ratio, and adjust brightness. The following information will help you understand how to fully operate the SHOWWX+. -
Page 16: How To Adjust Brightness
How To Adjust Brightness The image brightness can be reduced for close distance viewing in darker environments. Press the button to bring up the on screen menu. Use the buttons to navigate to BRIGHTNESS and press Select the desired setting and press to accept. -
Page 17: How To Adjust The Color Alignment
How To Adjust The Color Alignment Users can adjust horizontal or vertical alignment of each individual color (red, green, and blue). Press the button to bring up the on screen menu. Use the buttons to navigate to SYSTEM and press Use the buttons to navigate to COLOR ALIGNMENT and press An image of a vertical and horizontal crossed in the middle will appear... -
Page 18: How To Check Remaining Battery Life
How to Check Remaining Battery Life Follow these instructions to view how much battery life is remaining. Press the button to bring up the on screen menu. Use the buttons to navigate to SYSTEM and press Use the buttons to navigate to PROPERTIES and press Use the buttons to navigate to BATTERY INFORMATION and press How to Adjust The Green and Magenta Color... -
Page 19: Troubleshooting
Troubleshooting Problem Cause Solution The projector does Battery not inserted Make sure the battery not turn on. correctly. is correctly inserted. Battery not charged. Make sure the battery is fully charged. The projector colors look Different Color Mode Change to preferred Color Mode. incorrect. -
Page 20: Led Status & Meaning
You can find the Serial Number located under the battery. Register your Product Online Registering your new MicroVision product online is quick and easy. Your registration will allow us to serve you better over the lifetime of your product. Being a registered owner also keeps you informed of important product notifications and helps us continue to design products that meet your needs. - Page 22 EXTENT PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL Ninety (90) days BE LIMITED IN DURATION TO THE DURATION OF THE EXPRESS If a valid warranty claim is received by MicroVision or its WARRANTY AND TO THE REPAIR OR REPLACEMENT SERVICE authorized service representative during the Warranty AS DETERMINED BY MICROVISION IN ITS SOLE DISCRETION.
- Page 24 6222 185th Avenue NE Redmond, WA 98052 USA www.microvision.com DA0129234-001 Rev. B...
